HBT-11 HDBaset to HDMI Receiver Box
Product Information
Product Name: HBT-11 Receiver
Manufacturer: Datavideo
Model Number: HBT-11
FCC Compliance Statement
This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions:
- This device may not cause harmful interference.
- This device must accept any interference received, including
interference that may cause undesired operation.
Warnings and Precautions
- Read all of these warnings and save them for later
reference. - Follow all warnings and instructions marked on this unit.
- Unplug this unit from the wall outlet before cleaning. Do not
use liquid or aerosol cleaners. Use a damp cloth for cleaning. - Do not use this unit in or near water.
- Do not place this unit on an unstable cart, stand, or table.
The unit may fall, causing serious damage. - Slots and openings on the cabinet top, back, and bottom are
provided for ventilation. To ensure reliable operation and to
protect against overheating, these openings must not be blocked or
covered. - Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat. - Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with one wider
than the other. A grounding-type plug has two blades and a third
grounding prong. The wide blade or the third prong is provided for
your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet. - Protect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus. - Make sure that the total amperes of all the units that are
plugged into a single wall outlet do not exceed 15 amperes. - Never push objects of any kind into this unit through the
cabinet ventilation slots, as they may touch dangerous voltage
points or short out parts that could result in risk of fire or
electric shock. Never spill liquid of any kind onto or into this
unit. - Except as specifically explained elsewhere in this manual, do
not attempt to service this product yourself. Opening or removing
covers that are marked Do Not Remove may expose you to dangerous
voltage points or other risks, and will void your warranty. Refer
all service issues to qualified service personnel.
Warranty
Standard Warranty:
Datavideo equipment is guaranteed against any manufacturing
defects for one year from the date of purchase. The original
purchase invoice or other documentary evidence should be supplied
at the time of any request for repair under warranty. The product
warranty period begins on the purchase date. If the purchase date
is unknown, the product warranty period begins on the thirtieth day
after shipment from a Datavideo office. All non-Datavideo
manufactured products (product without Datavideo logo) have only
one year warranty from the date of purchase. Damage caused by
accident, misuse, unauthorized repairs, sand, grit or water is not
covered under warranty. Viruses and malware infections on the
computer systems are not covered under warranty. Any errors that
are caused by unauthorized third-party software installations,
which are not required by our computer systems, are not covered
under warranty. All mail or transportation costs including
insurance are at the expense of the owner. All other claims of any
nature are not covered. All accessories including headphones,
cables, and batteries are not covered under warranty. Warranty only
valid in the country or region of purchase. Your statutory rights
are not affected.
Three Year Warranty:
All Datavideo products purchased after July 1st, 2017, are
qualified for a free two years extension to the standard warranty,
providing the product is registered with the manufacturer.
Product Usage Instructions
- Read and familiarize yourself with the warnings and precautions
mentioned in the user manual. - Ensure the device is placed on a stable surface away from heat
sources and water. - Keep the ventilation slots unblocked to prevent
overheating. - Do not attempt to clean the device with liquid or aerosol
cleaners. Instead, use a damp cloth. - Before connecting or disconnecting any cables, ensure that the
unit is unplugged from the wall outlet. - Do not insert any objects into the cabinet ventilation slots to
avoid electric shock or fire hazards. - If any servicing is required, do not attempt to open or remove
covers marked “Do Not Remove.” Contact qualified service
personnel. - Register the product with Datavideo to qualify for the
three-year warranty extension (if applicable).
BOX
RECEIVER
HBT-11
Instruction Manual
Table of Contents
FCC COMPLIANCE STATEMENT……………………………….. 4 WARNINGS AND PRECAUTIONS ……………………………… 4 WARRANTY …………………………………………………………. 6
STANDARD WARRANTY ………………………………………………6 THREE YEAR WARRANTY……………………………………………..6 DISPOSAL ……………………………………………………………. 7 1. INTRODUCTION ………………………………………………… 8 FEATURES ………………………………………………………………8 2. SYSTEM DIAGRAM…………………………………………….. 9 3. CONNECTIONS………………………………………………… 10 REAR PANEL………………………………………………………….10 FRONT PANEL………………………………………………………..11 4. RS-422 PINOUT……………………………………………….. 14 5. DIMENSIONS ………………………………………………….. 15 6. SPECIFICATIONS ……………………………………………… 15 CABLE SELECTION……………………………………………………16 SERVICE AND SUPPORT ……………………………………….. 20
2
Disclaimer of Product & Services The information offered in this instruction manual is intended as a guide only. At all times, Datavideo Technologies will try to give correct, complete and suitable information. However, Datavideo Technologies cannot exclude that some information in this manual, from time to time, may not be correct or may be incomplete. This manual may contain typing errors, omissions or incorrect information. Datavideo Technologies always recommend that you double check the information in this document for accuracy before making any purchase decision or using the product. Datavideo Technologies is not responsible for any omissions or errors, or for any subsequent loss or damage caused by using the information contained within this manual. Further advice on the content of this manual or on the product can be obtained by contacting your local Datavideo Office or dealer.
3
FCC Compliance Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any interference received, including
interference that may cause undesired operation.
Warnings and Precautions
1. Read all of these warnings and save them for later reference. 2. Follow all warnings and instructions marked on this unit. 3. Unplug this unit from the wall outlet before cleaning. Do not use
liquid or aerosol cleaners. Use a damp cloth for cleaning. 4. Do not use this unit in or near water. 5. Do not place this unit on an unstable cart, stand, or table. The unit
may fall, causing serious damage. 6. Slots and openings on the cabinet top, back, and bottom are
provided for ventilation. To ensure safe and reliable operation of this unit, and to protect it from overheating, do not block or cover these openings. Do not place this unit on a bed, sofa, rug, or similar surface, as the ventilation openings on the bottom of the cabinet will be blocked. This unit should never be placed near or over a heat register or radiator. This unit should not be placed in a built-in installation unless proper ventilation is provided. 7. This product should only be operated from the type of power source indicated on the marking label of the AC adapter. If you are not sure of the type of power available, consult your Datavideo dealer or your local power company. 8. Do not allow anything to rest on the power cord. Do not locate this unit where the power cord will be walked on, rolled over, or otherwise stressed. 9. If an extension cord must be used with this unit, make sure that the total of the ampere ratings on the products plugged into the extension cord do not exceed the extension cord rating.
4
10. Make sure that the total amperes of all the units that are plugged into a single wall outlet do not exceed 15 amperes.
11. Never push objects of any kind into this unit through the cabinet ventilation slots, as they may touch dangerous voltage points or short out parts that could result in risk of fire or electric shock. Never spill liquid of any kind onto or into this unit.
12. Except as specifically explained elsewhere in this manual, do not attempt to service this product yourself. Opening or removing covers that are marked “Do Not Remove” may expose you to dangerous voltage points or other risks, and will void your warranty. Refer all service issues to qualified service personnel.
13. Unplug this product from the wall outlet and refer to qualified service personnel under the following conditions: a. When the power cord is damaged or frayed; b. When liquid has spilled into the unit; c. When the product has been exposed to rain or water; d. When the product does not operate normally under normal operating conditions. Adjust only those controls that are covered by the operating instructions in this manual; improper adjustment of other controls may result in damage to the unit and may often require extensive work by a qualified technician to restore the unit to normal operation; e. When the product has been dropped or the cabinet has been damaged; f. When the product exhibits a distinct change in performance, indicating a need for service.
5
Warranty
Standard Warranty
Datavideo equipment are guaranteed against any manufacturing defects for one year from the date of purchase.
The original purchase invoice or other documentary evidence should be supplied at the time of any request for repair under warranty.
The product warranty period begins on the purchase date. If the purchase date is unknown, the product warranty period begins on the thirtieth day after shipment from a Datavideo office.
All non-Datavideo manufactured products (product without Datavideo logo) have only one year warranty from the date of purchase.
Damage caused by accident, misuse, unauthorized repairs, sand, grit or water is not covered under warranty.
Viruses and malware infections on the computer systems are not covered under warranty.
Any errors that are caused by unauthorized third-party software installations, which are not required by our computer systems, are not covered under warranty.
All mail or transportation costs including insurance are at the expense of the owner.
All other claims of any nature are not covered. All accessories including headphones, cables, and batteries are
not covered under warranty. Warranty only valid in the country or region of purchase. Your statutory rights are not affected.
Three Year Warranty
All Datavideo products purchased after July 1st, 2017 are qualified for a free two years extension to the standard warranty, providing the product is registered with
6
Datavideo within 30 days of purchase. Certain parts with limited lifetime expectancy such as LCD panels,
DVD drives, Hard Drive, Solid State Drive, SD Card, USB Thumb Drive, Lighting, Camera module, PCIe Card are covered for 1 year. The three-year warranty must be registered on Datavideo’s official website or with your local Datavideo office or one of its authorized distributors within 30 days of purchase.
Disposal
For EU Customers only – WEEE Marking This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment. For more information about where you can drop off your waste equipment for recycling, please contact your local city office, your household waste disposal service or the shop where you purchased the product.
CE Marking is the symbol as shown on the left of this page. The letters “CE” are the abbreviation of French phrase “Conformité Européene” which literally means “European Conformity”. The term initially used was “EC Mark” and it was officially replaced by “CE Marking” in the Directive 93/68/EEC in 1993. “CE Marking” is now used in all EU official documents.
7
1. Introduction
The HBT-10 and HBT-11 are respectively the HDBaseT transmitter and receiver with a maximum allowable transmission distance of 120 meters. The transmitter allows transmission of up to 4K image quality video.
With the 48V power connected to one end of the HBT-11 HDBaseT receiver, the HBT-11 will thus be able to power the transmitter by Power over Ethernet (PoE). On the transmitter end (HBT-10), there is also a 12V/30W DC output serving to supply power to backend devices.
HDBaseT connection between the transmitter and the receiver can be established on a single Ethernet cable. In other words, HDMI video, DVIP control commands and power (PoE) can be transmitted between the transmitter and the receiver on just one cable.
Features
Transmit up to 4Kx2K video from HBT-10 Transmitter Box to HBT11 Receiver Box.
Extend video transmission up to 120m from HBT-10 Transmitter Box to HBT-11 Receiver Box.
Transmit video, audio, DVIP Ethernet control, RS-422/232 and PoE by a single Cat.5e/6/6a/7 cable
48V PoE Power supply from HBT-11 Receiver side. 12V 30W DC output at HBT-10 Transmitter Box side. Supports DVIP Control Protocol Supports RS-422/232 Control Protocol
8
2. System Diagram
9
3. Connections
Rear Panel
HDMI OUT HDMI port for video output.
DVIP Port Connects to Ethernet switch or router, serving as a communication port between the network and the HBT-11 receiver. 48V DC IN 48V DC power input connection
10
Power LED Indicator ON: Power connected OFF: Power disconnected
Front Panel
HDBaseT Port Connects between HBT-10 transmitter and HBT11 receiver using any standard Ethernet cable.
11
RS-232/RS-422 Interface (Phoenix Terminal) Connects to external RS-232/RS-422 device. RX: Receiver PIN (differential pair if using RS-422 connection) TX: Transmitter PIN (differential pair if using RS422 connection) G: Ground PIN
Note: See RS-422 pinout section for more information about RS-422 cabling.
DIP Switch The receiver box allows long distance connectivity to HBT-10 of up to 120 meters while compromising on maximum supported resolution of up to 1080p. Select 4K mode (2160p) if the connection distance is less than 70 meters. If your system is not required to support resolutions higher than 1080p, you can activate long reach mode and enjoy longer cable reach of up to 120 meters.
The DIP Switch is used to select from the available connection modes listed as follows:
00: 4K Mode RS-232 01: 4K Mode RS-422 10: Long Reach RS-232 11: Long Reach RS-422
Note: See the Cable Selection section for cable recommendations.
12
In addition to HBT-10, you can also receive video from HBT-5. The table below provides information about the available connection modes for receiving video from HBT-5 and HBT-10.
HBT-6
4K mode ONLY (60m@1080p60 or 35m@4K2K30)
Receiver End
HBT-11
4K mode ONLY (35m@4K2K30)
HBT- 5
Transmitter End
HBT-10
4K mode ONLY (60m@1080p60 or 35m@4K2K30)
Long reach mode (120m@1080p60)
4K mode (100m@1080p60 or 70m@4K2K30)
13
4. RS-422 Pinout
To use the RMC-180 PTZ Camera Control Unit to control the PTZ-150 camera behind the HBT-11 Receiver box, please connect the RMC-180 to the HBT-11 using the RS-422 wiring scheme as shown below.
HBT-11 Receiver Box
GND GND 3 White/Orange
RX- 1 White/Green TX- 5 Blue TX+ 4 White/Blue RX+ 2 Green
RMC-180 Controller
White/Orange 1 GND Orange 2 NC
White Green 3 TXBlue 4 RX-
White Blue 5 RX+ Green 6 TX+
White/Brown 7 NC Brown 8 NC
14
5. Dimensions
All measurements in millimeters (mm)
6. Specifications
Video / Audio
Input Output
Supported Resolutions
HDMI x 1
HDBaseT RJ-45 x 1 2160p 30/29.97/25 1080p 60/59.94/50/30/29.97/25 1080i 60/59.94/50 720p 60/59.94/50 720p 50/59.94/60
Control
DVIP Ethernet
RJ-45 x 1
RS-422 / RS-232
Phoenix Terminal Pitch 3.50 mm
Power
DC IN
DC 48 V
Dimensions
L x W x H
131.8 x 85 x 45.2 mm
Physical and Operating Environments
Operating Temperature
0 40 °C
15
Operating Relative Humidity
Operating Mode
HDBaseT Transmission Distance
10% 80%
4K Mode / Long Reach Mode
1080p60 Up to 120M by Cat. 6 Cable; 2160p30 Up to 70M by Cat. 6 Cable
Cable Selection
Video Resolutions (HBT-10/HBT-11 Pair ONLY)
Cable CAT5e/6
Range 120 meters 70 meters
Video Resolution
Up to 1080p, 60Hz, 36 bpp.
Data rates lower than 5.3 Gbps or below 255 MHz TMDS clock. Ultra HD video formats: HDMI Deep color: 1080p, 60, 48 bpp.
CAT6a/CAT7 120 meters(*)
4K x 2K
Data rates higher than 5.3 Gbps or above 255 MHz TMDS clock.
* Recommended Cables for Ultra-HD video at 120 Meter range
Type CAT7 S/FTP CAT6A H-STP CAT.7
P/N
Manufacturer
FR-LSZH Teldor
HFFR
Teldor
2170475 Earthline
Web http://www.teldor.com/
http://www.teldor.com/
http://products.lappgroup.com/onl ine-catalogue/datacommunicationsystems-for-ethernet-technology/
16
Notes
17
Notes
18
Notes
19
www.datavideo.com/product/HBT-11
Datavideo Technologies Co., Ltd. All rights reserved 2020
Apr-28.2021 Ver: E4
