Ness Z-Wave LUX PIR Sensor

SKU: ZA-117001

What is Z-Wave?

Z-Wave is the international wireless protocol for communication in the Smart Home. This
device is suited for use in the region mentioned in the Quickstart section.

Z-Wave ensures a reliable communication by reconfirming every message (two-way
communication) and every mains powered node can act as a repeater for other nodes
(meshed network) in case the receiver is not in direct wireless range of the
transmitter.

This device and every other certified Z-Wave device can be used together with any other
certified Z-Wave device regardless of brand and origin as long as both are suited for the
same frequency range.

If a device supports secure communication it will communicate with other devices
secure as long as this device provides the same or a higher level of security.
Otherwise it will automatically turn into a lower level of security to maintain
backward compatibility.

For more information about Z-Wave technology, devices, white papers etc. please refer
to www.z-wave.info.

Product Description

Built with premium components for better performance, these motion sensors provide instant and reliable performance as part of your security system. Ness is a leading developer of low power, highly reliable wireless solutions, including a wide range of intelligent wireless security, sensing and home automation devices.

Prepare for Installation / Reset

Please read the user manual before installing the product.

In order to include (add) a Z-Wave device to a network it must be in factory default
state. Please make sure to reset the device into factory default. You can do this by
performing an Exclusion operation as described below in the manual. Every Z-Wave
controller is able to perform this operation however it is recommended to use the primary
controller of the previous network to make sure the very device is excluded properly
from this network.

Inclusion/Exclusion

On factory default the device does not belong to any Z-Wave network. The device needs
to be added to an existing wireless network to communicate with the devices of this network.
This process is called Inclusion.

Devices can also be removed from a network. This process is called Exclusion.
Both processes are initiated by the primary controller of the Z-Wave network. This
controller is turned into exclusion respective inclusion mode. Inclusion and Exclusion is
then performed doing a special manual action right on the device.

Quick trouble shooting

Here are a few hints for network installation if things dont work as expected.

1. Make sure a device is in factory reset state before including. In doubt exclude before include.
2. If inclusion still fails, check if both devices use the same frequency.
3. Remove all dead devices from associations. Otherwise you will see severe delays.
4. Never use sleeping battery devices without a central controller.
5. Dont poll FLIRS devices.
6. Make sure to have enough mains powered device to benefit from the meshing

Association – one device controls an other device

Z-Wave devices control other Z-Wave devices. The relationship between one device
controlling another device is called association. In order to control a different
device, the controlling device needs to maintain a list of devices that will receive
controlling commands. These lists are called association groups and they are always
related to certain events (e.g. button pressed, sensor triggers, …). In case
the event happens all devices stored in the respective association group will
receive the same wireless command wireless command, typically a ‘Basic Set’ Command.

Association Groups:

Group NumberMaximum NodesDescription

Configuration Parameters

Z-Wave products are supposed to work out of the box after inclusion, however
certain configuration can adapt the function better to user needs or unlock further
enhanced features.

IMPORTANT: Controllers may only allow configuring
signed values. In order to set values in the range 128 … 255 the value sent in
the application shall be the desired value minus 256. For example: To set a
parameter to 200 it may be needed to set a value of 200 minus 256 = minus 56.
In case of a two byte value the same logic applies: Values greater than 32768 may
needed to be given as negative values too.

Parameter 1: Motion Alarm Retrigger Duration

The duration in seconds that the motion alarm would not be sent since last motion alarm reported. The motion alarm report is enabled only when the duration timer has expired. Range: 10~3600; Default: 240; value = 10 disable motion alarm report. Any valid value that great than 10 enable motion alarm report.
Size: 2 Byte, Default Value: 240

SettingDescription

Parameter 10: Night Light ON Duration

Range: 0~1. Value = 0 Night Light ON for 10 seconds (default). Value = 1 Night Light ON for 30 seconds.
Size: 1 Byte, Default Value: 0

SettingDescription

Parameter 11: Night Light ON based on ambient light level meas

Range: 0~1. Value = 0 Night Light ON only when sense detects total darkness (default). Value = 1 Night Light ON only when a small amount of light is detected.
Size: 1 Byte, Default Value: 0

SettingDescription

Parameter 12: Enable Tamper Alarm Report

This parameter setting is used to enable/disable the device cover removed Tamper Alarm report. Range: 0~1. Value = 0 – disable the Tamper Alarm report. Value = 1 – enable the Tamper Alarm report. (default)
Size: 1 Byte, Default Value: 1

SettingDescription

Parameter 13: Walk Test Mode Duration

This parameter setting is used to set the time out for Walk Test Mode. Range: 0~3. Value = 0 – disable Walk Test Mode; Value = 1 – 10 minutes; Value = 2 = 30 minutes (default); Value = 3 – 60 minutes.
Size: 1 Byte, Default Value: 2

SettingDescription

Parameter 2: Motion Alarm Retrigger Modes

This option will select how the motion alarm retrigger duration timer (CPN#1) to be reset. Range: 0~1. Value = 0, in this mode, the motion alarm retrigger duration timer (CPN#1) will be reset to zero once the motion event is detected. Hence, the motion alarm retrigger duration timer will start recounting which extends the retrigger duration. This mode will extend the battery life and reduce unnecessary motion alarm reports (default). Value = 1, in this mode, the motion alarm retrigger duration timer (CPN#1) would not be reset once the motion event has detected. The motion alarm reports will be enabled to send once the motion alarm retrigger duration timer has expired. In this mode, it will report the motion alarm event with greater fidelity. This setting might be used where the device will be used for automation tasks.
Size: 1 Byte, Default Value: 0

SettingDescription

Parameter 3: Motion Clear Duration

The period of time in seconds to send motion clear report after motion alarm has reported in Security Mode. Range: 0~3600; Default: 10; value = 0 disable motion clear report.
Size: 2 Byte, Default Value: 10

SettingDescription

Parameter 4: Low battery setting

Report battery low warning message when battery level reaches this value (percentage). Range: 10~50 (10%~50%)
Size: 1 Byte, Default Value: 10

SettingDescription

Parameter 5: Battery Scheduled Report Interval

The battery level scheduled report interval time is based on every 30 minutes per kick. The value N relatedto the time in minutes is N x 30 minutes. Range: 0~120. Default: 12 (12×30 =360 minutes). Value = 0 Disable Battery level scheduled reportBattery level scheduled report.
Size: 1 Byte, Default Value: 12

SettingDescription

Parameter 6: Luminance Change threshold

This parameter determines the change in Lux of light intensity level resulting in sending luminance report. Range: 0~60 (Lux). Default: 50. Value = 0 Disable luminance value scanning, no report. Note: The luminance value is scanned every 5 seconds. A luminance report will be sent if a change over the set threshold value is detected.
Size: 1 Byte, Default Value: 50

SettingDescription

Parameter 7: Temperature Change threshold

This parameter determines the change in temperature value resulting in sending temperature value report. Range: 0~80 (10 = 1.0 C or F; 20 = 2.0 C). Value > 0 and <10 set as 10.Default: 10. Value = 0 Disable temperature value scanning, no report.Note:The temperature value is scanned every 5 minutes. Atemperature report will be sent if a change over the setthreshold valueis detected.
Size: 1 Byte, Default Value: 10

SettingDescription

Parameter 8: Temperature Scheduled report interval

The temperature value report interval time is based on 30 minutes per kick. The value N related to the time in minutes is N x 30 minutes. Range: 0~120. Default: 6 (6×30 =180 minutes). Value = 0 Disable temperature scheduled report.
Size: 1 Byte, Default Value: 6

SettingDescription

Parameter 9: Temperature Scale Setting

Option to select the temperature scale type reported in Celsius or Fahrenheit. Range: 0~1. Value = 0 Celsius (C): Value = 1 Fahrenheit (F).
Size: 1 Byte, Default Value: 0

SettingDescription

Technical Data

Supported Command Classes

• Association Grp Info V3
• Association V2
• Battery
• Configuration V4
• Device Reset Locally
• Firmware Update Md V5
• Indicator V3
• Manufacturer Specific V2
• Multi Channel Association V3
• Notification V8
• Powerlevel
• Security
• Security 2
• Sensor Multilevel V5
• Supervision
• Transport Service V2
• Version V3
• Zwaveplus Info V2

Explanation of Z-Wave specific terms

• Controller — is a Z-Wave device with capabilities to manage the network.
  Controllers are typically Gateways,Remote Controls or battery operated wall controllers.
• Slave — is a Z-Wave device without capabilities to manage the network.
  Slaves can be sensors, actuators and even remote controls.
• Primary Controller — is the central organizer of the network. It must be
  a controller. There can be only one primary controller in a Z-Wave network.
• Inclusion — is the process of adding new Z-Wave devices into a network.
• Exclusion — is the process of removing Z-Wave devices from the network.
• Association — is a control relationship between a controlling device and
  a controlled device.
• Wakeup Notification — is a special wireless message issued by a Z-Wave
  device to announces that is able to communicate.
• Node Information Frame — is a special wireless message issued by a
  Z-Wave device to announce its capabilities and functions.
