Dreo Dr-hsh005 Oil Filled Heater User Guide

DR-HSH005 Oil Filled Heater

Product Information: Oil-Filled Heater

The DREO Oil-Filled Heater is a household electrical appliance
designed to provide warmth and comfort during cold weather. It is
manufactured by Shenzhen Hesung Innovation Technology Co., LTD in
China, and the model number is DR-HSH005. The heater comes with a
user guide and can be registered for warranty extension by scanning
the QR code or visiting dreo.com/warranty. For any expert support,
customers can contact DREO at [email protected].

Product Usage Instructions

Before using the DREO Oil-Filled Heater, it is important to read
and follow all safety instructions provided in the user guide. Here
are some usage instructions:

  1. Place the heater on a flat and stable surface, away from
    combustible materials like furniture, bedding, and curtains. Keep
    them at least 3 feet (0.9 m) away from the front of the heater and
    away from the sides and rear.
  2. Plug the heater directly into a wall outlet/receptacle. Never
    use an extension cord or relocatable power tap (outlet/power
    strip).
  3. Turn on the heater by using the controls provided on the unit.
    Always turn off the heater and unplug it when not in use.
  4. Do not use the heater outdoors, in bathrooms, laundry areas, or
    other indoor locations where it may fall into a bathtub or other
    water container.
  5. Avoid touching hot surfaces of the heater with bare skin. Use
    the handle provided when moving the heater.
  6. Do not insert foreign objects into any ventilation or exhaust
    opening of the heater as this may cause electric shock, fire, or
    damage to the unit.
  7. Do not use the heater on soft surfaces like a bed, where
    openings may become blocked.
  8. If the cord or plug is damaged or the heater malfunctions, do
    not operate it. Discard the heater or return it to an authorized
    service facility for examination and/or repair.
  9. Always use the heater as described in the user guide. Any other
    use not recommended by the manufacturer may cause fire, electric
    shock, or injury to persons.
  10. Extreme caution is necessary when using the heater around
    children or invalids and whenever the heater is left operating and
    unattended.

By following these instructions, customers can safely and
effectively use the DREO Oil-Filled Heater for their heating
needs.

Oil-Filled Heater
User Guide

[email protected]
MANUFACTURER Shenzhen Hesung Innovation Technology Co., LTD ADDRESS Yousuowei Building, Jiaxian Road, Shenzhen, China

MODEL: DR-HSH005 [email protected]

Thank You
for Choosing Dreo !

We

hope

you

Your support means the enjoy our oil – filled heater

world to as much

us as

.
we

did

creating

.

Scan or visit dreo.com/warranty
to extend your warranty by registering your product. If you need any help, don’t hesitate to email us to get expert support!
Email: [email protected]

CONTENTS
IMPORTANT SAFETY INSTRUCTIONS ————————-01 USING YOUR HEATER————————————————–06
Package Contents——————————————————07 Product Diagram ——————————————————–07 Caster Setup ————————————————————-08 LED Display —————————————————————10 Control Panel ————————————————————10 Remote Control———————————————————-11 Operations and Functions ——————————————12 Other Features ———————————————————-14 Replacement of Batteries in Remote Control —————–15 Specifications ————————————————————16 CLEANING AND MAINTENANCE ———————————–17 TROUBLESHOOTING—————————————————- 19 WARRANTY AND SERVICE——————————————-22

01
IMPORTANT SAFETY INSTRUCTIONS
Oil-Filled Heater

1

Thank you for choosing DREO Oil Filled Heater. Please read this User Guide thoroughly before use and keep it for future reference.
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL SAFETY INFORMATION AND INSTRUCTIONS. KEEP FOR FUTURE REFERENCE. FOR HOUSEHOLD USE ONLY
When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following:
Read all instructions before using this heater.
This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provided, use the handle when moving this heater.
Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9 m) from the front of the heater and keep them away from the sides and rear.
Extreme caution is necessary when any heater is used by or near children or invalids and whenever the heater is left operating and unattended.
Always unplug heater when not in use.
2

Do not operate any heater with a damaged cord or plug or after the heater malfunctions, has been dropped or damaged in any manner. Discard heater, or return to authorized service facility for examination and/or repair.
Do not use outdoors.
This heater is not intended for use in bathrooms, laundry areas and similar indoor locations. Never locate heater where it may fall into a bathtub or other water container.
Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings. Do not route cord under furniture or appliances. Arrange cord away from traffic area and where it will not be tripped over. To disconnect heater, turn controls to off, then remove plug from outlet.
Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric shock or fire, or damage the heater.
To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not use on soft surfaces, like a bed, where openings may become blocked.
A heater has hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint, or flammable liquids are used or stored.
Use this heater only as described in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock, or injury to persons.
Always plug heaters directly into a wall outlet/receptacle. Never use with an extension cord or relocatable power tap (outlet/power strip).
3

A loose fitting outlet can cause the plug to overheat or cause a fire. Be sure plug fits tight in the outlet.
If there is a loose fit between the plug and the socket or the plug becomes very hot, the socket may need to be replaced. Check with a qualified electrician to replace the socket.
It is normal for the plug and cord to feel warm to the touch. A plug or cord which becomes hot to the touch or becomes distorted in shape may be a result of a worn electrical outlet. Worn outlets or receptacles should be replaced prior to further use of the heater. Plugging the heater into a worn outlet / receptacle may result in overheating of the power cord or fire.
The output of this heater may vary and its temperature may become hot enough to burn exposed skin. Use of this heater is not recommended for persons with a high sensitivity to heat or an inability to react to avoid burns. should be replaced prior to further use of the heater. Plugging the heater into a worn outlet / receptacle may result in overheating of the power cord or fire.
Ensure the heater is on a stable, secure surface to eliminate the potential of tipping it over.
Make sure that no pieces of polystyrene or other packaging material have been left between elements of the appliance. It may be necessary to pass over the appliance with a vacuum cleaner.
Do not attempt to modify or repair the product by yourself. Doing so could void the warranty and cause damage or personal injury. Only a repair technician may disassemble or repair this product.
4

Choking hazard ­ This remote control unit contains a small battery. Keep the remote control away from children and do not swallow the battery. If the battery is swallowed seek medical advice at once. If the machine is not working as it should, has received a sharp blow, has been dropped, damaged, left outdoors, or dropped into water, do not use and contact Customer Support.
NOTE: There may be a trace of smoke or odor when the unit is first operated. This indicates that a drop of oil fell on the heating coil during the manufacturing process. It will quickly evaporate and should not re-occur.
IMPORTANT – This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to rig this safety feature.
DANGER – High temperatures may be generated under certain abnormal conditions. Do not partially or fully cover or obstruct the front of this heater.
READ AND SAVE THESE INSTRUCTIONS
5

02
USING YOUR HEATER

Package Contents
1 x Oil-Filled Heater 1 x Remote Control 4 x Casters 1 x Thank You Card 1 x User Guide
Product Diagram

Handle

LED Display Control Panel

Fins

Oil-Filled Heater

Power Cord and Plug

Caster Assemblies

6

7

Caster Setup Instructions
The heater is packaged with the casters unattached. You must attach them before operating the heater to prevent the heater from tipping over. The casters are inside the foam at the bottom of the package.
1
Place the heater upside down and extend the caster supports outwards.

3
Set the heater upright and plug in.

2
Align four casters with the mounting holes and press them into the holes.
8

Tip-over hazard. Do not operate without the casters attached.
Fire hazard. Operate the heater in the upright position only. Any other position can cause damage to this heater and even a fire hazard.
9

LED Display

Temperature/Time

Heating Status

F

Timer

Heat Mode
Control Panel

Fahrenheit
Power Status Child Lock Hour

Decrease Temperature/ Time
Timer

Increase Temperature/ Time
Heat Mode

Remote Control

Mute
Temp/Time Timer

Power On/Off Mode Temp/Time +
ECO Mode

Power On/Off

10

11

Operations and Functions
Place the heater on a firm, level surface free from obstructions, and at least 3ft. (0.9m) away from any wall or combustible materials. Plug into an appropriate voltage AC 120V outlet, The unit will enter standby mode with a beep and power indicator on red. Your heater is ready for use now.

Power ON/OFF

When the unit is plugged in, press on the heater

/ remote control to turn the heater on with default

settings: 95°F and high mode (

) on the

LED display.

Press once again to turn the heater off.

Mode / Heat Level Settings

When the unit is on, repeatedly press

on the

heater to cycle through High -> Medium -> Low -> ECO

modes, OR simply press

or

on the remote

control for mode switch.

ECO Mode
When ECO mode is on, the heater will adjust the working mode automatically based on the ambient temperature.

Mute/Unmute

Press on/off.

on the remote control to turn the buzzer

12

Temperature Adjustment

When the unit is on, press or on the heater / remote control to adjust the set temperature from 40 to 95°F in 1°F increments.

Note:

When the ambient temperature reaches the set temperature, the heating element will stop running and the indicator will go off.
after the unit is turned off, the heater will continue radiating heat for a while because of the unique properties of diathermic oil.

When the ambient temperature is lower than the set temperature, the heater will start running again.

Timer
When the unit is running, press on the heater / remote control to enter timer setting.

Press press

or to select a time (00h-24h) and again to start the timer.

When the timer ends, the heater will automatically shut off and go into standby. Note: 1. If you set the timer when the unit is on standby, the heater will automatically start running when the timer ends.
2. Press the power button to end the timer immediately.

Child Lock

When the unit is on, hold

and

at the

same time for 2 seconds to enable/disable Child

Lock.

Note: 1. All the buttons will be locked when Child Lock is enabled. 2. Child Lock is not applicable to the remote control.

13

Other Features

Memory Function

If you turn off the heater and keep it connected to the power source, the heater will return to its last status (working mode & temperature) once turned on again.

Note: not applicable to timer, mute, eco mode and child lock settings.

When the ambient temperature is above 122°F, the heater will stop heating, with 10 beeps and the error code “FF” flashing on the Overheat display. Protection Please unplug it from the power source and power it on again when the ambient temperature drops below 122°F.

When the heater is tipped over, the heater will shut off automatically. Tip-over Protection Please place the heater back on a flat, level and stable surface. Turn it on again.

Display Auto-
Dimming

The display will go dim automatically after 60 seconds if no action is taken by the user.

14

Replacement of Batteries in Remote Control
1. Remove the battery cover in the direction indicated by the arrow.
2. Replace with two new AAA 1.5 batteries. Make sure that the positive(+) and negative(-) terminals are positioned correctly.
3. Push the battery cover back into place.
CAUTION: Replace with new batteries of the same type when replacement is required. Remove the batteries when the remote control is unused for long period of time. Do not attempt to dismantle the batteries. Do not dispose the batteries in fire, batteries may explode or leak.
15

Specifications

Model Input
Rated Power
Remote Control Battery

DR-HSH005 120V~ 60Hz 1500W (High) 900W (Medium) 600W (Low)
AAA 1.5V

16

03 CLEANING AND MAINTENANCE
Oil-Filled Heater
17

Cleaning and Maintenance
It is recommended that the heater be cleaned at least one time during the operating season and before off-season storage in order to provide the optimum level of performance. Always disconnect the appliance from the mains by switching it off and removing the plug from the power outlet before cleaning.
Turn the heater “OFF”, unplug it and wait for the heater to cool down. Use only a soft cloth to gently wipe the outer surfaces of the heater clean. Do not use any cleaning agents or detergents. Never immerse the heater in water and never allow water to drip into the motor housing. Be sure not to wet the heating element and the switches. For storage, you may leave the heater covered to protect it from dust. Store it in a cool, dry location and arrange the cable away from traffic areas so that it will not be tripped over or damaged.
Caution:
Do not allow water to run into the interior of the heater as this could result in a fire or electric shock hazard. Any other servicing should be performed by an authorized service representative.
18

04
TROUBLESHOOTING
Oil-Filled Heater
19

Troubleshooting

The following troubleshooting guide addresses the most common problems. If your problem is not listed or still persists, please contact our Customer Support at [email protected].

Problem Possible Causes

Solution

E2 – Temperature sensor short circuit

Malfunction

E1 – Temperature sensor open circuit

Codes on LED

Display

FF – Overheat Protection (Ambient temperature above 122°F)

Unplug it from the power source and contact Customer Support.
Unplug it from the power source and contact Customer Support.
Unplug it from the power source and power it on again when the ambient temperature drops below 122°F.

Heater does Power cord is not

not start

properly plugged in.

Connect the plug to a powered electrical outlet.

20

Heater does not start

Overheat Protection has been activated.
No power is passing through the unit.

Turn the heater OFF, unplug it and allow it to cool.
Check and remove any objects on or adjacent to the heater.
Wait 5-10 minutes before plugging the unit back in.
Ensure that your circuit breaker or fuse is working properly.
Ensure your heater is placed on a flat and even surface.

Make sure the

The set temperature thermostat is set at

is lower than the

a higher temperature

ambient temperature. than the ambient

temperature.

Turn off the unit and

The heater suddenly stops

The temperature exceeds the threshold of the thermal cutoff.

unplug it from the power outlet. Allow it to cool, and then plug it into the electrical

during heating

outlet again.

The heater is tipped Place it on a flat, level

over.

and stable surface.

21

05 WARRANTY AND SERVICE
Oil-Filled Heater
22

Warranty and Service
Default 12-Month Warranty This product is covered with DREO product and labor warranty for 12 months from the date of its original purchase.
Extend Your Warranty Extend your warranty by registering your new product on our website https://dreo.com/warranty.
The warranty will not apply in cases of:
Accident, misuse, or repairs performed by unauthorized personnel. Any unit that has been tampered with or used for commercial purposes. Normal wear and tear of wearable parts. Use of force, damage caused by external influences. Damage caused by non-observance of the User Guide, e.g. connection to an unsuitable mains supply or non-compliance with the instructions. Partially or completely dismantled appliances. Defects caused by or resulting from damages from shipping or from repairs, service, or alteration to the product or any of its parts that have been performed by a repair person not authorized by DREO.
We can only provide after-sales service for products that are sold by DREO or DREO authorized retailers and distributors. If you have purchased your unit from a different place, please contact your seller for return and warranty issues.
23

Customer Support
We’re Here to Help! If you encounter any issues or have any questions regarding your new product, please contact our helpful Customer Support Team. Your satisfaction is our goal!
Email: [email protected] * Please have your order confirmation number ready before
contacting Customer Support.

MADE IN CHINA

E190384

24
