SONY Wi-Fi Network AV Receiver
Enjoy flexible connectivity, powerful configurability and renowned ES quality in this 7.2 channel 4K AV receiver with Dolby Atmos® and DTS:X object-based surround sound. Add in full 4K HDR compatibility and easy IP integration with leading control systems and you have the total package of installation-friendly features and audio/video performance.
Bullets
- 7.2 Ch. 100W per channel (8ohms, 1KHz, 0.9%, 2CH)
- Supports Dolby Atmos®, and DTS:X® object based surround up to 5.1.2 plus two phantom rear surround channels9,10
- 4K HDR compatibility 6-in/2-out HDMI® flexibility with HDCP 2.2 support3
- Digital Cinema Auto Calibration EX with speaker relocation technology
- Firmware update via network connection
- Exceptional circuitry and structure yield incredible audio performance
- Three DSPs (digital signal processors) to reduce unwanted electrical noise
- Flexible multi-zone distribution with IR repeater (1- in, 1-out) for external device control
- In-ceiling speaker mode for natural, rich front channel sound staging
- Experience amazing sound with Hi-Res Audio
Features
7.2 Ch. Of Power
With 100W per channel, the STR-ZA810ES delivers cinema-like surround sound and crystal clear music reproduction (100W @ 8 ohms, 1 kHz, THD 0.9%) For special installations, the amplifier can be configured to support: 2 pairs of speakers either independently (A or B) or simultaneously (A and B), in addition to Bi-Amp fashion.
Supports Dolby Atmos®, and DTS:X® object based surround⁹,¹⁰
You’ll feel like you’re inside the action as the sounds of people, music, and objects move all around you in three dimensional space.9,10 Can’t fit seven channel surround? Phantom rear surround channels will transform your five channel system into a seven channel system.
4K HDR compatibility
Flexible connectivity with 6 assignable HDMI® inputs and 2 outputs supporting HDR and HDCP 2.2.3,8 In addition the ZA810ES allows full, native 4K video content pass-through to 4K capable televisions and projectors, and even up-scales high definition movies and TV shows to 4K quality.³
Digital Cinema Auto Calibration EX with speaker relocation technology
D.C.A.C. EX with stereo mic is Sony’s unique auto calibration technology. This technology balances output to closely simulate sound as would be produced by optimally positioned and angled speakers. The results are nothing short of breathtaking, with the entire sound field seamlessly integrated for outstanding surround sound.
Firmware update via network connection¹
Perform firmware updates quickly and easily over a network connection1
Built for sound
Every detail from the electronic component selection, to special 2nd generation ES solder, structural/chassis elements, and even screw placement has been scrutinized and tuned in the higher interest of reliably consistent sound performance. The STR-ZA810ES offers improved structural stability for better sound via the analogue signal path. This circuit is located on a glass epoxy board, in order to achieve higher speed and power.
Three DSPs to reduce unwanted electrical noise
Dispersing the load between three DSPs allow the realization of clarity and realistic ambience by reducing noise
Flexible 2nd zone connectivity and control
Easily expand your audio/video experience beyond the living room with flexible 2nd zone connectivity and control.
Complete with dedicated 2nd zone HDMI®, IR repeater, and both amplified and line-level audio connectivity, all audio (including network services, BT connected devices and USB) and video sources connected to the STR-ZA810ES can be independently controlled and output from the Main Zone to a second zone (bedroom or den).
In-Ceiling speaker mode
Developed especially for use with in-ceiling speakers and easily configured during setup, In-Ceiling Speaker Mode virtually relocates the Front and Center in-ceiling speaker sound images to better coincide with the screen. Dialog and music will sound as if coming from the screen instead of the ceiling.
Amazing Hi-Res Audio quality
Enjoy the subtlest nuances of studio-quality sound in higher than CD quality with High-Resolution Audio.7 Passion for music unites every component from signal to speaker so it feels like the artist is performing right in front of you. Supports high bit rate 192k/24-bit WAV/FLAC audio playback, and even native DSD up to 5.6MHz. Additional file formats supported include: MP3, AAC, WMA, WAV 192k, FLAC 192k, ALAC and AIFF Simply connect the compatible device to the receiver and enjoy.
Advanced on-screen graphical user interface
Easily set-up and control the A/V receiver via intuitive on-screen graphical user interface. Change inputs, adjust settings, and confirm volume levels on-screen.
Dual-band (2.5/5 GHz)Wi-Fi®1
Wirelessly connect to your home network and access music stored on: your computer, network storage device, smartphone, or built-in music services¹,³.
Also cast music, podcasts and radio from 100+ apps with Chromecast built-in¹
Multi-room listening, plus voice control powered by Google Home¹
Easily expand and control your music across multiple, compatible speakers in separate rooms with powerful multi-room capability and intuitive SongPal™ Link app functionality.4 Also enjoy voice control, powered by Google Home6, that lets you control what music you want-and where-by the sound of your voice.
Control with your iPhone® or Android™ devices with free Apps³
Download the free SongPal™ and Network Audio Remote apps from iTunes® or the Google™ Play Store and use your iPhone® or Android™ devices with the SongPal™ app to control receiver functionality including volume and input selection²,⁴
Standby Audio/Video signal pass-through
Enjoy convenient access to all of your HDMI® connected devices without having to power on the receiver³.
Sony® ES 5-Year Limited Warranty
All ES-Series receivers come with an industry leading 5-year parts and labor warranty, 90-day advanced exchange program, and dedicated toll-free support line staffed by CEDIA-trained product experts. (1-877-619-7669; Monday – Friday 10am – 7pm ET)⁵
Specifications
Amplifier/Receiver
| Audio Features | A/V SYNC | Yes (Variable) | ||
| A/V Sync Time/Sampling Frequency | 0-300msec/192kHz | |||
| Center Speaker Lift Up | Yes | |||
| Digital Legato Linear | Yes | |||
| DSEE HX | Yes (USB/ Home Network/ Bluetooth-RX/ Spotify Connect) | |||
| In-Ceiling Speaker Mode | Yes | |||
| OP processing | Yes | |||
| Pure Direct | Yes | |||
| Sound Optimizer | Yes | |||
| Speaker Selector | A/B/A+B/OFF | |||
| Speaker Terminal Type | Screw (Ni) | |||
| Sub Woofer Cross Over Frequency | 17 points (40-200Hz) | |||
| Audio Input | Analog Audio In | 4 | ||
| Coax. | 1 | |||
| Audio Output | Headphone Out | Yes (Gold) | ||
| Pre Out (Subwoofer) | 2 | |||
| DCAC Features | Automatic Phase Matching | Yes | ||
| D.C.A.C. EX / Advanced D.C.A.C. / D.C.A.C. | D.C.A.C. EX | |||
| EQ for D.C.A.C | 31band GEQ | |||
| Mic | Calibration Mic: Stereo | |||
| Speaker Relocation | Yes | |||
| Input/Output Others | Ethernet | Ethernet Port (Power over Ethernet) : 1 (0) | ||
| NFC | Yes | |||
| USB Front(ver) / Rear(ver) | Yes (2.0) | |||
| Wi-Fi | Yes (2.4GHz/5GHz), (11a/b/g/n) | |||
| Output Power | Center | 100W(8ohms, 1kHz, 1ch, THD 0.9%) | ||
| Front | 100W + 100W (8ohms, 1kHz, 2ch, THD 0.9%) | |||
| Number of amp. channels | 7ch | |||
| Speaker Impedance | 6ohms-16ohms | |||
| Surround | 100W + 100W(8ohms, 1kHz, 2ch, THD 0.9%) | |||
| Surround Back | 100W + 100W(8ohms, 1kHz, 2ch, THD 0.9%) | |||
| Sound Field | 2ch | Yes (2ch Stereo) | ||
| Direct | Yes | |||
| Dolby Surround | Yes | |||
| Front Surround | Yes | |||
| Headphone 2ch | Yes | |||
| Neural:X | Yes | |||
| Yes | ||||
| Front A | Yes | |||
| Front High (L/R)/ Surround Back for Common Use | Yes (Height / Surround Back/ Front B / Bi-AMP (for Common Use)) | |||
| Surround | Yes | |||
| Zone2 | Yes | |||
| Yes | ||||
| Front (Bass/Treble) | Yes | |||
| Surround (Bass/Treble) | Yes | |||
| Surround Back (Bass/Treble) | Yes | |||
| Yes | ||||
| Direct Tuning | Yes | |||
| FM/AM | Yes (FM only) | |||
| Preset Channel (FM/AM) | TTL30 (30/-) | |||
| Station Name | Yes | |||
| 2 (0) | ||||
| 1 | ||||
| HDCP2.2 | HDMI Input supporting (Front): 6(0) HDMI Output supporting: 2 (1:Assignable) | |||
| HDMI | ||||
| Audio Features | Audio Return Channel | Yes | ||
| S-Select | Yes | |||
| Decoding Formats | Dolby Atmos | Yes | ||
| Dolby Dual Mono | Yes | |||
| Dolby TruHD/Dolby Digital Plus | Yes/Yes | |||
| DSD | Yes (Up to 2.8MHz 5.1ch) | |||
| DTS:X | Yes | |||
| DTS / DTS-ES (Matrix6.1 / Discrete6.1) | Yes/Yes | |||
| DTS 96/24 | Yes | |||
| DTS HD MA / DTS HD HR | Yes/Yes | |||
| LPCM | Yes (Up to 192kHz/24bit 7.1ch) | |||
| Others | BRAVIA® SYNC™ (CEC Control) | Yes (One-Touch Play, System Audio Control, System Power Off) | ||
| Video Features | 3D over HDMI | Yes | ||
| 4K 60p 4:4:4 Support | Yes (Except for VIDEO1 input) | |||
| HDR | Yes | |||
| Installation | ||||
| Control Features | CIS IP Control | Yes | ||
| IR Repeat (In/Out) | Yes (1/1) | |||
| Features | 2nd A | Speaker (Variable) / Line (Variable, Fixed) | ||
| HDMI Zone | Yes | |||
| Multi Zone Line Out Level Control (Zone2/Zone3) | Yes (Yes/-) | |||
| Multi Zone Volume Control (Zone2/ Zone3) | Yes (Yes/-) | |||
| RS-232C for control | Yes | |||
| Network Features | ||||
| AirPlay | Yes | |||
| FLAC | Yes (Up to 192kHz/24bit 5.1ch) | |||
| Google Cast | Yes | |||
| Mobile Application | SongPal / Video & TV sideview | |||
| Music Decoding Formats for Network Client | [MP3].mp3, [AAC/HE-AAC].m4a, .aac, [WMA9 Standard].wma, [LPCM].wav, [FLAC].flac, .fla, [DSF]. dsf, [DSDIFF].dff, [AIFF].aiff, .aif, [ALAC].m4a | |||
| Network Player/Renderer | Yes/Yes | |||
| SongPal Link | Yes (SongPal compatible models with iPod/iPhone/ iPad (iPhone 6s Plus iPhone 6s iPhone 6 Plus iPhone 6 iPhone 5s iPhone 5c iPhone 5 iPhone 4s iPod touch (5th and 6th generation)) | |||
| Spotify Connect | Yes | |||
| Easy Setup Wizard | Yes | |||
| Other | ||||
| Additional Features | GUI | YES (Only through HDMI) | ||
| GUI Language | English, French, Spanish | |||
|
Customize Features | Custom Preset (Easy Automation) | Yes | ||
| Input Assign (HDMI/Component/ Opt/Coax) | Yes (-/-/Yes/Yes) | |||
| Sleep Timer | Yes (up to 2 hours) | |||
|
General | Auto Standby | Yes | ||
| Detachable AC | Yes | |||
| Pin Jack | Nickel | |||
| Power Consumption | 240W | |||
| Power Consumption(Power Stand By) | 0.5W Bluetooth Standby: 2.5W | |||
| Power Requirement | 120V 60Hz | |||
| Remote Commander | RMT-AA320U | |||
| System Update (Internet/USB/PC) | Yes (Yes/Yes/-) | |||
| Accessories | ||||
| Accessories | Supplied Accessories | Calibration microphone FM wire antenna AM loop antenna AC power cord Remote control (RMT-AA320U) R03 (size-AAA) batteries Front cover | ||
| USB Type A | ||||
| USB Mass Storage | FLAC | Yes (Up to 192kHz/24bit 5.1ch) | ||
| Interface | 2.0 | |||
| Music Decoding Formats | [MP3].mp3, [AAC/HE-AAC].m4a, .aac, [WMA9 Standard].wma, [LPCM].wav, [FLAC].flac, .fla, [DSF].dsf, [DSDIFF].dff, [AIFF].aiff, .aif, [ALAC].m4a | |||
| Walkman Connectivity | Music/Video/Photo | Yes/-/- | ||
| Weight and Measurements | ||||
| Weight and Measurements | Carton Dimensions (WxHxD mm) | 19 x 5/8 x 15 5/8 x 8 inches (496 x 396 x 211 mm) | ||
| Receiver Dimension (WxHxD inches) | 17 x 6 1/4 x 13 1/8 inches (430 x 156 x 331 mm) | |||
| Receiver Weight (pound) | 20 lbs. 1oz. (9.1 kg) Gross weight: 24lb 5oz (11 kg) | |||
- Wireless connectivity requires an 802.11 home network (802.11n recommended). (broadband)
- Interoperability and compatibility among Bluetooth® devices vary. (BT)
- Requires HDMI® cable sold separately. (HDMI-24P)
- Requires download of SongPal app for iPhone from the App Store or for Android from Google Play. User must link compatible devices in order to control operation. Subject to app terms and conditions.
- For full terms and conditions please visit www.esupport.sony.com
- Requires download of Google Home app for iPhone from the App Store or for Android from Google Play. User must link compatible devices in order to control operation. Subject to app terms and conditions. Some features may not be available in all countries.
- Only compatible with High-Resolution Audio when wired.
- Requires HDMI® cable, HDR media and HDR capable device sold separately.
- May require HDMI® cable, Dolby Atmos media and Dolby Atmos capable playback device sold separately.
- May require HDMI® cable, DTS:X media and DTS:X capable playback device sold separately.
