2 Product Information: Gevi Nugget Ice Maker (GIMN-1000B)

GIMN-1000B Nugget Ice Maker

Product Information: Gevi Nugget Ice Maker (GIMN-1000B)

Gevi is a newly built brand specializing in small home
appliances. The Gevi Nugget Ice Maker is designed to bring
convenience and joy to families around the world. With a focus on
innovation and quality, Gevi ensures that every product meets high
standards. The ice maker is suitable for household use only and is
built to last.

Important Safety Instructions

Before using the ice maker, it is crucial to read and understand
all the safety instructions provided in the user manual. This will
help reduce the risk of fire, explosion, electric shock, or injury.
Additionally, it is important to note that the ice maker should not
be used outdoors as radiation can potentially damage the plastic
components.

Getting Your Ice Maker Ready

Unpacking: Carefully unpack the ice maker and
ensure that no items are causing damage to its surface.

Know Your Ice Maker: Familiarize yourself with
the different components of the Gevi Nugget Ice Maker. These
include the ice basket, ice scoop, control panel, front lid, drain
hoses, exhaust fan, water inlet, air vent, power cord, water
reservoir, water screen, magnetic switch, infrared sensor, top
water reservoir, and UV light.

Control Panel

The control panel of the Gevi Nugget Ice Maker features various
buttons and indicators:

On/Off: Press this button to turn the ice
maker on or off.
Clean: Press and hold this button for 3
seconds to enter the self-cleaning program.
Indicators: The indicators on the control
panel serve different purposes. They flash when the ice maker is
plugged in, glow solidly during ice making, glow white when the ice
maker is running the self-cleaning program, glow white when the
water supply is insufficient, and glow white when the ice basket is
full.

FAQs

Water Residue Found: It is normal to find
water residue in the water reservoir or drain hoses as every Gevi
Ice Maker undergoes a running test before leaving the plant. To
ensure cleanliness, run the self-cleaning program twice with fresh
water before the first use.
Time of Ice Making: The time taken to make ice
is influenced by ambient and water temperature. The first ice will
be produced within 15 to 30 minutes. On average, it takes 3-4 hours
to fill the ice basket.
Water Flowing During Ice Making: When the ice
maker starts making ice or refilling water, water flows through the
ice chute into the water reservoir to cool it. Water will stop
flowing once its temperature is low enough to form ice.

For further assistance or information, please refer to the
complete user manual or contact Gevi’s Customer Support.

View Fullscreen

USER MANUAL
NUGGET ICE MAKER
GIMN-1000B
Household Use Only

THANK YOU FOR HAVING GEVI A PART OF YOUR HOME
Gevi is a newly built brand specializing in small home appliances. Our goal is to bring convenience and joy to families around the world. We are proud of the innovation and quality that put into every Gevi product and we hope you will too. To ensure proper use of this appliance and make it last longer, please read this manual thoroughly before using and save it for future reference.
To let us better provide service, register your Gevi appliances online now to receive important product information and warranty details. You may also find our contact ways in the Customer Support section of this User Manual.
One more important notice: Keep the ice maker upright for at least 2 hours before first use and every time it’s heavily skewed or inverted.
Gevi Team

Table Of Contents
IMPORTANT SAFETY INSTRUCTIONS……………………………………………… 1 GET YOUR ICE MAKER READY……………………………………………………….. 3 Unpacking………………………………………………………………………………………… 3 Know Your Ice Maker………………………………………………………………………… 3 Before First Use………………………………………………………………………………… 6 HOW TO USE………………………………………………………………………………… 7 Operation Guide……………………………………………………………………………….. 7 Ice Making………………………………………………………………………………………… 9 Cleaning…………………………………………………………………………………………..10 Descaling………………………………………………………………………………………… 11 TROUBLE SHOOTING…………………………………………………………………… 12 TECHNICAL PARAMETERS…………………………………………………………….14 CUSTOMER SUPPORT…………………………………………………………………..14 WARRANTY………………………………………………………………………………….15

IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING

Nugget Ice Maker

To reduce the risk of fire, explosion, electric shock, or injury when using your ice maker, follow these important safety instructions:
·Before using, check if the power source corresponds to 120V, 60Hz. ·Do not remove any safety, warning, or product information labels from your ice maker. ·Plug the ice maker into an exclusive grounded outlet, do not use an adapter. No other appliance
should be plugged into the same outlet. Be sure that the plug is fully inserted into the receptacle. ·Do not operate any appliance with a damage cord or plug or after the appliance malfunction
or has been damaged in any manner. Return the appliance to the nearest authorized service facility for examination, repair or adjustment. ·Do not store or use gasoline or other flammable material and vapors around this appliance. ·Avoid the use of an extension cord because it may overheat and cause a risk of fire. However, if it is necessary to use an extension cord:
Use only extension cords with grounding plug. The marked rating of an extension cord must be equal to or greater than the rating of this appliance. It should be positioned such that it does not drape over the counter or tabletop where it can be pulled on by children intentionally. ·Do not try to open the housing of the ice maker for repair, study or otherwise purpose. This action may result in frostbite, electrical shock, fire, property loss or death. ·The action of cleaning ice maker requires scale remover which contains acids. Acids can cause burns. If skin contact with concentrated cleaner may happen, flush with water. If swallowed, drink large amount of water or milk and call physician immediately. Keep scale remover out of reach of children. ·Repare service shall be performed by qualified electric service personnel and component parts shall be replaced with manufacturer authorized replacement components. ·When handling, installing, and operating the appliance, care should be taken to avoid damage to the refrigerant tubing.

IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING

Nugget Ice Maker

Outdoor Use Notice
·Keep Cool: Operation in ambient temperature beyond the limits listed in this manual (Refer to page 5) may result in severe damage which is not covered by warranty.
·Keep Upright: Place on level surface only, skewed placement may damage the refrigeration system. ·Provide Shade: Heat from the sun will reduce the unit’s ability to make and store ice. UV
radiation can potentially damage the plastic components.
Electricity
Do not, under any circumstances, remove the ground prong from the power cord or use an adaptor that prevents it from functioning. For personal safety, this unit must be properly grounded. ·Do not plug or unplug the unit with wet hand. ·Grounding is to minimize the possibility of electric shock hazard. The power cord of this appliance
is equipped with a 3-prong plug which mates with a standard 3-prong wall outlet. Have your wall outlet and circuit checked by a qualified electrician to make sure it’s properly grounded. ·The appliance should not be plugged into a 2-prong outlet, it is user’s responsibility and obligation to replace it with a properly grounded 3-prong wall outlet. ·The unit should always be plugged into its rated source, 120 volt, 60 Hz, 15 amp circuit. This helps the machine to provide the best performance and also prevents overloading wiring circuits which could potentially cause a fire hazard from overheated wires. ·Repair or replace immediately all power cords that are frayed or otherwise damaged. Do not use a cord that has cracks or abrasion damage along its length or at either end.
Disposal of Your Appliance
All refrigeration products contain flammable refrigerants, which under federal law must be removed prior to disposal. Please check with the company handling the disposal for what to do if you are getting rid of refrigeration product.

GET YOUR ICE MAKER READY

Nugget Ice Maker

Unpacking
IMPORTANT : Do not remove any safety, warning, or product information labels from your ice maker. · Package includes: 1 ice maker, 1 ice basket, 1 ice scoop and 1 user manual. · Remove tape and any labels from your ice maker before using (except for the labels listed above). · Do not use sharp tools, alcohol, flammable fluids or rough cleaners to remove tape or glue.
These items can cause damage to the surface of your ice maker.
Know Your Ice Maker

Gevi Ice Maker

Ice Basket

Ice Scoop 3

GET YOUR ICE MAKER READY

Nugget Ice Maker

Control Panel Front Lid

Know Your Ice Maker
Drain Hoses Exhaust Fan Water Inlet Air Vent

Air Vent II Power Cord

Water Reservoir Max Water Line

Water Screen

Magnetic Switch

Ice Full Infrared Sensor
4

Top Water Reservoir UV Light

GET YOUR ICE MAKER READY
Know Your Ice Maker

Nugget Ice Maker

Control Buttons On/Off – Press to turn the ice maker on or off. Clean – Press and hold for 3 seconds to enter self-cleaning program.

Indicators – Keep flashing when the ice maker is plugged in, glow solidly during ice making.

– Glow white when the ice maker is running self-cleaning program.

– Glow white when the water supply is not enough to continue making ice.

– Glow white when the ice basket is full.

FAQs
1.Water Residue Found Every Gevi Ice Maker goes through a running test before leaving the plant, so it’s normal to find water residue in water reservoir or drain hoses. Run self-cleaning program twice with fresh water before first use.
2.Time of Ice Making Time of ice making is affected by the ambient and water temperature. (Refer to page 5 for temperature range.) The first ice comes out between 15 and 30 minutes. Usually, it takes 3-4 hours to fill the ice basket.
3.Water Flowing During Ice Making Every time the ice maker starts making ice or water is refilled.Water flows through the ice chute into water reservoir, this is to cool the water. Water will stop flowing when its temperature is low enough to form ice.
4.Sounds Made by Ice Maker The ice maker is designed to work quietly but will make some sounds during operation.
5.Heat Generation It’s normal for the ice maker to generate some heat during working, especially when it has kept working for a long time.
5

GET YOUR ICE MAKER READY

Nugget Ice Maker

Before First Use
1.Unpack and check if all the items (Refer to page 2) are available. Please contact Gevi Customer Service if anything is missing.
2.Ensure the ice maker stands upright on the level surface. After the jolt of transport, keep the ice maker still for 2 hours before plugging in.
3.The incline angle should not exceed 45° when moving. Turning upside down is strictly forbidden. Doing so can cause damage to the compressor or refrigerating system.
4.Keep the environment dry and stay away from heat sources such as ovens, heaters and corrosive gases. Maintain at least 6 inches clearance on all sides of the ice maker for ventilation.
5.The ice maker should operate between 50°F (10°C) and 90°F (32°C). Use water with a temperature between 46°F (8°C) and 82°F (28°C) for ice making or cleaning. Exceeding the limit may result in severe damage which is not covered by the warranty.
6.Clean your ice maker and accessories. Add water to the reservoir, run self-cleaning program twice with fresh water, and then drain it out through the drain hoses.

keep it still for 2 hours

HOW TO USE

Nugget Ice Maker

Operation Guide
1.Add Water Pour potable water with a temperature between 46°F (8°C) and 82°F (28°C) into the water reservoir. Do not exceed the “Max” water line.
Figure 1
2.Drain Water · Take the drain hoses off and put them in a sink or a bucket. Make sure that the end of the
hoses are lower than the bottom of the ice maker. · Remove the drain cap. The drain hoses will drain the water by themselves. · After fully drained, seal back the drain hoses and hang them up at the back of your ice maker.

Figure 2

Figure 3

Figure 4
Notes Drain the ice maker should be through the drain hoses at the back of the machine. Do not tip the ice maker over.
7

HOW TO USE

Nugget Ice Maker

3.Heat Dissipation The ice maker generates some heat while it is working, so a 6-inch clearance on all sides should be kept for proper ventilation. Remember to keep the environment dry and stay away from heat sources such as ovens, heaters and corrosive gases.
Figure 5
4.Magnetic Switch Magnetic switch in the lid works for the below two scenarios.
Scenario 1. The ice maker stops ice making when the indicator is on.When you open and close the lid, the magnetic switch triggers ice making. If the ice full infrared sensor (refer to page 3) detects that the ice is not full, the machine continues ice making. Otherwise, the indicator of lights up again. This is designed to save energy in case the ice melts and the machine restarts making ice constantly but no one is around.
Scenario 2. The ice maker stops ice making when the water is not enough , it will not continue to make ice until there’s enough water. When you open and close the lid, the magnetic switch triggers water level detection. If there’s enough water for ice making, the machine will resume ice making. Otherwise, the indicator of lights up again.

5.Turn Off the Ice Maker Short press “On/Off” button to turn off the ice maker. The machine will continue to work for an extra 30-60s to remove the remaining ice from internal components, and it will automatically stop working when the process is completed. The indicator keeps flashing unless the ice maker is unplugged. Note: When unplugging the ice maker, empty the ice basket to avoid overflow of water from melted ice.

HOW TO USE

Nugget Ice Maker

Ice Making
1.Ensure the drain hoses at the back of the ice maker have been sealed and hung up on the machine.
2.Plug into a 120V/60Hz wall outlet. Check if the indicator flashes.
3.Open the lid, add potable water into water reservoir, then close the lid. Be careful not to exceed the “Max” water line.If it’s the first time using this ice maker, read instructions of “Before First Use” on page 5.

Figure 6

4.Press the “On/Off” button. The indicator glows white solidly.
5.Wait for 15-30 minutes to enjoy fresh nugget ice. Note that time of first ice is affected by the ambient temperature and water temperature.(Refer to page 5 for temperature range.)

Figure 7

6.The ice maker keeps making ice until the ice basket is full, or the water runs low.

Figure 8

Notes · Remember to take out the ice scoop before making ice to avoid it being covered by the ice. · Heat insulation layer used for housing only helps slow down the melting of ice. The rate of melting
depends on ambient temperature. It’s recommended to transfer ice to freezer for longer storage. · When the machine stops ice making triggered by , it will not continue to make ice until the ice is
fully/partially removed, or the lid is opened and closed. This is designed to save energy in case ice melts and machine restarts making ice but no one is around. · If the ice maker is not to be used for some time, empty the water reservoir and dry it for storage. · The ice maker is designed to work quietly but will make some noise during operation.

HOW TO USE

Nugget Ice Maker

Cleaning
1.Remove all the ice.
2.Drain the ice maker through the drain hoses. Remember to place the hoses into a sink or a bucket before removing the drain cap.
3.Pour cleaning solution into water reservoir and add water to the max water line.
4.Close the lid, press and hold the button for 3 seconds to enter self-cleaning program.

Figure 9

5.The self-cleaning program ends in 5 minutes. Then empty the ice maker through the drain hoses and seal them back.

6.Refill water into the water reservoir. Repeat step 4 and step 5 more than twice to rinse out the residues. Remember to use fresh water each time.

Figure 10

7.Clean ice basket and ice scoop.

8.Clean the exterior of the machine with a damp sponge.

Figure 11

Notes · Do not use organic solvent, boiled water, detergent, strong acid or strong alkali, etc. for cleaning. · It’s recommended to clean the ice maker once a week to keep ice fresh and help the machine
last longer.

HOW TO USE
Descaling
1.Remove all the ice.
2.Drain the ice maker through the drain hoses. Remember to place the hoses into a sink or a bucket before removing the drain cap.
3.Pour descaling solution into water reservoir and add water to the max water line.

Nugget Ice Maker
Figure 12

4.Close the lid, press and hold the button for 3 seconds to enter self-cleaning program.

5.The self-cleaning program ends in 5 minutes. Then empty the ice maker through the drain hoses and seal them back.

Figure 13

6.Refill water into the water reservoir. Repeat step 4 and step 5 more than twice to rinse out the residues. Remember to use fresh water each time.

Figure 14

Notes · Do not use organic solvent, boiled water, detergent, strong acid or strong alkali, etc. for descaling. · It’s recommended to descale the ice maker once a week to keep ice fresh and help the machine
last longer.

TROUBLE SHOOTING

Nugget Ice Maker

Problem

Trouble Shooting
Possible Causes

Solutions

Water is not enough

Add water to reservoir manually

“Add Water” On

Water screen in the water reservoir is blocked
Pump malfunction

Clean water screen Contact Gevi Customer Service for help

Ice basket is full

Empty the ice basket

“Full” On

Ambient temperature exceeds limited working temperature
Infrared sensor blocked

Change the environment to meet the requirements on page 5.
Check if any ice has blocked or got stuck in the infrared sensor and Clean it.

NTC malfunction

Contact Gevi Customer Service for help

“Making”On and Defrosting mode “Cleaning” Flash

1.No action is needed. The ice maker is in defrosting process and it will end in approx 30 minutes. 2.Alternatively, you can hold and press the “Clean” button for 3 seconds, and then press the “ON /OFF” button again to restart the appliance.

“Making” and Ice making components are “Cleaning” Flash frozen

1.Unplug the ice maker for 45-60 minutes for ice to melt. Then run cleaning program 2-3 times with fresh water.

TROUBLE SHOOTING

Nugget Ice Maker

Problem

Trouble Shooting
Possible Causes

Solutions

“Making” and Ice making components are “Cleaning” Flash frozen

2.Contact Gevi customer service for help if it happens frequently.

No Ice Noise

Poor heat dissipation
The water temperature is too high

Keep a 15cm/6inch clearance on all sides of the ice maker for proper ventilation.
Use water with a temperature between 46°F(8°C) and 82°F(28°C)

The ambient temperature is too high

Operate in an environment between 50°F (10°C) and 90°F (32°C)

The ice-making system is Malfunctioning

Contact Gevi customer service for help

Turn off the machine for 45 to 60 Ice-making components are frozen minutes for ice to melt. Then follow
the steps of “Descaling” on page 10.

Resonance

Remove any other object that is in contact with the ice maker.

Compressor malfunction

Contact Gevi customer service for help

Exhaust fan makes a loud noise

Making a sound during working is normal. If the sound is too loud, contact Gevi customer service for help.

Water Leak

Contact Gevi customer service for help

TECHNICAL PARAMETERS

Nugget Ice Maker

Model: Applicable Climate: Class: Power Source: Rated Power: Refrigerant/Refrigerant Amount: Foaming Agent: Net Weight: Housing: Unit Size (DxWxH):

GIMN-1000B ST/SN/N/T I 120V/60Hz/3.0A 170W R600a / 24g C5H10 16.5kg/36.4Lbs SUS430 17.2 x 9.6 x 16.7 inch

CUSTOMER SUPPORT
Gevi Official Website Have a question or need assistance with your appliances? Visit Gevi Official Website any time any where. You can also get more information about Gevi via www.gevi.com
Gevi Official Hotline Wish to speak with someone? Call 855-9922-888 during normal business hours.
Gevi Official Email To describe your issue in detail, write to us at [email protected]

WARRANTY

Nugget Ice Maker

www.gevi.com
Warranty service is provided by Gevi Customer Service Center. To contact customer service team, visit our website at www.gevi.com, email at [email protected] or call Gevi at 855-9922-888.

Period

Gevi Will Replace

30 Days From the date of original purchase

Whole unit if the ice maker fails due to a defect in materials or workmanship.

1 Year From the date of original purchase

Any part of the ice machine which fails due to a defect in materials or workmanship.

Warranty Extension
· Purchase Warranty Extension service at www.gevi.com/products/warranty-extension.
· Register your warranty at www.gevi.com/warranty to receive 3 months warranty extension for FREE.

Warranty Register

NOTE

Nugget Ice Maker

NOTE

Nugget Ice Maker

NOTE

Nugget Ice Maker

Tel: 855-9922-888 Email: [email protected] Website: www.gevi.com
