Aperta Sub XL Subwoofer Isolation

Product Information:

The product mentioned in the user manual is the Aperta Sub and
Aperta Sub XL. These are part of the IsoAcoustics Aperta Series,
which also includes other products like the GAIA Series, OREA
Series, DELOS Series, Premium Isolation Stands, Floating Island,
zaZen Series, and Isolation Platform.

The Aperta Sub is a compact isolation stand with dimensions of
10.5×11.5×1.3 inches (265x290x33mm) and a weight capacity of 80 lbs
(36.3 kg). It comes with 4 Carpet Discs for added stability.

The Aperta Sub XL is a larger version with dimensions of
14.5x16x1.5 inches (368x406x37mm) and a weight capacity of 160 lbs
(72.5 kg). It also includes 4 Carpet Discs.

Product Usage Instructions:

To use the Aperta Sub or Aperta Sub XL, follow these steps:

Identify the appropriate location for your subwoofer or audio
component.
Place the Aperta Sub or Aperta Sub XL on a stable surface in
the desired location.
If using on a carpeted surface, attach the included Carpet
Discs to the bottom of the stand for added stability.
Ensure that the weight of your subwoofer or audio component
does not exceed the weight capacity specified for the respective
stand.
Carefully place your subwoofer or audio component on top of the
Aperta Sub or Aperta Sub XL.
Adjust the position of your subwoofer or audio component as
desired for optimal sound quality.

By using the Aperta Sub or Aperta Sub XL, you can enhance the
sound quality and bass definition of your audio system.

View Fullscreen

1s0 RCOUSTICS®
Sou nd quality by design
Instructions
1) Choose the location where the subwoofer will be positioned. 2) Place the Aperta Sub stand in position with the lsoAcoustics logo facing forward . If the Aperta Sub stand will be positioned on a medium or thick carpet, attach the carpet disks underneath the isolators. The carpet disks provide a strong connection in the carpet and a solid foundation for the Aperta Sub. 3) Gently lower the subwoofer on top of the Aperta Sub stand . The isolator should be positioned directly against the bottom of the subwoofer cabinet. The shape of the Aperta Sub stand allows positioning directly underneath the subwoofer cabinet without interference with the existing subwoofer feet. In some cases the existing feet may need to be removed (if possible) to avoid interference.
1) Choisissez !’emplacement ou le subwoofer sera positionne . 2) Placez l’Aperta Sub en position avec le logo lsoAcoustics vers !’avant. Si l’Aperta Sub est sur un tapis moyen ou epais, fixez les disques de tapis sous les isolateurs. Les disques de tapis permettent une connexion solide dans le tapis pour fournir une base solide et stable pour l’Aperta Sub. 3) lnstallez doucement votre caisson de basse sur le dessus du pied Aperta Sub. L’isolateur doit etre positionne en sens contraire du caisson de basse. La forme du support Aperta Sub permet un positionnement directement sous le caisson de basse sans interference avec les pieds existants. Dans certains cas, les pieds existants peuvent devoir etre retires (si possible) pour eviter les interferences.
Discover greater bass definition Decouvrez une meilleure definition des basses

}lpertasue
Dimensions {WxDxH): 10.5″x11 .5″x1 .3″ (265x290x33mm) Weight Capacity: 80 lbs (36.3 kg)
Includes: 1x Aperta Sub & 4x Carpet Discs
Jlperta SUB XL
Dimensions {WxDxH): 14.5″x16″x1 .5″ (368x406x37mm) Weight Capacity: 160 lbs (72 .5 kg)
Includes: 1x Aperta Sub XL & 4x Carpet Discs
Carpet Disks Included Disques de tapis inclus

1s RCOUSTI®
Sound q u al ity by design

Discover. …

Jlperta Series

GAIA Series

OREA series

DELOS Series

Premium Isolation Stands…

True Spacial Clarity Extraordinary Isolation …

Floating Island …

zaZen Series
Isolation Platform

For bookshelf, desktop and center channel speakers.

For floor standing speakers
