DOOR20NPSB-G1 Mini Dosing NPS

Product Information

• Model: Mini Dosing NPS
• Pool Volume: 120 m3
• Pump Flow: 1.8 l/h
• Reference: DOOR20NPSB-G1

Technical Specifications

• Display: Digital display
• Desinfectant dosage: Automatic chlorine dosage by ORP
  probe
• Smart injection: Yes
• ORP set point adjustment (mV): 200 to 900
• Calibration ORP probe: 1 point
• ORP probe: ORP Gold
• Control panel size (mm): Width – 118, Height – 231, Depth –
  78

Installation Diagram

Content

• 2-year warranty for the main unit
• 1-year warranty for the ORP Gold probe

Options

No additional options are specified in the user manual.

Product Usage Instructions

1. Ensure that the pool volume is set correctly to 120 m3.
2. Check that the pump flow is set to the recommended rate of 1.8
   l/h.
3. Install the Mini Dosing NPS according to the provided
   installation diagram.
4. Connect the ORP probe to the control panel.
5. Adjust the ORP set point on the control panel within the range
   of 200 to 900 mV.
6. Calibrate the ORP probe using the 1-point calibration
   method.
7. Monitor the digital display on the control panel for chlorine
   dosage information.
8. Ensure that the ORP Gold probe is covered by a 1-year
   warranty.

Mini Dosing®
Automatic chlorine dosage by ORP probe
Benefits · Digital display of ORP value · Integrated silent dosing pump · High quality ORP probe
Features · Chlorine dosage regulation by ORP probe · Adjustable ORP set point · Safeties: high and low ORP values, overfeeding · Easy installation and assembly

Model
Mini Dosing NPS

Pool volume (m3)
120

Pump flow (l/h)
1,8

Reference
DOOR20NPSB-G1

Technical specifications

Display Desinfectant dosage Smart injection ORP set point adjustment (mV) Calibration ORP probe ORP probe Control panel size (mm)

digital display liquid chlorine by ORP control 200 to 900 1 point 475 mV ORP Gold W 118 x H 231 x D 78

Installation diagram Cl

Content
· Control box · ORP probe Gold · ORP calibration solution 475 mV · Probe holder, injection connector · Paddle clamp x2 (diam 50 mm) · Power cable (2 m) · Wall support (with screws) · User manual

Options
· Measure chamber for ORP probe with connection kit

Warranties
2 Box
years
1 Probe
year ORP Gold
