S5239 Axle Back Exhaust
Product Information
| Product Name | MBRP Performance Exhaust |
|---|---|
| Product Type | Automotive exhaust system |
| Compatibility | Fits most vehicles |
| Features | – Improved power and performance – Enhanced exhaust sound – Easy installation |
Product Usage Instructions
Removal of Stock System:
- Apply penetrating lubricant liberally to all exhaust fasteners,
hangers, and rubber insulators. - Measure 3.75″ from the center of the sway bar towards the rear
of the vehicle and mark both pipes. Verify marks are just in front
of the factory bend, then cut both pipes. The factory front pipe
will need support to prevent it from falling. Refer to Figure 1
& 2. - Remove the factory rear muffler from the rubber
insulators.
Installation of MBRP Performance Exhaust:
- Slide a 2.17″ Clamp onto each pipe, insert the Drivers-Side
Tail Pipe into the factory bezel then onto the cut pipe and lastly
into the factory rubber isolator. Repeat for passenger side. Refer
to Figure 3 & 4.
Congratulations! You are ready to begin experiencing the
improved power, sound, and driving experience of your MBRP
Performance Exhaust. Enjoy your purchase!
Page 2 of 2
Figure 1 Figure 2 Figure 3
Removal of Stock System
1. Apply penetrating lubricant liberally to all exhaust fasteners, hangers, and rubber insulators.
2. Measure 3.75″ from the center of the sway bar towards the rear of the vehicle and mark both pipes. Verify marks are just in front of the factory bend, then cut both pipes. The factory front pipe will need support to prevent it from falling. Refer to Figure 1 & 2.
3. Remove the factory rear muffler from the rubber insulators.
Installation of MBRP Performance Exhaust
1. Slide a 2.17″ Clamp onto each pipe, insert the Drivers-Side Tail Pipe into the factory bezel then onto the cut pipe and lastly into the factory rubber isolator. Repeat for passenger side. Refer to Figure 3 & 4
2. Carefully align the system. Align the edge of each band clamp with the edge of the joint it is connecting. Tighten all hardware and clamps, starting at the front and working rearward to secure the system. Check along the full length of the exhaust system to ensure there is adequate clearance for fuel lines, vent lines, brake lines, frame, bodywork, suspension and any wiring, etc. If there is any interference detected, relocate or adjust to provide adequate clearance. Ensure all clamp connections are secure and components are unable to rotate or slide. Band clamps require approximately 45 lb-ft (60 N-m) of torque. Verify clearances, system security and band clamp torque after 30-60 miles (50-100 km) of driving.
Figure 4
S5239 © 02/22
Congratulations! You are ready to begin experiencing the improved power,
sound and driving experience of your MBRP Performance Exhaust.
We know you will enjoy your purchase!
