Spektrum ™
SPMXAE1240 AVIAN ™
Dual 40 AMP SMART ESC
| Specifications | Cont. Current | LiPo Cells | BEC Output | Size/Weight |
| SPMXAE1240 | 40A | 3–6S LiPo | 6.0V / 7.4V Adjust. | 60 x 35 x 20mm / 105g |
| Motor Wire and Connector | Battery Wire and Connector |
| 50mm / 14AWG / 4mm Bullet | 150mm / 12AWG / IC5 |
Wiring Diagram
Other programming options include using the SPMXCA200 programming box and the SmartLink USB application.
Go to:
SpektrumRC.com for more information.
| Programmable Item | Option 1 | Option 2 | Option 3 | Option 4 | Option 5 | Option 6 | Option 7 | Option 8 | Option 9 |
| 1. Brake Type | Disabled | Normal | Proportional | Reverse | |||||
| 2. Brake Force | 0 | Level 1 | Level 2 | Level 3 | Level 4 | Level 5 | Level 6 | Level 7 | |
| 3. Voltage Cutoff Type | Soft Cutoff | Hard Cutoff | Surge SW | ||||||
| 4. LiPo Cells | Auto Calc. | 3S | 4S | 5S | 6S | ||||
| 5. Cutoff Voltage | Disabled | 3•0V/ Cell | 3.2V/ Cell | 3.4V/ Cell | 3.6V/ Cell | 3.8V/ Cell | |||
| 6. BEC Voltage | 6.0V | 7.4V | |||||||
| 9. Start-up Time | Normal | Soft | Very Soft | ||||||
| 10. Timing | Low (5°) | Med.(15°) | High (30°) | ||||||
| 11. Motor Rotation | CW | CCW | |||||||
| 12. Active FreeWheel | Enabled | Disabled | |||||||
| 13. Thrust Reverse | CH5 | CH6 | CH7 | CH8 | CH9 | ||||
| 14. Rud Reverse | Normal | Reverse | |||||||
| 15. Difference | Normal | Difference |
*blacked fields indicate default setting 142120.1
Avian Dual 40 Amp Brushless ESC SPMXAE1240
