KEMPII SHELLBOX

Product Information

The AMT vaults are designed to provide excellent protection
performance for underground installations in the electrical,
energy, and telecommunication sectors. These vaults are made from
fully recycled polyethylene bags, and they are designed to meet the
highest demands of mechanical and environmental resistance. The
modular assembly of these vaults makes them easy to transport,
store, and install.

The AMT vaults offer high load capacity, flame retardant
protection, resistance to sunlight, abrasive wear, and a variety of
chemical agents. These vaults are made and tested under
international standards, ensuring their quality and reliability.
They also come with lateral cavities for better anchoring and
support, allowing walls up to 2 inches thick.

Product Usage Instructions

Place the lower frame on the floor.
Install one of the 60×60 cm square sidewalls on the frame using
a mallet.
Place one of the 60×90 cm rectangular side panels on the other
side of the frame, taking into account the coincidence of the
male-female assembly of its edges.
Install the other 60×60 cm square sidewall on top of the
previous panel using a mallet.
Place the other 60×90 cm rectangular side panel on top of the
frame, taking into account the coincidence of the male-female
assembly of its edges.
Finally, install the cover on top of the vault using galvanized
hexagonal screws and 2 1/2 screws. The cover comes with handles on
the sides for better handling and opening.

Note: The AMT vaults come with a high relief anti-slip surface
and a customization area with a logo. They also come in a variety
of colors according to requirements.

View Fullscreen

DESCRIPTION
AMT vaults are designed based on the highest demands of mechanical and environmental resistance, providing an excellent protection performance for underground installations in the electrical, energy and telecommunication sector. Its modular assembly facilitates transportation, storage and installation.
This product is made from recycled polyethylene bags, on strength of the commitment we have of contributing to the ecological balance.
Provides high load capacity, flame retardant protection, resistance to sunlight, abrasive wear, resistance to a variety of chemical agents, in addition to its design, made and tested under international standards.
CHARACTERISTICS
· · · · · · · · ·
· Manufactured with a modular body of low density polye-
thylene, fully recycled, while maintaining excellent resistance.
· It is recommended to be used in telecommunications,
energy, and electrical substations.
· The cover is secured with galvanized metal hexagonal
screws and has handles on the sides for better handling and opening.
· Self-extinguishing material, resistant to solar radiation
and abrasion.
· Provides protection against a wide range of chemical
agents such as: acids, ketones, solvents, gasses, water vapor, etc.
· Its modular design allows it to be easily transported,
stored and assembled.
· Withstands loads of up to 25 tons in compression and
tension.
· Optimum to be installed in different environments such
as sidewalks, gardens or vehicular streets with intense and heavy traffic.
· Structural design with lateral cavities provides greater
support and subterranean anchorage, allowing walls up to 2 inches thick.

Version: 00 Date: 21/02/2022
SB-KEMPII-SB

Version: 00 Date: 21/02/2022

Handle for cover lifting.

Customization area with logo.

Hexagonal screws for cover security.

High relief anti-slip surface.

Lateral cavities for better anchoring.

Variety of colors according to requirements.

TECHNICAL SPECIFICATIONS
··············

General register

Parameter

Value

Distributed load capacity

25 tons

Point load

17 tons

Fatigue strength

1000 cycles with 14.5 Kgf

Flexion

26 mm, 15 Tons

Manufacturing material

Low density polyethylene

Total weight (cover and register)

40.9 Kg

Width

53 cm

General dimensions

Length

63 cm

Height

55 cm

Low Density Polyethylene

Nomenclature (Spanish/English)

PEBD/PELD

Density

0.922 g/cm3

Breaking strain

20/20 Mpa

Elongation at breaking point DM/DT

380/910 %

Impact resistance

230 g/F50

NORMATIVITY AND STANDARDS
··············
ALT’s modular registers are manufactured in full compliance with the following standards, endorsed and certified by the Equipment and Materials Testing Laboratory LAPEM.

Version: 00 Date: 21/02/2022

Specification
Pedestrian/Light Duty ANSI/SCTE 77 TIER 15 ANSI/SCTE 77 TIER 22
Pedestrian/Light Duty AS3996-Class B AS3996-Class C
Pedestrian/Light Duty EN 124 Class B125 EN 124 Class C250

Test load

lbf

American

3000

22500

100

33750

150

APAC

3370

18000

33750

150

EMEA

2250

28100

125

56202

250

PARTS LIST
· · · · · ·
Part
Lower frame 60×55 cm side panels 50×55 cm side panels Top frame Cover Galvanized hexagonal screws 2 1/2″ screws

Quantity
1 piece 2 pieces 2 pieces 1 piece 1 piece 4 pieces 10 pieces

Code
MI-KEMPII-SB L60-KEMPII-SB L50-KEMPII-SB MS-KEMPII-SB
T-KEMPII-SB –

DIMENSIONAL SCHEME
· · · · · · · · · · ·
487

587

Version: 00 Date: 21/02/2022

Total height 550 Internal height 412

ExterioInrt6e3ri0or 548

Dimension
Width Length Height

Exterior
530 630 550

InterioExr t4e4r8ior 530

Interior
448 548 412

Unit
mm mm mm

ASSEMBLY STEPS
· · · · · · · ·

Version: 00 Date: 21/02/2022

Place the lower frame on the floor.

Install one of the 60×60 cm square sidewalls on the frame, using a mallet.

Place one of the 60×90 cm rectangular side panels on the other side of the frame, taking into account the coincidence of the male-female assembly of its edges.

Repeat the previous step with the same type of frame, alternating the assembly of the edges.

Install the last square side in such a way it fits correctly with the rest of the previously installed faces.

Install the top frame.

Place the 10 screws of 2 1/2″ to adjust the top frame to the side faces. The figure shows how to install.

Place the cover on the frame using the handles.

Finally install the 4 hexagonal screws in the corners of the cover.

ORDER CONFIGURATION
· · · · · · · · · · ·
SB-KEMPII-SB N/ C/ HT/ HTM

Version: 00 Date: 21/02/2022

N: Black

HT: Color on cover HTM: Color on cover and frame

C: Full color
