Arebos Ar-he-hsspw Upright Vacuum Cleaner Instruction Manual (+ PDF)

Please follow all security measures mentioned in this user’s
manual to ensure a secure use of the vacuum cleaner. It is
important to read and understand the safety instructions provided
to avoid any potential injury or damage. Keep the operating
instructions in a safe place for future reference.

Assemble the Unit

Note: Ensure that the handheld vacuum cleaner is not connected
to the charger before assembling the Metal tube.

Take out the handheld vacuum cleaner, metal tube, and floor
brush.
Connect the floor brush with the extended tube. Insert the
extended tube into the floor brush until you hear a click,
indicating it is assembled correctly.
Assemble the battery by buckling it into the groove in the unit
and rotating it to lock it in place. To remove the battery, push
the battery button.

Using the Handheld Vacuum Cleaner

Note: Please ensure that the vacuum cleaner is not connected to
the charger before use.

The handheld vacuum cleaner can be used directly. The combined
crevice nozzle can also be used directly with the handheld vacuum
cleaner. If you have a connection converter, you can connect it
with other suitable brushes.
Press the power switch to turn on the vacuum cleaner. The
screen will display the logo, battery status, and current speed.
You can adjust the vacuum cleaner by touching the screen. The
screen indicates low speed, normal speed, and high speed.

Battery Status Indicator

Note: The battery status indicator light will blink when the
battery capacity is not enough. The battery status indicator has
four lights to indicate the battery capacity:

4 blue lights: battery capacity > 90%
3 blue lights: battery capacity 55% – 90%
2 blue lights: battery capacity 25% – 55%
1 blue light: battery capacity < 25%
1 blue blinking light: battery capacity empty

View Fullscreen

Original User Manual AREBOS Upright Vacuum Cleaner Premium
Upright Vacuum Cleaner
AR-HE-HSSPW
Please follow all security measures in this user’s manual to ensure a secure use.
Thank you for trusting in AREBO1S.

Original User Manual AREBOS Upright Vacuum Cleaner Premium
Thank you for purchasing our product. Please read the operating instructions carefully before using the product for the first time. If you give the product to a third party, this manual must be handed over with it. Keep the instruction manual for future reference. The drawings in this manual may not match the physical objects. Please refer to the physical objects.
Security Instructions
Explanation of the symbols By means of a CE marking, it can be recognized that a product complies with the legal requirements of European legal standards and therefore may be traded within the European Community.
This product must not be disposed of with household waste!
Warning! Read the safety instructions carefully. Failure to follow the safety precautions could result in serious injury or damage. Keep the operating instructions in a safe place.
Protective insulated housing (protection class II)!
Take special care when using this article.
Important Safety Instructions · Do not charge or use the appliance outdoors. · Arrange for repairs to be carried out only by specialist workshops. Under no circumstances should you open the appliance yourself. Interference that are not carried out by a specialist workshop could lead to physical injuries. · Before switching the hand vacuum cleaner on, ensure that the mains voltage corresponds to the voltage indicated in the technical data for the appliance. · Never touch the power supply or the appliance with wet or damp hands. · Do not use the adapter with an extension cable; connect the power adapter directly to a power socket.
2

Original User Manual AREBOS Upright Vacuum Cleaner Premium
To avoid the risk of injury: · Do not change any accessories while the appliance is switched on. · Do not use the hand vacuum cleaner for vacuuming up sharp objects or glass shards. · Never vacuum up burning matches, glowing ashes or cigarette butts. · Do not use the hand vacuum cleaner for vacuuming up chemical products, stone dust, gypsum, cement or similar particles. · Do not use the hand vacuum for vacuuming up liquid, water or similar particles. · This appliance is not suitable for use with inflammable and explosive substances or chemical and aggressive liquids. · Always store the appliance indoors. To prevent accidents, keep the appliance in a dry location when not in use. · Under extreme conditions, leaks in the battery cells may occur. In the event that battery fluid comes into contact with skin or eyes, the affected area must be rinsed off with water immediately. Contact a physician. · This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
Tips for safety · Use only accessory parts recommended by the manufacturer. · The adapter may not be used for other purposes. Never carry the wall holder or the adapter by the cable. Do not pull on the cable when you want to move the appliance. · Always grip the power plug to disconnect the adapter from the power supply. · Always be sure to keep the hand vacuum away from heating elements, ovens or other heated appliances and surfaces. · Always make certain that the ventilation slits are open. A blocked ventilation circuit can result in overheating and damage to the appliance. · This product contains rechargeable batteries. Do not throw the batteries into a fire and do not subject them to high temperatures. There is the risk of an explosion! · Take special care when using the hand vacuum on stairs. · Do not use the hand vacuum without the dust filter inserted. · Do not use the adapter for a different product and do not attempt to charge this appliance with a different charger than supplied with this appliance.
3

Original User Manual AREBOS Upright Vacuum Cleaner Premium
Overview of the appliance
1. Screen 2. Battery 3. Battery release button 4. Cover 5. Power switch 6. Dust container release button 7. Dust container 8. Dust container open button 9. Upper extension wand release button 10. Extension Tube 11. Extension tube release button 12. Roller brush 13. LED headlight 14. Motor brush 15. 2 in 1 dust brush 16. Wall changer base+ adapter

Model Input voltage/current Output voltage/current Protection Class

Technical Specification
AR-HE-HSSPW 100-240 V, 50/60 Hz 26.5V, 500mA II

Operation Instructions
Assemble the unit
Note: Ensure that the handheld vacuum cleaner is not connected to the charger before assembling the Metal tube. 1. take out of handheld vacuum cleaner, metal tube and floor brush. 2.Connect the floor brush with the extended tube. Please insert the extended tube into the floor brush You will hear the “click” when the extended tube is Assembled rightly.

Original User Manual AREBOS Upright Vacuum Cleaner Premium
3. Connect the floor brush with the extended tube. Please insert the extended tube into the floor brush. You will hear the “click” when the extended tube is Assembled rightly.
Assemble the battery As shown in the figure, the battery must buckle the groove in the unit. Then rotating to buckle it. Remove the battery to push the battery button.
5

Original User Manual AREBOS Upright Vacuum Cleaner Premium
Use the handheld vacuum cleaner
Note: Please take out of the charger before use the vacuum cleaner. If the vacuum cleaner is charging or low battery status, the vacuum cleaner will not work.
1. The handheld vacuum cleaner can be used directly. The combined crevice nozzle can be used with the handheld vacuum cleaner directly. If you have the connection converter, it can be connected with your other suitable brush.
2. Press the power switch, the vacuum cleaner is in low speed. The screen display LOGO, battery status and low speed. when touch the screen with hand, it can adjust the vacuum cleaner. indicate low speed, indicate normal speed, indicate high speed.
6

Original User Manual AREBOS Upright Vacuum Cleaner Premium
Battery status indicator
Note: The battery status indicator light will blink when the battery capacity is not enough. The battery status indicator is with 4 lights to indicate the battery capacity. 4 blue lights: battery capacity>90% 3 blue lights: battery capacity 55%~90% 2 blue light: battery capacity 25%-55% 1 blue light25% 1 blue blinking light: battery capacity -empty
Charging your vacuum cleaner
Note: The handheld vacuum cleaner will not work when it’s charging with charger. The screen display LOGO and battery status
1. Place the unit or handheld vacuum cleaner near an electrical power outlet and plug in the charger. 2. Connect the charger to the charging socket. The battery status indicator lamp will dynamically shine to indicate that the vacuum cleaner is property connected to the charger and that the unit is being charged 3. When it’s fully charged, all of the 4 lamps will light and will turn off 3 hours after it’s fully charged.
7

Original User Manual AREBOS Upright Vacuum Cleaner Premium
The wall charger base assemble As shown in the figure
Empty the dust container & dust filter Note: To get the best performance, empty the dust container and clean the dust filter after 5 cleanings. Push down the dust release button.
8

Original User Manual AREBOS Upright Vacuum Cleaner Premium
Clean the dust container & dust filter
Note: To get the best performance, empty the dust container and clean the dust filter after 5 cleanings. 1. Remove the handheld vacuum cleaner from the unit. 2. Press down the release button of dust container and then remove the dust container from the handheld vacuum cleaner as the following sketch
3. Take out the HEPA filter from HEPA cover directly. Wash the HEPA filter and HEPA cover with cold water, After HEPA filter and HEPA filter dry completely, Do not use a hair dryer to dry it. Air dry only.
9

Original User Manual AREBOS Upright Vacuum Cleaner Premium
Clean the floor brush rorating the rotating brush Release button and then take out the roating brush from the bottom of floor brush. Clean the hair and the thread. 1. As show in the figure, slide the release button.
H
2. As shown in the figure, rotate the cover and push out the roller.
CAUTION: The suction inlet must be open and free of any obstructions at all times. Otherwise, the motor will overheat and could be damaged. Note: it is recommended that the sponge & scouring pad filter will be replaced every three (3) to six (6) months depending on usage to ensure best performance of the vacuum cleaner. Please note: The dust filter is washable. It should, however, be replaced every three (3) to six (6) months depending on usage, to ensure best performance of your vacuum cleaner. Important: Make sure that dust filter has completely air dried before replace back in the handheld vacuum cleaner. Warning: Please remove the floor brush cleaner from the unit before cleaning the power floor brush.
10

Original User Manual AREBOS Upright Vacuum Cleaner Premium
Environmentally friendly disposal
Warning Danger of suffocation! Packaging material is dangerous for children. Never let children play with packaging material. Disposal and packaging
· The packaging of your unit consists of materials that are necessary to guarantee effective protection during transport. These materials are fully recyclable and therefore reduce the environmental impact. Dispose of the packaging in a bin for recyclable materials.
Disposal of old equipment · Old appliances must be disposed of in accordance with the guidelines and regulations of the local waste disposal authority. Check with your local administration for the address of the nearest recycling centre and deliver your appliance there.
The symbol of the crossed-out dustbin on a Waste electrical or electronic equipment indicates that it must not be disposed of with household waste at the end of its life. Collection points for waste electrical and electronic equipment are available free of charge in your area. You can obtain the addresses from your city or local government. You can find out about other return options created by us on our website www.arebos.de.
The separate collection of Waste electrical or electronic equipment is intended to enable the reuse, recycling or other forms of recovery of Waste electrical or electronic equipment and to avoid the negative consequences of disposal on the environment and human health.
Notes on battery disposal The symbol of the crossed-out dustbin on batteries or accumulators indicates that they must not be disposed of with household waste at the end of their service life. If batteries or accumulators contain mercury (Hg), cadmium (Cd) or lead (Pb), you will find the respective chemical symbol below the symbol of the crossed-out trash can. You are legally obliged to return old batteries and accumulators after use. You can do this free of charge in a retail store or at another collection point near you. Addresses of suitable collection points can be obtained from your city or local government.
Our customer service number: Tel. +44 (0) 208 068 5604 Fax: +49 (0) 931 4523 2799 / E-Mail: [email protected]
Office address: Canbolat Vertriebs GmbH · Gneisenaustraße 10-11 · 97074 Würzburg
Return address can be found in the imprint: https://www.arebos.de/impressum/
Revocation/Return
· Check the product for transport damage. Immediately report any damage to the transport company that delivered the product.
· Revocation/Return: Please note that the full purchase price can only be refunded if the returned goods are unused, new and in their original packaging.
11

Original User Manual AREBOS Upright Vacuum Cleaner Premium

Declaration of Conformity EU

We, the

Canbolat Vertriebs GmbH, Gneisenaustraße 10–11, 97074 Würzburg, Germany

hereby declare that the equipment described below, by virtue of its design and construction and in the versions placed on the market by us, complies with the relevant essential health and safety requirements of the EU directives.

Name of the product: AREBOS Upright Vacuum Cleaner Premium Model number: AR-HE-HSSPW Article number: 4260627423989

Should the appliance be modified without our consent, this declaration of conformity will lose its validity.

Verified acc. to: Standard EU: EN 60335-2-2:2010+A11:2012+A1:2013 EN 60335-1:2012+A11:2014 EN 62233:2008 (EMC) 2014/30/EU EN55014-1: 2006+A1: 2009+A2: 2011 EN 55014-2: 1997+A1: 2001+A2: 2008 EN 55014-2: 2015 EN 61000-3-2: 2014 EN 61000-3-3: 2013 2011/65/EU (ROHS)

Date/Manufacturer Signature/Location:

Würzburg, 09.03.2022

Signature: Dipl.-Inform. (Univ.) Korhan Canbolat, Managing Director
Representative of these instructions for use/technical data: Dipl.-Inform. (Univ.) Korhan Canbolat, Managing Director
Office address: Canbolat Vertriebs GmbH Gneisenaustraße 10-11 D-97074 Würzburg
Return address can be found in the imprint: https://www.arebos.de/impressum/ VAT identification number: DE 263752326 Court of the Commercial Register is Würzburg, HRB 10082 WEEE Reg.-No. DE 61617071
