Assembly Instructions
43020904 3 SECTION GARMENT RACK
MAXIMUM TOTAL LOADING WEIGHT: 23KG (10KG FOR THE UPPER RAIL, 5KG FOR THE LOWER RAIL & 8KG FOR THE BOTTOM).
Hardware list
 | a | Screw | 12PCS |
 | b | Gasket | 10PCS |
 | c | Gasket | 4PCS |
 | d | Wheel | 2PCS |
 | e | Wheel | 2PCS |
 | f | Spanner | 1PC |
 | Tool Required Screw Driver (Not Provided) |
DO NOT TIGHTEN THE SCREWS UNTIL THE PRODUCT IS FULLY ASSEMBLED. FOR INDOOR USE ONLY.
 |  |  |
