CK 04711 One Lumen CVC
User Guide
Contents:
1: One-Lumen Catheter:14 Ga.(2.2mmOD)x16cm,Side Holes
1: Spring-Wire Guide:.032″(0.81mm) dia.x17-3/4″(45cm) (Straight Soft Tip on One End-“J” Tip on Other)
1: Catheter:18 Ga.x2-1/2″(6.35cm)Radiopaque over 20 Ga. RW Introducer Needle
1: Injection Needle:22 Ga.x1-1/2″(3.81cm)
1: Injection Needle:25 Ga.x1″(2.54cm)
1: Introducer Needle:18 Ga.x2-1/2″(6.35cm)TX
1: Blunt Fill Needle:18 Ga.x1-1/2″(3.81cm)2:Syringe: 5m LLuer-Slip
1: Tissue Dilator:7Fr.(2.3mm)x10.2cm1:
1: 5m L1% Lidocaine HCl Solution and Alcohol Prep
1: 3 mL Applicator 2% CH Gand 70% IPA Chlora Prep®1One-Step Solution with Hi-Lite Orange™ Tint
1: Drape: 18″x26″ (46cm x 66cm) with3″ (7.6cm) fenestration
1: Scalpel: #11
1: Dressing: OpSite®2 7cm x 6cm
2: Gauze Pad:2″ x 2″(5cm x 5cm)
4: Gauze Pad:4″ x 4″(10cm x 10cm)
1: Suture: 3-0 Braided Silk with Straight Needle
1A registered trademark of Care Fusion or one of its subsidiaries.
2A registered trademark of T. J. Smith & Nephew, Limited.
Rx only
Warning: Read all package-insert warnings, precautions, and instructions prior to use. Failure to do so may result in severe patient jury or death.CaliforniaProp.65⚠WARNING: Cancer and Reproductive Harm.www.P65Warnings.ca.gov Not made with natural rubber Atex.
Not made with natural rubber latex.
Store between 20 — 25°C (68 — 77°F). Sterilized using ethylene oxide unless otherwise indicated in the contents list. Fluid path components are non-pyrogenic. Arrow International provides the enclosed medication label(s) for your convenience. Please ensure that these labels are applied to the correct syringe and corresponding medication.
 Lumen | Priming Volume* (mL) | Gravity Flow Rate† (mL/hr) |
Distal(14Ga.) 0.31 7678 | ||
*Priming volumes are approximate and are done without accessories.
†Flow rate values are approximate and are determined using deionized water at 100 cm head height.
Arrow Internationa LLC
A subsidiary of Teleflex Incorporated
3015 Carrington Mill Blvd.
Morrisville, NC 27560 USA
WWW.teleflex.com
LBL 052782 R01 (2022-03)
