QAZQA 105090 Dong Industrial Table Lamp
INSTRUCTION MANUAL
Dong TL 1 Bronze Black 105090
SAFETY INSTRUCTION
Please study the instruction manual and the below information carefully before installing or using this product. Please keep this user manual for further reference
- The luminaires may only be installed by authorized end qualified technicians according to the valid regulations for electrical installation.
- Maintenance of the luminaires is limited to their surfaces. During maintenance, no moisture can come into contact with any areas of the terminal connections or voltage control parts.
- The electrical supply must be switched off at the outset, preferably by means of a switch in the distribution box, before any installation, maintenance, or repair work is undertaken.
- Exterior lighting must not be installed during rain.
- Take account of the minimum separation distance from other objects and the room required around the fitting.
- If in any doubt, consult a professional, taking local installation requirements into account. Some countries stipulate that lighting may be installed only by registered installers.
- Clamping screws in electrical connections must be adequately tightened. This is particularly the case with 12V low voltage conductors.
- When replacing a halogen lamp, wait for it to cool, for a minimum of 5 minutes.
- Clean with a clean, dry cloth or brush, use no solvents or abrasives. Avoid dampness on all electrical components
- Take account of all available technical information.
- Take note of the symbols when connecting wires:
N =Neutral L =Live =Earth - Meaning of symbols:
For indoor use only, where direct contact with water is impossible
- Protection Closs I: the fitting must be earthed
- Protection Closs II: the fitting is doubled insulated and does not require earthing
- Protection Closs Ill: the fitting is low voltage
- Minimum distance from lighted objects (meters)
- Only the self-shielded halogen lamp should be used with the luminaire
- Strip the wire to the indicated length (mm);different items require different lengt
- Connect using the specified coble; different items require different cable
- The type of lamp and maximum size and wattage indicated in each lighting unit must not be exceed; different items require different kind of light sources with different bulb icons
- The armature is designed to work only with the indicated voltage. Different items require L.::J different working voltage.
- The luminoire can be used in combination with o dimmer
- The reference light angle and light space of the luminaire
- This luminaire cannot be disposed together with normal domestic waste in standard rubbish can, but you hove to bring it to o staging area for electrical waste.
FittinQ B.V
Smarcgdweg 52, 5527 LB Ha pert, The Netherlands www.qozqo.n
