IDF-DK935 Vickersen White Make Up Vanity Table With Tilting Mirror
Product Information:
- Product Name: Vanity Set
- Version: 22-10-19
- Included Tools: Allen Wrench
- Required Tools (Not Included): Phillips Screwdriver
- Recommended Number of People: 2
- Assembly Rating: Easy (5-point system)
Product Usage Instructions:
- Check Before Starting:
- Double-check all parts, hardware, and accessories to ensure
everything is accounted for. - If anything is missing or defective, contact us for
replacements. - Review the pre-assembly handouts for quick tips and
instructions. - Prep Time: Familiarize yourself with the assembly instructions
and diagrams before starting.
- Double-check all parts, hardware, and accessories to ensure
- Pre-Assembly Introduction:
- Assembling the furniture is recommended to be done by at least
two people to avoid potential injury or damage. - Choose a suitable location near the intended placement area for
assembly. - Ensure there is sufficient space to move around during the
assembly process. - Use cardboard, blankets, or a carpeted area to prevent
scratches and damages while assembling. - Place the furniture on a flat and level surface with each leg
evenly touching the floor.
- Assembling the furniture is recommended to be done by at least
- Cam Lock Fastener Assembly Instructions:
- Screw the cam bolt into the panel.
- Insert the cam bolt into the bolt hole of the joint panel.
- Align the cam lock with its side opening or arrow pointing to
the cam bolt. - Turn the cam lock clockwise gently until it cannot turn
anymore.
- Exploded View:
- Assembly Instructions:
- Attach Screw Cam Bolt (#J) to Side Plates (#1, 2).
- Attach Wood Dowel (#E) to Left Side Plate (#1) and insert Cam
Lock (#K) onto Upper Horizontal (#5). Attach Upper Horizontal (#5)
to Left Side Plate (#1). - Attach Laminate (#3) to Left Side Plate (#1) using Bolt (#A)
with Washers (#C, D) and Wood Dowels (#E). - Align and attach…
VERSION # 22-10-19
Allen Wrench
(Included)
Phillips Screwdriver
(Not Included)
2 – People Recommended
EASY
DIFFICULT
The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
1 / 14
CHECK BEFORE STARTING
Are you missing anything?
Double-check all parts, hardware and accessories listed are all acccounted for.
Should we send any replacements?
Are there any irregularities or flaws in the parts? We can send replacements!
Check out our Quick Tips!
We recommend reviewing the pre-assembly handouts. Even experts need a refresher now and then!
Prep Time!
Please review the assembly instructions and all diagrams prior to assembling.
2 / 1
PRE ASSEMBLY INTRODUCTION
We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process.
Teamwork
ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
Suitable Location
Assembling near the area of the intended location is highly recommended.
Sufficient Space
Make sure you have enough space to move around during the assembly.
Avoid Scratches
Use cardboard, blankets or a carpeted area while assembling furniture to prevent to prevent scratches and damages.
Flat Surface
Make sure the furniture rests on a flat and level surface with each leg evenly touching the floor.
3 / 1
4 /
CAM LOCK FASTENER ASSEMBLY INSTRUCTIONS
Note :
Every cam lock bolt must have a cam lock connector in order to fasten the parts together.
cam bolt
cam lock screwdriver
1
Screw the cam bolt into panel.
2
Insert the cam bolt into the bolt hole of joint panel.
3
Align the cam lock with its side opening (or arrow) pointing to cam bolt.
4
Turn the cam lock clockwise gently until it will not turn any more.
/ X
VANITY SET
#1 1pc
#2 1pc
#3 1pc
Left side plate #5 1pc
Right side plate #6 1pc
Laminate #7 1pc
#4 1pc
Back plate #8 2pcs
Upper horizontal #9 1pc
Box #10 1pc
Mirror base
Mirror pole
Mirror
Glass
#A 12pcs
#B 2pcs
#C 14pcs
#D 14pcs
Bolt 1/4” x 1-3/8” #E 12pcs
Bolt 1/4” x 2” #F 1pc
Lock washer 1/4” #G 1pc
Washer 5/16” x 19mm #H 1pc
Wood Dowel 8 x 30mm
Allen Wrench 4mm Block Drawers
6 / 14
Screw 3 x 12mm
#I 2pcs
Glass suction cup Ø26mm #M 3pcs
#J 2pcs
Cam Bolt 7.5 x 35mm
#N 1set
#K 2pcs
Cam Lock Ø15 x 12mm
light bulb
Anti-tip Skit
Exploded View
#L 2pcs
Mirror Bolt 5/16” x 1-3/4”
#8 #3 #1
#9 #8 #7 #10
#4 #2
#5
#6
7 / 14
ASSEMBLY INSTRUCTIONS
1
Part #1 x1pc
Part #2 x1pc
Hardware #J x2pcs
#J
#1 #2
Screw Cam Bolt (#J) to Side Plates (#1, 2)
2
Part #5 x1pc Hardware #E x2pcs Hardware #K x1pc
#5
#K
#F #E
Attach Wood Dowel (#E) to Left Side
#1
Plate (#1). Insert Cam Lock (#K) unto
Upper Horizontal (#5). Attach Upper
Horizontal (#5) to Left Side Plate (#1)
8 / 14
ASSEMBLY INSTRUCTIONS
3
Part #3 x1pc Hardware #A x4pcs Hardware #C x4pcs Hardware #D x4pcs Hardware #E x2pcs
#F #A #C #D
#E
Attach Laminate (#3) unto Left Side Plate (#1) and secure by using Bolt (#A) with Washers (#C, D) and Wood Dowels (#E)
#1
#5 #3
4
Part #4 x1pc Hardware #A x2pcs Hardware #C x2pcs Hardware #D x2pcs
#F
#A #C #D
Align and attach
Back Plate (#4)
#4
by using Bolt (#A)
with Washers
(#C, D)
9 / 14
ASSEMBLY INSTRUCTIONS
5
Hardware #A x6pcs
Hardware #C x6pcs
Hardware #D x6pcs
Hardware #E x4pcs
#2
Hardware #K x1pc
Insert Cam Lock (#K) and Wood Dowels (#E) unto Upper Horizontal (#5). Align and attach Right Side Plate (#2) by using Bolt (#A) with Washers (#C, D).
#D #C #A
#F
#E
#F
#K #5
#D #C #A
#F
6
Part #7 x1pc Part #8 x2pcs Hardware #B x2pcs Hardware #C x2pcs Hardware #D x2pcs Hardware #E x4pcs
Align and attach Mirror Base (#7) and Mirror Pole (#8) using Bolt (#B) with Washers (#C, D) and Wood Dowels (#E)
#8
#7
#E
#D #C #B
#F
10 / 14
ASSEMBLY INSTRUCTIONS
7
Part #9 x1pc
Hardware #L x2pcs
#L
#9
Attach Mirror (#9) and secure using Mirror Bolt (#L)
8
Hardware #G x1pc Hardware #H x1pc Attach Block Drawers (#G) with Screw (#H)
#H #G
11 / 14
ASSEMBLY INSTRUCTIONS
9
Part #6 x1pc Align and insert Box (#6). Affix Handle as shown
#6
10
Part #10 x1pc Hardware #I x2pcs
Align and attach Glass (#10) using Glass Suction Cups (#I)
#10 #I
12 / 14
ASSEMBLY INSTRUCTIONS
11
Hardware #M x3pcs
Attach Light Bulbs (#M) as shown
#M
OFF ON
WALL
12
Hardware #N x1set #N
WALL
Plug power cords to the electrical outlet.
13 / 14
