V-mark Temp Tag Gen2 Thread Device User Guide

Temp Tag Gen2 Thread Device

Product Information:

The V-Mark Enterprises Ltd. Ext. Temp Tag (Gen2) is a device
that can be controlled by NFC NDEF messages. It has been tested to
work with Thread Mesh network and can support the external probe.
The device has a 6 pin connector for the most of I2C sensors and
comes with an LED. The NFC Coil Antenna is around the LED cover.
The device comes in a deep sleep state to extend battery life and
should join a network to be able to interact with other devices via
Thread commands.

Working Parameters:

  • Work Frequency:
  • TX Power:
  • Battery:
  • Measuring Range:
  • Battery Life:
  • Operating Temperature:
  • Storage Environment:
  • Size:

Product Usage Instructions:

  1. Take the Temp Tag out of the box.
  2. The device comes in a deep sleep state, so it can only be
    triggered by an NFC reader at this point.
  3. The device should join a network to be able to interact with
    other devices via Thread commands.
  4. The device has one LED for display and can execute different
    actions depending on the NDEF messages.
  5. Refer to the user manual for the corresponding actions for each
    NDEF message.
  6. Ensure that the device is not co-located or operation in
    conjunction with any other antenna or transmitter to maintain
    compliance with FCC’s RF Exposure guidelines.

V-Mark Enterprises Ltd. Add.: 400-601 West Broadway, Vancouver BC, Canada V5Z 4C2 Phone: 604.588.6178, Fax: 604.859.8818, Email: [email protected]
Ext. Temp Tag (Gen2 ) User Guide
Introduction
The Temp Tag described in this user guide is using a Thread device , it has been tested to work with Thread Mesh network. This device can be controlled by NFC NDEF messages. This device can support the external Probe. It is with a 6 pin connector for the most of I2C sensors. In the picture below we can see the Temp Tag with LED. The NFC Coil Antenna is around the LED cover.

Out of the box
The Temp Tag comes in a deep sleep state to extend battery life, at this point it can only be triggered by NFC reader. This device should join a network to be able to interact with other ones via Thread commands.

User interface

The Temp Tag has one LED for display; the device can execute different actions depending on the

NDEF messages. The following table shows the according actions:

NFC NDEF message activate hibernate reset

LED indicator Fast blink 10 times Keep on about 2s Keep on about 2s

Action Network steering / finding Set the device into deep sleep mode
Reset the device

Working Parameter
Parameter Work Frequency
TX Power Battery
Measuring range
Battery Life Operating Temperature Storage Environment
Size

V-Mark Enterprises Ltd. Add.: 400-601 West Broadway, Vancouver BC, Canada V5Z 4C2 Phone: 604.588.6178, Fax: 604.859.8818, Email: [email protected]
Value Thread 2.4GHz and NFC 13.56MHz Max 8dBm ER14250, 3.6V, 1200mAH TMP117 on board: -40~85±0.1-20~55 SHTC3-40~85±0.2-20~55 SHTC30~100%RH ±2%20%RH~80%RH 5 years -40~85 -40~85, Nocondensation 88mm*45mm*19mm

FCC Warnings
Changes or modifications not expressly approved by the party responsible for compliance couldvoid the user’s authority to operate the equipment. This equipment has been tested and found tocomply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. Theselimits are designed to provide reasonable protection against harmful interference in a residentialinstallation. This equipment generates uses and can radiate radio frequency energy and, if notinstalled and used in accordance with the instructions, may cause harmful interference to radiocommunications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,which can be determined by turning the equipment off and on, the user is encouraged to try tocorrect the interference by one or more of the following measures: — Reorient or relocate the receiving antenna. — Increase the separation between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. –Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the followingtwo conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that maycause undesired operation.
NOTE:This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter.
RF Exposure Statement

V-Mark Enterprises Ltd. Add.: 400-601 West Broadway, Vancouver BC, Canada V5Z 4C2 Phone: 604.588.6178, Fax: 604.859.8818, Email: [email protected]
To maintain compliance with FCC’s RF Exposure guidelines, this equipment should beinstalled and operated with minimum distance of 20cm the radiator your body. This deviceand its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter.
