Stream1955: Product Information and Usage Instructions

Product Information

The Stream1955 is a next-generation System-On-Module that
enables a breakthrough for connected Smart Soundbars with Dolby
Atmos / Sony 360 / DTS:X. It is a compact module (34 x 47mm) that
provides online connectivity, 3D audio (Dolby Atmos…) and voice
assistant capability in one single unit. This module is suitable
for a range of applications, including:

Smart Dolby ATMOS / DTS:X Soundbars
Connected audio products with or without voice assistant,
high-quality display, 3D audio…
High-end audio products
Enhance any product by adding connectivity and voice
assistance

The Stream1955 features a Quad Core ARM A53 1.6 Ghz NXP iMX8M
mini/nano processor, the latest SoC platforms with ample processing
power and a multitude of signal interfaces (multi-channel I2S I/O,
MIPI, etc.), WiFi 802.11ax (WiFi 6) 2 x 2 MIMO / BT 5.0, eMMC and
DDR4 memory, RAM 8Gb / Flash 16 Gb (pSLC), and state-of-the-art
wireless link robustness. It also has 3D Audio decoding in SoC – no
DSPs required, and all major voice assistants can be realized
without extra DSP. The StreamSDK software is optimized to run
proven and feature-rich, and the module and StreamSDK take care of
the most complex parts of a connected device and therefore de-risk
the product creation process.

Usage Instructions

The Stream1955 can be used to add online connectivity, 3D audio,
and voice assistant capability to a range of audio products. To use
the Stream1955, follow these steps:

Integrate the Stream1955 module into your audio product.
Connect your audio product to a power source.
Connect your audio product to a wireless network using the WiFi
802.11ax (WiFi 6) 2 x 2 MIMO / BT 5.0.
Configure the StreamSDK software to enable the desired
features, such as 3D audio decoding and voice assistant
capability.
Test your audio product to ensure that it is working
correctly.

For further technical support, please contact StreamUnlimited
Engineering GmbH by phone on +43 1 667 2002 4014 or by email at
[email protected]. You can also visit the StreamUnlimited
website at www.StreamUnlimited.com.

View Fullscreen

Stream1955
Online connectivity, 3D audio (Dolby Atmos…) and voice assistant capability in one single module

Potential Applications
Smart Dolby ATMOS / DTS:X Soundbars
Connected audio products with or without voice assistant, high-quality display, 3D audio…
High-end audio products
Enhance any product by adding connectivity and voice assistance

Next-generation System-On-Module enables a breakthrough for connected Smart Soundbars with Dolby Atmos / Sony 360 / DTS:X
Key Points 3D Audio decoding in SoC – no DSPs
required All major voice assistants can be realized
without extra DSP Optimised to run proven and feature-rich
StreamSDK Software Module and StreamSDK take care of the
most complex parts of a connected device and therefore de-risk the product creation process Compact size (34 x 47mm) Low power

Features Quad Core ARM A53 1.6 Ghz NXP iMX8M
mini/nano Latest SoC platforms with ample processing
power and a multitude of signal interfaces (multi-channel I2S I/O, MIPI, etc.) WiFi 802.11ax (WiFi 6) 2 x 2 MIMO / BT 5.0 State-of-the-art wireless link robustness eMMC and DDR4 memory RAM 8Gb / Flash 16 Gb (pSLC). Plenty of storage space even for demanding applications
Schedule In mass production

StreamUnlimited, founded in 2005, is a supplier of software solutions and hardware modules for connected audio and IoT products, with over 120 employees at office locations in Vienna, Bratislava, Iasi, Shenzhen, Japan and Santa Clara, CA. As the de facto global system integrator offering its own IP and engineering services, StreamUnlimited development partnerships include all major semiconductor companies and technology providers in the consumer electronics and IoT channel. StreamUnlimited works with a global cross-section of high-end audio, CEDIA-channel, premium and mainstream consumer electronics and smart home manufacturers.

StreamUnlimited Engineering GmbH Gutheil-Schoder-Gasse 10, 1100 Vienna, Austria Phone: +43 1 667 2002 4014 E-mail: [email protected] Website: www.StreamUnlimited.com
