ProxiSwitch v2 Proximity Touch Controller
Product Information: ProxiSwitch V2
The ProxiSwitch V2 is an invisible switch that allows for
touchless control of electric devices. It operates on a voltage
range of 12-24V and is designed to be safe and easy to use.
Safety Rules:
- Do not connect the device to loads exceeding the permitted
values. - Connect only in accordance with the diagram presented in the
manual to avoid dangerous connections that can damage the
controller and void the warranty. - Always perform assembly work with the power circuit
disconnected to minimize the risk of electric shock. - Ensure that the power mains meet the quality requirements
defined by EN 50081-1, EN 50082-1, UL508, EN 60950 to maintain the
warranty.
Installation – Basics:
- Disconnect the supply voltage circuit before installing the
controller. Make sure the main voltage is disconnected by switching
off the mains fuse or disconnecting the power supply from the
socket. - Install the controller in a place protected against adverse
environmental conditions and third-party access. It is recommended
to mount the device in a stable and fixed position. - Familiarize yourself with the diagram provided in the manual
and connect the power wires (+) (red or black with a white dotted
line) and (-) (black) first. Pay attention to the designation of
the controller connectors. - Connect the LED strip, ensuring correct polarity. The device
comes with double-sided adhesive tape on the bottom side for
mounting. Clean and dry the surface where it will be adhered,
remove the protective film, adhere it in the chosen place, and hold
for a few seconds. Remember that the device detects the hand only
from the side of the adhesive tape. - Adhere the device to a non-conductive surface such as furniture
board or tile. Avoid mounting near metal elements as it may affect
the device’s functionality. - During the first 15 seconds after connecting the power source,
the device performs an autocalibration process. Do not place your
hand or any conductive objects near the device during this time to
ensure accurate calibration. - If the device reacts incorrectly during normal operation, force
the auto-calibration process by disconnecting and reconnecting the
power supply to the controller. Avoid placing your hand near the
controller for the first 15 seconds after reconnecting the power
supply.
Connection Diagrams:
General diagram of connection to the 12-24V DC device:
General scheme of connection to the LED strip 12-24V DC:
Touch button – ProxiSwitch V2 + SwitchBoxDC:
Touch button – ProxiSwitch V2 + wLightBoxS V2:
Control:
To turn on/off the LED strip, simply close your hand to the
controller. The device operates in four operating modes:
- Bistable without memory: After switching on the power supply,
the output is initially switched off. Each time you close your
hand, the output changes. When the power supply is disconnected and
reconnected, the output will always be off.
proxiswitch v2
user manual
“INVISIBLE” SWITCH – ELECTRIC DEVICES TOUCHLESS CONTROL (12-24V)
SAFETY RULES
Do not connect the device to loads exceeding the permitted values.
Connect only in accordance with the diagram presented in the manual. Improper connections may be dangerous, it can damage the controller, and loss of the warranty.
DANGER! Risk of electric shock! Even with the device turned off, the outputs may be live. All assembly work should be ALWAYS performed with the disconnected power circuit.
The installation of the device to a power mains that does not meet the quality requirements defined by EN 50081-1, EN 50082-1, UL508, EN 60950, will result in the loss of the warranty.
1
INSTALLATION – BASICS
Disconnect supply voltage circuit before installing the controller. Remember that any mounting works should be carried out when the main voltage is disconnected (switch off the mains fuse or disconnect the power supply from the socket).
The controller should be installed in a place protected against adverse environmental conditions, protected from third party access. It is recommended that the device be mounted in a stable and fixed position.
Familiarize yourself with the diagram and then proceed with the installation of the controller. Pay special attention to the designation of the controller connectors. Start by connecting the power wires: (+) (red or black with a white dotted line) and (-) (black).
Connect the LED strip (paying attention to the polarity). The device is equipped with two stripes of double-sided adhesive tape on the bottom side. Before sticking the controller, clean and dry the the surface where it will be adhered. Remove the protective film, adhere in the chosen place and hold for a few seconds. When choosing the mounting location, remember that the device detects the hand only from the side of the adhesive tape.
The device should be adhered to a non-conductive surface, eg furniture board, tile, etc. If the device is not stably fixed or mounted near metal elements, it may not work properly.
Each time the power source is connected, the device performs the autocalibration process within the first 15 seconds. During this time, do not place your hand or any conductive objects near the device, as this will affect the calibration process.
If during the normal operation the device reacts incorrectly, force the auto-calibration process by disconnecting and reconnecting the power supply to the controller. Remember that after connecting the power supply do not put your hand near the controller for the first 15 seconds!
CONNECTION DIAGRAMS
General diagram of connection to the 12-24V DC device:
General scheme of connection to the LED strip 12-24V DC:
Touch button – proxiSwitch v2 + switchBoxDC:
DEVICE 12-24V DC
Touch button – proxiSwitch v2 + wLightBoxS v2:
LED STRIP
2
CONTROL
To turn on / off the LED strip, close your hand to the controller.
The device can operate in four operating modes:
1. bistable without memory – after switching on the power supply, the output is switched off, each time you close your hand, the output changes. When the power supply is disconnected and reconnected, the output will always be off.
2. bistable with memory – after switching on the power supply, the output state depends on the state before the power loss (the last state is remembered 5 seconds after its last change). Each time you close your hand, the output state changes.
3. monostable NO – after turning on the power, the output is in off state. It turns on when you close your hand.
4. monostable NC – when the power is turned on, the output is also on. It turns off when you close your hand.
To change the operating mode of the device, follow the steps below:
1. turn on the power, wait 5 seconds until the LED starts flashing; immediately disconnect the power.
2. turn on the power, wait 10 seconds until the LED starts flashing; immediately disconnect the power.
3. turn on the power, wait 15 seconds until the LED starts flashing; immediately disconnect the power.
4. turn on the power. Select the mode by placing your hand close the controller. Each time you close your hand, the number of LED flashes indicates the selected mode.
5. wait 10 seconds after the last movement until the LED starts flashing; immediately disconnect the power.
6. after reconnecting the power supply, the device start to work in the newly selected mode.
TECHNICAL SPECIFICATIONS
supply voltage
1224V DC
energy consumption
<0,1W
maximum current maximum power
5A 120W
status signaling
blue diagnostic LED
modes detection range
bistable, bistable with state memory, monostable NO, monostable NC
depending on the material: plexiglass, solid wood, plywood, chipboard – 3cm,
metal – detection with the entire surface,
honeycomb panels – no detection
maximum detection time in monostable mode
8 sec
autocalibration
at startup and every 15 seconds
sensor
proximity, capacitive sensor
supply voltage mounting method housing
1224V DC
under the surface of nonconductive, adhesive tape
made of polyurethane composition not containing halogens, self-extinguishing
for thermal class B (130 °C)
dimensions
38 x 38 x 19 mm
protection level controller operating temperature
IP20 from -20 to + 50°C
ADDITIONAL INFORMATION
HELP
The latest versions of the manual, additional informations and materials about products are available on our website: blebox.eu General questions: [email protected] Service and technical support: [email protected]
for more information visit our website
www.blebox.eu
or send us an email to: [email protected] support is available at [email protected]
made in Europe
