Wall Range Hood, 36″, Box Chimney
User Guide
Wall Range Hood, 36″, Box Chimney
QUICK REFERENCE GUIDE > HC36DTXB2_N
Wall Range Hood, 36″, Box Chimney
Series 7 | Contemporary
Stainless Steel and GlassThe wall chimney range hood has contemporary styling, extracting steam, grease, and cooking odors quietly and efficiently.
- With four fan speeds, select the perfect extraction rate for your cooking
- Energy-efficient LED lighting to illuminate your cooking surface
- Powerful 600CFM maximum airflow
DIMENSIONS
| Height | 23 3/4 – 41 1/16″ |
| Width | 35 3/8″ |
| Depth | 19 11/16″ |
FEATURES & BENEFITS
Quiet and effective
This vent hood features four fan speeds providing powerful extraction to quickly remove odors and steam. As odors can linger in the kitchen well after cooking is finished, the timer keeps the vent hood working for up to 15 minutes before automatically turning off.
Simple controls
This Fisher & Paykel chimney range hood features a sleek and easy-to-use soft-touch control panel. This range hood’s LED lights provide bright, warm, energy-efficient lighting ensuring the entire cooktop surface is illuminated.
Easy cleaning
The black glass and stainless steel finish is easily wiped clean. Multi-layered, dishwasher-safe filters trap grease effectively and can easily be removed for cleaning.
Complimentary Design
This wall chimney vent hood’s sleek stainless steel finish will complement any contemporary kitchen and is designed to match the rest of Fisher & Paykel’s kitchen appliance family.
SPECIFICATIONS
Accessories
| Chimney extension | 791774 |
| Light bulb | 792579 |
| Recirculation carbon filter | 791772 |
| Recirculation diverter | 792580 |
Fan ratings
| Maximum sound rating | 67dBA |
| Speed 3 sound rating | 63dBA |
Installation and cleaning
| Air outlet size | 6″ |
| Dishwasher safe filters | 3 |
| Ducted | Top extraction |
| Recirculation | Optional – top extraction |
Performance
| Extraction type | Surface |
| Fan speeds | 4 |
| Filter type | Mesh |
| Number of filters | 3 |
Power requirements
| Depth | 19 11/16″ |
| Height | 23 3/4 – 41 1/16″ |
| Width | 35 3/8″ |
Product information
Control type…………………… Soft-touch
Ventilation features
Light type ………………….. LED
Warranty
Parts and labor……………………… 2 years
SKU…………………..50084
The product dimensions and specifications on this page apply to the specific product and model. Under our policy of continuous improvement, these dimensions and specifications may change at any time. You should therefore check with Fisher & Paykel’s Customer Care Centre to ensure this page correctly describes the model currently available. ? Fisher & Paykel Appliances Ltd 2020
Other product downloads are available at fisherpaykel.com
Data Sheet Wall Range Hood
