PRM16 Series 16 mm Motorized Potentiometer
Product Information
The PRM16 Series is a 16 mm Motorized Potentiometer that is RoHS
compliant. It features remote controllability and is suitable for
both motorized and manual operation. The potentiometer has a dual
section and offers a smooth manual operating feel. It comes with
various taper options.
The electrical characteristics, environmental characteristics,
mechanical characteristics, and standard resistance table of the
potentiometer can be found in the user manual.
The potentiometer is designed for various applications such as
guitar amplifiers, mixing consoles, amplifiers, CD players, karaoke
volume controls, and servo tracks.
Product dimensions and specifications for ordering are also
provided in the user manual.
Product Usage Instructions
To use the PRM16 Series Motorized Potentiometer, follow these
steps:
- Choose the desired model designator code based on the required
specifications (refer to the “How To Order” section). - Identify the number of sections needed (single or dual
section). - Select the terminal configuration (PIN layout) that suits your
application. - Determine the detent option (detents or no detents).
- Choose the appropriate standard shaft length (15 mm, 20 mm, 25
mm, or 30 mm). - Refer to the resistance taper charts to select the desired
taper series and curve number. - Select the resistance code based on the required resistance
value in ohms.
Once you have determined all the necessary specifications, use
the model designator code to place an order for the PRM16 Series
Motorized Potentiometer.
For any further assistance or clarification, please refer to the
complete user manual or visit the manufacturer’s website.
*RoHS COMPLIANT
Features
Remote controllable Suitable for both motorized and manual
operation Dual section Smooth manual operating feel Various taper options RoHS compliant*
PRM16 Series – 16 mm Motorized Potentiometer
Electrical Characteristics
Taper………………………………………………………………………………………………………………………………………………………………….. Linear, audio Standard Resistance Range…………………………………………………………………………………………………………………….1K ohms to 1 megohm Standard Resistance Tolerance………………………………………………………………………………………………………………………………………..±20 % Power Rating
B3 Taper……………………………………………………………………………………………………………………………………………………………….. 0.1 watt Other Tapers ……………………………………………………………………………………………………………………………………………………….. 0.05 watt Maximum Operating Voltage ………………………………………………………………………………………………………………………………………… 150 Vac Attenuation R100K ohms …………………………………………………………………………………………………………………………………………………..100 dB min. 100K ohms>R50K ohms …………………………………………………………………………………………………………………………………….90 dB min. 50K ohms>R10K ohms ………………………………………………………………………………………………………………………………………80 dB min. 10K ohms>R5K ohms ………………………………………………………………………………………………………………………………………..70 dB min. 5K ohms>R1K ohms ………………………………………………………………………………………………………………………………………….60 dB min. 1K ohms>R500 ohms ………………………………………………………………………………………………………………………………………..50 dB min. Voltage Proof ………………………………………………………………………………………………………………………………………….. 500 VDC for 1 minute Motor Voltage …………………………………………………………………………………………………………………………………………………………… 4.5 VDC Motor Current (@ 4.5 VDC)…………………………………………………………………………………………………………………………………… 100 mA max.
Environmental Characteristics
Operating Temperature Range …………………………………………………………………………………………………………………………..-10 °C to +70 °C Sliding Noise………………………………………………………………………………………………………………………………………………………….47 mV max.
Mechanical Characteristics
Mechanical Angle …………………………………………………………………………………………………………………………………………………….. 300 ° ±5 ° Rotational Speed ………………………………………………………………………………………………………………………………………………..12 ±3 seconds Rotational Torque ……………………………………………………………………………………………………………………………………………. 150 to 450 g-cm Stop Strength……………………………………………………………………………………………………………………………………………………… 9 kg-cm max. Push-pull Strength ……………………………………………………………………………………………………………………………..10 kg max. for 10 seconds Rotational Life…………………………………………………………………………………………………………………………………………………….. 15,000 cycles Soldering Condition ………………………………………………………………………………………..260 °C within 5 seconds or 300 °C within 3 seconds Hardware …………………………………………………………………….. One flat washer and mounting nut supplied per potentiometer with bushing
Standard Resistance Table
Resistance (Ohms)
1,000 2,000 5,000 10,000 20,000 50,000 100,000 200,000 500,000 1,000,000
Resistance Code
102 202 502 103 203 503 104 204 504 105
Asia-Pacific: Tel: +886-2 2562-4117 · Email: [email protected] EMEA: Tel: +36 88 885 877 · Email: [email protected] The Americas: Tel: +1-951 781-5500 · Email: [email protected] www.bourns.com
WARNING Cancer and Reproductive Harm www.P65Warnings.ca.gov
*RoHS Directive 2015/863, Mar 31, 2015 and Annex. Specifications are subject to change without notice. Users should verify actual device performance in their specific applications. The products described herein and this document are subject to specific disclaimers as set forth on the last page of this document, and at www.bourns.com/legal/disclaimer.pdf.
Downloaded from Arrow.com.
Applications
Guitar amplifiers Mixing consoles Amplifiers, CD players, karaoke volume controls Servo tracks
PRM16 Series – 16 mm Motorized Potentiometer
Product Dimensions
Knurled, 18 Tooth Shaft
1.0
DIA.(.263.06)
(.039)
48.35
(1.904)
11.6
A 12.0
(.457)
(.472)
18.1 (.713)
15.1
4.0
(.594) (.157)
3.55
1.0
DIA. 24.4
(.961)
(.140)
(.039) 1.0
(.039) 7.0
(.276)
KNURL 18
TEETH
1.9 (.075)
R2 R1
2.0 (0.79)
18.2 (.717)
0.3 (.012)
3.25 (.128)
6.4 (.252)
DIA.
12.0 (.472) 7.5 ± 0.2 (.295 ± .008) 0.3 (.012) 1.5 (.059)
3.0 +0/-0.1 (.118 +0/-.004)
1.4 (.055)
22.7 (.894) 17.0 (.669)
B
C1
M7
X
0.75 (.030)
A
15.0 (.591)
B
7.0 (.276)
20.0 11.0 (.787) (.433)
25.0 14.0 (.984) (.551)
30.0 14.0 (1.181) (.551)
16.0 (.630)
Slotted Shaft
15.0 (.591)
5.0 (.197)
2.0 (0.79)
60 ° 0.3
(.012) 1.5
(.059)
1.6 ± 0.2 (.063 + .008)
1.0 (.039)
6.0 ± 0.1 (.236 ± .004)
DIA.
0.5 (.020)
M7
X
0.75 (.030)
12.0 (.472)
7.5 ± 0.2 (.295 ± .008)
22.7 (.894) 17.0 (.669)
16.0 (.630)
3.0 +0/-0.1
(.118 +0/-.004)
123
1.0 ± 0.15
(.039 ± .006)
4.0 (.157)
12.5 (.492)
DIMENSIONS:
MM (IN)
TOLERANCES UNLESS OTHERWISE NOTED:
< 10.0 = ±0.3 (.394) (±.012)
> 10.0 = ±0.5 (.394) (±.020)
Shaft Length
15.0 (.591)
20 (.787)
25 (.984)
30 (1.181)
Shaft Wobble
0.23 (.009)
0.35 (.014)
0.47 (.019)
0.58 (.023)
123 1.0 ± 0.15 (.039 ± .006)
11.5 (.453)
5.0 (.197)
16.8 (.661)
4.0 (.157)
12.5 (.492)
3.8 (.150)
MOUNTING SURFACE
5.0 (.197)
5.0 (.197)
7.0 (.276)
DIA. 1.2 + 0.2/-0
(.047 + .008/-0)
6 PLCS.
(.21.062)X
1.2 (.047
+ +
.00.028/-/0-0)2
PLCS.
Specifications are subject to change without notice. Users should verify actual device performance in their specific applications. The products described herein and this document are subject to specific legal disclaimers as set forth on the last page of this document, and at www.bourns.com/docs/legal/disclaimer.pdf.
Downloaded from Arrow.com.
PRM16 Series – 16 mm Motorized Potentiometer
How To Order
P RM 1 6 2 – K 4 1 5 K – 1 0 3 B 3
MODEL DESIGNATOR Code Description PRM16 16 mm Motorized Potentiometer
NUMBER OF SECTIONS Code Description
2 Dual Section
TERMINAL CONFIG. (PIN LAYOUT) Code Description
K PC Pins Vertical/Down Facing
DETENT OPTION Code Description
4 No Detents
STANDARD SHAFT LENGTH Code Description
15 15 mm 20 20 mm 25 25 mm 30 30 mm
RESISTANCE TAPER (SEE TAPER CHARTS) Taper Series followed
by Curve Number
RESISTANCE CODE Code Value in Ohms 102 1,000 202 2,000 502 5,000 103 10,000 203 20,000 503 50,000 104 100,000 204 200,000 504 500,000 105 1,000,000
Code K S
SHAFT STYLE Description Knurled (18 Tooth Serrated) Slotted
X 100 (%)
Output Voltage across Terminals 1-2 Input Voltage across Terminals 1-3
Tapers
A Series Tapers 100
90
80
70
60
50
40 30 20 10
0 10 20 Terminal 1
(30A);A6(25A);A5
(20A);(A145A);A3
(10A);A2
(05A);A1
30 40 50 60 70
Rotational Travel (%)
80 90 100 Terminal 3
Output Voltage across Terminals 1-2 Input Voltage across Terminals 1-3
X 100 (%)
(3B);B3 (4B);B4 (1B);B1 (2B);B2
B Series Tapers 100
(5B);B5 90 80 70
60 50 40
30 20 10
0 10 20 Terminal 1
30 40 50 60 70 Rotational Travel (%)
80 90 100 Terminal 3
Output Voltage across Terminals 1-2 Input Voltage across Terminals 1-3
X 100 (%)
C Series Tapers 100
90
80
70
60
50
40 30 20 10
0 10 20 Terminal 1
(25C()3;C0C5);C6
(10C);C2 (05C);C1
(20C);C4 (15C);C3
30 40 50 60 70 Rotational Travel (%)
80 90 100 Terminal 3
REV. 10/19
Specifications are subject to change without notice. Users should verify actual device performance in their specific applications. The products described herein and this document are subject to specific legal disclaimers as set forth on the last page of this document, and at www.bourns.com/docs/legal/disclaimer.pdf.
Downloaded from Arrow.com.
