TITANAXS-1616CS Titan AXS Mid-Wheel Drive Powerchair
Titan AXS Mid-Wheel Drive Powerchair
Product Information:
| Product Code | Description |
|---|---|
| TITANAXS-1616CS | K0823, 1/ea |
| TITANAXS-1618CS | K0823, 1/ea |
| TITANAXS-1816CS | K0823, 1/ea |
| TITANAXS-18CS | K0823, 1/ea |
| TITANAXS-20CS | K0823, 1/ea |
| TITANAXS-2020CS | K0823, 1/ea |
| TITANAXS-22CS | K0823, 1/ea |
Product Specifications:
| Weight Capacity | Top Speed | Estimated Range | Max. Climbing Angle | Turning Radius | Ground Clearance | Overall Dimensions | Seat Dimensions | Depth | Back Height | Seat-to-Floor Height | Motor Controller | Batteries | Battery Charger | Brakes | Freewheel Mode |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| K0823, 1/ea | K0823, 1/ea | K0823, 1/ea | K0823, 1/ea | K0823, 1/ea | K0823, 1/ea | K0823, 1/ea | K0823, 1/ea | K0823, 1/ea | K0823, 1/ea | K0823, 1/ea | K0823, 1/ea | K0823, 1/ea | K0823, 1/ea | K0823, 1/ea | K0823, 1/ea |
Accessories:
| Description |
|---|
| Flat Free 6 x 2 |
| 10 x 3 |
| 87 lbs. |
| 44 lbs. |
| 40 lbs. |
| 171 lbs. |
| Limited Lifetime |
| 24 Months |
| 12 Months |
Accessory Descriptions:
| Description |
|---|
| ELR Bracket, 1/ea |
| ELR Set, 1/pr |
| Swing-Away Joystick, 1/ea |
| Oxygen Tank Holder, 1/ea |
| Cane/Crutch Holder, 1/ea |
| 18 Seat Cover, 1/ea |
| 20 Seat Cover, 1/ea |
| 22 Seat Cover, 1/ea |
For any further assistance, please contact our Customer Service
at 800.371.2266.
Revision: 20180531
Titan AXS Mid-Wheel Drive Powerchair
INSET A
INSET B
INSET C
INSET D
INSET E
INSET F
· Captain’s seat, available in 7 different width and depth combinations, is height adjustable, reclines, swivels in 45° increments, and has a height adjustable headrest
· Padded, contoured armrests with height, width and angle adjustment · Adjustable length controller mount · Interchangeable color panels in red and blue included · Flip-up footplate with height, depth and angle adjustment · Positioning belt included · Programmable controller with Bluetooth electronics for easy trouble-shooting and service · Flat-free, non-marking tires · Easy freewheel operation
PRODUCTS TITANAXS-1616CS TITANAXS-1618CS TITANAXS-1816CS TITANAXS-18CS TITANAXS-20CS TITANAXS-2020CS TITANAXS-22CS
Description K0823, 1/ea K0823, 1/ea K0823, 1/ea K0823, 1/ea K0823, 1/ea K0823, 1/ea K0823, 1/ea
SPECIFICATIONS Weight Capacity Top Speed Estimated Range Max. Climbing Angle Turning Radius Ground Clearance Overall Dimensions Seat Dimensions Depth Back Height Seat-to-Floor Height Motor Controller Batteries Battery Charger Brakes Freewheel Mode
Description 300 lbs. 4 mph 19 miles 6° 20″ 2.5″ 39.25″ (L) x 23.5″ (W) x 44″ (H) 16″ | 18″ | 20″ | 22″ 16″ | 18″ | 20″ 18″ 20.75″ 21.75″ 320W x 4600RPM Dynamic Linx 40A 12V x 33AH 4A Electromagnetic Yes
Customer Service | 800.371.2266
Rev: 20180531
SPECIFICATIONS Tires Caster Wheels Drive Wheels Base Weight Battery Weight (Pair) Seat Weight Total Weight Warranty on Frame Warranty on Electronics Warranty on Batteries
ACCESSORIES AE2500 LK3JELR AA4100 SF8010 SF8030 ST205-COVER ST301-COVER ST306-COVER
Description Flat Free 6″ x 2″ 10″ x 3″ 87 lbs. 44 lbs. 40 lbs. 171 lbs. Limited Lifetime 24 Months 12 Months
Description ELR Bracket, 1/ea ELR Set, 1/pr Swing-Away Joystick, 1/ea Oxygen Tank Holder, 1/ea Cane/Crutch Holder, 1/ea 18″ Seat Cover, 1/ea 20″ Seat Cover, 1/ea 22″ Seat Cover, 1/ea
Customer Service | 800.371.2266
Rev: 20180531
