User Manual

Read me first

• Please read this manual before operating your tablet, and keep it for future reference.
• The descriptions in this manual are based on the default settings.
• Images and screenshots used in this manual may differ from the actual product.
• Available features and additional services may vary by device, software, or service provider.
• Our company is not liable for performance issues caused by third-party applications.

Assembling

Unpack

Check your product box for the following items.

• Mobile phone
• User manual
• Adapter

You can purchase additional accessories from your local retailer.

Charge the battery

Before using the device for the first time, you must charge the battery.

1. You can charge the device with a travel adapter or by connecting the device to a PC with a USB cable.
2. The battery full icon is shown when finished if your device is off.

Warning: Use only original batteries and chargers. Unapproved chargers or cables can cause batteries to explode or damage your device.

Install the SIM card

You need to insert a SIM card to use the Phone function. To install the SIM card, follow the instructions below.

1. Make sure that the card’s gold contacts face into the device.
2. Push the SIM card into the slot.

Install the memory card

To store additional multimedia files, you need to insert a memory card.

1. Insert a memory card with the gold contacts facing downwards.
2. Push the memory card into the slot.

Notice: Our company uses approved industry standards for memory cards, but some brands may not be fully compatible with your device.

Getting started

Turn your device on, rebootand off

To turn on your device, press and hold the power key.
To reboot your device, press and hold the power key, select “reboot”.
To turn off your device, press and hold the power key, select “power off”.

Switch to flight mode

To use only your device’s non-network services, switch to flight mode. Please follow the instructions below to turn on flight mode:
Tap Settings Network & internet Advanced Airplane mode from the application list to turn on flight mode.

Home screen

The home screen has multiple panels. Scroll left or right to the panels on the home screen, you can view indicator icons, widgets, shortcuts to applications, and other items.

Taskbar

The taskbar is shown at the top of the screen. It displays commonly used option buttons, battery level indicator, current time, and other indicator icons.

Indicator icons

Icon	Definition	Icon	Definition
	Open WiFi available		Flight mode activated
	WiFi connected		New email
	Signal strength		New text or multimedia message
	BT connected		Call in progress
	Uploading data		Missed call
	Downloading data		Call on hold
	Connected to PC		Call diverting activated
	Alarm activated		Battery power level
	Music being played		Don’t disturb
	Auto-rotate		Location
	Flashlight

Notification panel

Pull down to open the top of the notification bar to show the 6 users commonly used shortcut switch, support click on the switch, and long press to enter the corresponding settings. If you continue to pull down the notification bar to display all the quick switches, the fast switch in the lower right corner of the page will display an “Edit” button, click to add/delete custom shortcut switch, or drag the sort.
Tap icon to activate or deactivate wireless connection features and other settings. Wi-Fi: Activate or deactivate the Wi-Fi connection.

Bluetooth: Activate or deactivate the Bluetooth connection.
Notifications: Activate or deactivate the notification feature.
Flashlight: Activate or deactivate the Flashlight.
Auto-rotate screen: Activate or deactivate the auto-rotation feature.
Battery Saver: Activate or deactivate the Battery Saver.
Brightness: Adjust the basic brightness level of the display to lighter or darker.
Settings: Access Settings application.

Autorotation

If you rotate the device while using some features, the interface will automatically rotate as well. To prevent the interface from rotating, open the notifications panel and select Auto-rotate screen, then tap it to Off.

Lock & unlock the screen

Slide to unlock the screen.
To lock the screen manually, press the Power key.

Customize your device

To customize your device according to your preferences, tap Settings from the application list or notification panel.

Manage applications

To manage the applications installed on your device, tap Settings Apps& notifications.

1. To uninstall an application, select an item and tap UNINSTALL, tap OK to confirm.
2. To stop or change the settings of an application, select an item and tap the option you need.

Security

You can protect your device and data by setting a screen lock or encrypting your mobile phone.

Set a screen lock
To set a screen lock, tap Settings Security Screen lock from the application list.

• None: Deactivate the screen lock.
• Swipe: Slide to unlock the screen.
• Pattern: Draw a pattern to unlock. Follow the instructions to draw your lock When prompted, draw the pattern to unlock the screen.
• PIN: Enter a numeric PIN to unlock. When prompted, enter the PIN to unlock the
• Password: Enter a passcode to unlock. When prompted, enter the passcode to unlock the screen.

Screen time-out
Select Settings Display Advanced Screen timeout from the application list, you can set the time before the screen times out and goes into lock mode. ( you have not entered any characters or made other selections).

Set up the fingerprint

• Fingerprint: Want to use your fingerprint to unlock the screen or confirmation of purchase, you need to:
  1, set the standby screen lock mode;
  2, and add your fingerprint;

Attention: In addition to using fingerprint unlock their devices, you can also set the equipment before startup requires the user to unlock pattern, to further protect the equipment. Equipment starts, to answer the phone, receive a message, or notice (including an alarm clock). This can be in to protect the data on the equipment after the device is lost or stolen.

Display size

1. You can set it Settings Display Advanced Display size

Data Saver

1. You can set it Settings Network &internet Data usage Data Saver

Quick Switch

1. You can switch applications by simply double-clicking the “Recents” button

Reset mobile phone

You can reset system and desktop settings to their original values by the following steps:

1. Select Settings System  Advanced  Reset options from the application list.
2. Tap Erase all data (factory reset).
3. Tap Erase all data.
4. Tap Erase all data. The device resets to the factory default settings automatically.

Warning: Factory data reset will erase all data from your device, including your GoogleTM account, system and application data and settings, and downloaded applications.

Communication

Phone

To use calling functions, tap Phone from the application list.

♦ Make calls
To make calls, you can use any of the three ways:

• Enter numbers by using the virtual numeric keypad on the screen
• Make a call from the call log.
• Make a call from contacts.

Answer a call
To answer a call, Swipe up the screen.

Decline or end a call
To decline a call, Swipe down the screen.
To end a call in progress, tap the red button.

Call settings

To change call settings, tap the options button at the lower right below the dial-up interface.

1. Ringtone & Vibrate
   • You can set different ringtones for incoming calls. Settings Sound Select Phone ringtone to open a list of ringtones, select the desired ringtone, and then select OK to
   • Settings Sound Select Vibrate for calls to open the vibration function and the phone vibrates to notify you when a call is coming.
2. Dial pad touch tones
   Settings sound Advanced Dial pad tones you can open or close the Dial pad tones.
3. Voice mail
   With the call divert network service, you can direct incoming calls to your voice mailbox.
   Phone Settings Voicemail  Select SIM card
   Tap Service in Advanced Settings to set your voice mail service provider.
   Tap Setup in Advanced Settings to set your voice mail number.
   Tap Sound in Notifications Advanced Settings to set the desired ringtone for your voice
4. Fixed Dialling Numbers
   If FDN mode is activated, your device will restrict outgoing calls, except for the numbers stored in the FDN list.
5. Quick responses
   Quick response is a feature to reject the call with predefined messages.
   Tap one of the pre-written messages to be displayed when you want the call to be rejected, then tap OK.
6. Call forwarding
   Call diverting is a network feature to send incoming calls to another number that you specify.
7. Call waiting
8. If call waiting is activated, the network notifies you of a new incoming call while you have a call in progress or you can make a new call during a call.

Contacts

Tap Contacts from the application list to access contacts.

• All: List all your contacts saved in the device memory and SIM cards.
• Favorites: List the contacts that you have set as favorites or the contacts that you have sent message to or dialed.

Add new contact

1. Access Contact number.
2. Click
3. Enter necessary Contact name.
4. Click ✓.

Edit a contact

1. To edit a contact, select and click the contact you want to change.
2. Click the edit icon at the upper right.
3. Change necessary fields.
4. Click ✓.

Import/Export contacts

1. Import from the SIM card
   To import the contacts from the SIM card, click the options button at the upper left and then select Settings Import Select USIM Click OK SelectcontactsDClick ✓.
2. Import from MEMORY card
   To import contacts files (in vcf format) from a memory, tap the options button at the upper left and then select ImportnSelect .vcf file click OK nSelect .vcf file, and then the contacts will be imported to your device.

Search for contacts

1. Enter the desired information in the Search contacts input box, then your device shows the result.

Messaging

Learn to create and send a text or multimedia message, and view or manage messages that you have sent or received.

View messages

1. Click Messaging from the application list.
2. Click the message to view the detailed information.

Create and send SMS

1. Click enterNEW MESSAGE.
2. In the Type name or number field, enter the recipient’s mobile phone numbers manually. If you enter more than one number, separate the numbers with a comma.
3. In the Type text message field, enter the text of the message.
4. Click Send to send the message.

Create and send MMS

A multimedia message can include pictures, sound, and text.

1. Click enter NEW MESSAGE.
2. In the Type name or number field, enter the recipient’s mobile phone numbers manually. If you enter more than one number, separate the numbers with a comma.
3. Click Attach to Select one of the items below.
   • Pictures: Insert image.
   • Capture picture: Capture a new picture and insert the picture.
   • Videos: Insert videoclip.
   • Capture video: Capture a new video clip and insert the video clip.
   • Audio: Insert sound clip.
   • Record audio: Record sound clip and insert the sound clip.
   • Slideshow: Add more than one slide.
   • Contact: Insert contacts
   • Calendar: Insert Calendar
4. In the Type text message field, enter the text of the message.
5. ClickSend to send theMultimedia message.

Email

To receive and send mail, you must have a remote mailbox service. This service may be offered by a service provider. Your device is compliant with applicable internet standards for POP3/IMAP/Exchange.
Before you can send or receive mail on your device, you need to set up an email account and define the email settings correctly. You can define more than 1 mailbox.

Set up your email

1. Click Email from the application list.
2. You can use the mailbox guide to set up your mailbox, tap Next until it’s done.
3. If you need to add another email account, tap the options button at the upper left Settings Add account, then set up the email account with the mailbox guide.

When you are finished setting up the email account, the email messages are downloaded to your device. If you have created more than two accounts, you can switch between email accounts. Select an account name at the top left of the screen and select the one you want to retrieve messages from.

Delete your email account

ClickSettings from application list Users & account Click on the email address Click the “REMOVE ACCOUNT” button

Create and send email

1. Open Email application.
2. Click the write button.
3. In the To field, enter the recipient’s email addresses manually and separate them with a comma. Add more recipients by tapping Cc/Bcc.
4. Click to choose attachments that you want to insert.
5. Enter the subject and the text.
6. Click SEND button to send the email.

Web

Browser

Tap Browser from the application list to access the web.

Browser webpages

1. Select Browser to launch a specified homepage.
2. To access a specific webpage, select the URL input field, enter the web address of the webpage, and select

Set homepage

1. Tap the options button  at the upper right.
2. Select Settings General Set homepage.
3. Enter the web address of the desired webpage.

Add bookmarks

While navigating a website, click select “Save to bookmarks” to Save bookmarks and easily

access it later.

View bookmarks and history

Tap the options button at the upper right select “Bookmarks/History” to open the bookmark list and the recent history. Click a bookmark or any entry to display the webpage.

Customize browser

To make adjustments in your browser settings, click the options button at the upper right, and then select Settings.

Entertainment

Camera

With the camera function, you can capture photos and take videos.

Capture a photo

1. Open the application list and select
2. Before taking a picture, you need to know some settings.
   Place two fingers on the screen and spread them apart or move fingers closer together to zoom in or zoom out.

   Icon	Definition
   	Settings
   	Change to video mode.
   	take photos
   	Tap to switch between the front and rear camera lenses
   	Smile Mode
   	Change to panorama mode to take a landscape photo.

3. Aim the lens at the subject and tap to take a photo. The photo is saved automatically to the folder DCIM.=
4. Select the image viewer icon at the lower right to view the pictures.

Record a video

1. Open the application list and select camera. Tap to change to video mode.
2. Tap to start recording. The length of the video recording is restricted by the available space on your storage.
3. Tap to stop recording. The video is saved automatically to the folder DCIM.
4. After recording videos, select the image viewer icon at the lower right to view the recorded videos.

Tools

Calendar

With the Calendar feature, you can consult the calendar by day, week, or month, create events, and set an alarm to act as a reminder, if necessary.

To access the calendar, tap Calendar from the application list.

1. To create an event, tap the option button at the upper right and then select New event.
   • Fill in the fields, and set category, date, time & and alarm.
   • After you finish, select DONE.
2. You can view the calendar in different views, Day, Week, Month, and All.
3. To delete an entry, tap the event to open it tap the options button at the upper right, and then select Delete select OK

Alarm

From the application list, tap Clock, and then select .

1. Tap add an alarm.
   • Tap the numeric pad to set alarm time, and then select AM or PM, when you are finished, tap OK.
   • Tap the time to change alarm time.
2. Set repeat cycle, alarm ringtone, Vibrate, and edit Label message, tapOK after finished.
3. Tap “DISMISS” to shut down the alarm, and tap “SNOOZE”, then the alarm will stop ringing for a few minutes.
4. Tap the Arrow of one alarm and click to Delete this alarm.

File Manager

Many features of the device, such as images, videos, documents, received attachments, and download files or applications, use memory to store data. With File Manager, you can store and browse files and folders on your device, or edit, move, copy files; you can send files to compatible devices as well.

Note:

1. Some file formats are not supported depending on the software of the device.
2. Some files may not play properly depending on how they are encoded.

Sound Recorder

With Recorder, you can record a voice memo. From the application list, tap Sound Recorder.

1. To record a voice memo, tap .
2. To stop the recording, tap .
3. To listen to a voice recording that you just recorded, tap .

Calculator

With this feature, you can use the device as a calculator. The calculator provides the basic arithmetic functions. Tap the virtual numeric and calculation keys to perform a calculation.

Connectivity

USB Connection

You can connect your device to a PC and use it as a removable disk, which allows you to access the file directory.

1. If you want to transfer files from or to the device, insert a memory card into the device.
2. With a USB cable, connect your device to a PC.
3. Open the notification panel, Use USB to select Transfer files.
4. Open the folder to view files.
5. Copy files from the PC to the device memory or memory card.

Wi-Fi

With Wi-Fi, you can connect to the internet or other network devices anywhere an access point or wireless hotspot is available.

Activate the Wi-Fi feature

1. From the application list, tap Settings Network & internet, turn on the Wi-Fi feature.

Find and connect to Wi-Fi

1. Once the Wi-Fi feature is activated, the device automatically searches for available Wi-Fi
2. Select a network.
3. Enter a password for the network (if necessary).
4. Select Connect.

Bluetooth

With Bluetooth, you can share music, pictures, video, contacts with another phone. You can use a Bluetooth headset phone or listen to music.

Activate the Bluetooth feature

1. From the application list, tap Settings Connected devices Pair a new device.

Scan and connect to other Bluetooth devices

1. The device automatically searches for other Bluetooth devices.
2. Select a device and pair.

Safety Precautions

Read these simple guidelines before using your device. Not following them may be dangerous or illegal.

Aircraft
Switch off in aircraft and follow any restrictions. Wireless devices can cause interference in aircraft.

Vehicles
Never use your device while driving. Place it in a safe place.
Position your device within easy reach. Be able to access your device without removing your eyes from the road.

Electronic devices
In some circumstances, your device may cause interference with other devices.

Potentially explosive environments
Switch off your device when in any area with a potentially explosive atmosphere, and obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

Pacemakers and other medical devices
Pacemaker manufacturers recommend that a minimum separation of 8 inches be maintained between a wireless device and a pacemaker to avoid potential interference with the pacemaker.
Operation of any radio transmitting equipment, including wireless phones, may interfere with the functionality of inadequately protected medical devices. Consult a physician or the manufacturer of the medical device to determine if they are adequately shielded from external RF energy or if you have any questions.
Switch off your device in health care facilities when any regulations posted in these areas instruct you to do so.

Operating environment
When connecting to another device, read its user guide for detailed safety instructions. Do not connect incompatible products.
Do not place your device in the airbag deployment area.
Use the device only in its normal operating positions as explained in the product documentation.
Always switch off your device when its use is prohibited or when it may cause interference and danger.

Areas with posted regulations
Switch off your device when any regulations posted in these areas instruct you to do so.

Care & Maintenance

Use only manufacturer-approved accessories. Using general accessories may shorten the life of your device or cause the device to malfunction.
Keep your device dry. Humidity and all types of liquids may damage device parts or electronic circuits.
Do not use or store the device in dusty, dirty areas.
Do not store the device in hot or cold areas.
Do not store your device near magnetic fields.
Do not store your device with such metal objects as coins, keys, and necklaces.
Do not drop your device or cause impacts to your device.

Google is a trademark of Google LLC.

FCC Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

The device has been evaluated to meet general RF exposure requirements. The device can be used in portable exposure conditions without restriction.

Specific Absorption Rate (SAR) information:
This Tablet meets the government’s requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluations of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. FCC RF Exposure Information and Statement the SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: Tablet has also been tested against this SAR limit. This device was tested for typical body-worn operations with the back of the phone kept 0mm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain an 0mm separation distance between the user’s body and the back of the phone. The use of belt clips, holsters, and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements and should be avoided.
