Smart Lock Pro + Connect
August Smart Lock Pro
The August Smart Lock Pro is a smart lock that allows you to
lock and unlock your door using your smartphone or voice assistant.
It comes with a mounting plate, adapters, and an adhesive strip for
installation. Before starting, it is recommended to confirm the
compatibility of your deadbolt at august.com/compatibility.
What’s Inside the Box
- August Smart Lock Pro
- Mounting Plate
- 3 Adapters
What You Need
- Phillips Screwdriver
- Adhesive Strip
Product Usage Instructions
- Prepare your existing deadbolt by using the supplied adhesive
strip to hold the keyed side of the lock in place. - Remove your existing thumbturn by unscrewing and removing the
screws from your existing deadbolt thumbturn. If there is an
additional back plate, remove that as well. Be sure to unlock your
deadbolt before removing the thumbturn entirely. - Prepare the mounting plate by removing the screws from the
thumbturn and inserting them into the front of the mounting
plate. - Attach the mounting plate by tightening the screws by hand
until the mounting plate is secured against the door. - Choose your adapter by selecting it from the Compatibility
Chart provided at august.com/compatibility. If your lock brand is
not in the chart, slide each adapter onto the tailpiece to find the
right one. The correct adapter will have the small nub pointing up.
Place the correct adapter onto the tail piece with the small nub
pointing up. - Open the wing latches by pulling out both side wing latches to
prepare for mounting. Slide the August Smart Lock Pro over the
tailpiece and attach it to the mounting plate. Make sure the back
of the lock is flush with the door. To secure the August Smart Lock
Pro, clamp down both side wing latches to the mounting plate
completely. - Remove the faceplate by pressing down on the August logo
located at the bottom of the faceplate. Grab the top of the
faceplate and remove it. - Remove the battery tab while holding the batteries in place.
Make sure that the battery is properly seated in its
compartment. - Replace the faceplate by placing it back onto the August Smart
Lock Pro, with the August logo at the bottom. - Install DoorSenseTM by following the instructions provided at
http://support.august.com/customer/portal/articles/2875699.
DoorSenseTM enables your lock to know when the door is open and
closed. - Use the August Home app to complete setup by downloading and
installing it from http://august.com/app. Select Get Started from
the home screen, or, if already logged in to the app, select Set Up
a Lock from the main menu.
If you need any help or have any questions, call 844-AUGUST1
(284-8781) or visit august.com/support for answers.
August Smart Lock Pro
Installation Guide
Inside the Box
August Smart Lock Pro
Mounting Plate
3 Adapters
What you need
Phillips Screwdriver
Adhesive Strip
!
Before starting, we recommend confirming your deadbolt at august.com/compatibility
1
1. Prepare your existing deadbolt
Use the supplied adhesive strip to hold the keyed side of the lock in place.
2. Remove your existing thumbturn
Unscrew and remove the screws from your existing deadbolt thumbturn. If there is an additional back plate, remove that as well. Be sure to unlock your deadbolt before removing the thumbturn entirely.
2
3. Prepare the mounting plate
The included mounting plate has two adjustable screw-holes that can be repositioned as needed. Remove the screws from the thumbturn and insert them into the front of the mounting plate.
4. Attach the mounting plate
Tighten the screws by hand until the mounting plate is secured against the door.
3
5. Choose your adapter
Select your adapter from the Compatibility Chart above. If your lock brand is not in the chart, slide each adapter onto the tailpiece to find the right one. The correct adapter will have the small nub pointing up. NOTE: The adapters can be placed in the mounting plate backwards. So if the shape is correct, but it seems backwards, try flipping the adapter around.
6. Attach the correct adapter
Place the correct adapter onto the tail piece with the small nub pointing up.
4
7. Open the wing latches
Pull out both side wing latches to prepare for mounting.
8. Attach the August Smart Lock Pro
Slide the August Smart Lock Pro over the tailpiece and attach it to the mounting plate. Make sure the back of the lock is flush with the door. To secure the August Smart Lock Pro, clamp down both side wing latches to the mounting plate completely.
5
9. Remove the faceplate
Press down on the August logo located at the bottom of the face plate. Grab the top of the faceplate and remove it.
10. Remove the battery tab
While holding the batteries in place, remove the plastic battery isolation tab. Make sure that the battery is properly seated in its compartment.
6
11. Replace the faceplate
Place the faceplate back onto the August Smart Lock Pro, with the August logo at the bottom.
12. Install DoorSenseTM
DoorSenseTM enables your lock to know when the door is open and closed. For instructions on installing DoorSenseTM, please visit the link below:
http://support.august.com/customer/portal/articles/2875699
7
13. Use the August Home app to complete setup
Download and install the August Home app. Select “Get Started” from the home screen, or, if already logged in to the app, select “Set Up a Lock” from the main menu.
http://august.com/app
Help
Call 844-AUGUST1 (284-8781) or visit: august.com/support for answers.
12.17-R1
8
