Philips 55pus6754 4k Uhd Smart Tv User Manual

Philips 55PUS6754 4K UHD Smart TV

Technical Specifications

Ambilight

• Ambilight Version
• 3- sided

Picture/Display

• Display
• 4K Ultra HD LED
• Diagonal screen size (metric) 139 cm
• Diagonal screen size (inch) 55 inch
• Panel resolution
• 3840 x 2160
• Aspect ratio
• 16:9
• Picture enhancement
  • Micro Dimming
  • Pixel Precise Ultra HD
  • Ultra Resolution
  • 1200 PPI
• Diagonal screen size (inch) 55 inch

Supported Display Resolution

Computer inputs on all HDMI up to 4K UHD 3840 x 2160 @60 Hz Video inputs on all HDMI

• up to 4K UHD 3840 x 2160 @60 Hz
• HDR supported
• HDR10/HLG (Hybrid Log Gamma)
• HDR10+/Dolby Vision

Smart TV Features

User Interaction

• SimplyShare
• Wi-Fi Miracast Certified*

Interactive TV HbbTV Programme

• Pause TV
• USB Recording*

SmartTV apps*

• Online Video Stores
• Open Internet Browser
• TV on Demand
• YouTube

Ease of Installation

• Auto-detect Philips devices
• Network installation wizard
• Settings assistant wizard

Firmware upgradeable

• Firmware auto upgrade wizard
• Firmware upgradeable via USB
• Online firmware upgrade

Screen Format Adjustments

• Advance – Shift
• Basic – Fill Screen
• Fit to Screen
• Zoom, Stretch
• Widescreen

Philips TV Remote app*

• Apps
• Channels
• Control
• NowOnTV
• TV Guide
• Video On Demand

Ease of Use

• One-stop Smart Menu button
• On-screen User manual

Processing

• Processing Power
• Quad Core

Tuner/Reception/Transmission Digital TV

DVB-T/T2/T2-HD/C/S/S2 MPEG Support

• MPEG2
• MPEG4

Video Playback

• NTSC
• PAL
• SECAM

TV Programme guide*

• 8-day Electronic Programme Guide Signal strength indication
• Yes
• Teletext
• 1000 page Hypertext
• HEVC support
• Yes

Connectivity

• Number of HDMI connections
  • 3
• Number of USBs
  • 2
• Number of components in (YPbPr)
  • 1
• Wireless connections
  • Wi-Fi 802.11n 2 x 2 integrated
  • Dual Band

Other connections

• Satellite Connector
• Common Interface Plus (CI+)
• Digital audio out (optical)
• Ethernet-LAN RJ-45
• Audio L/R in
• Headphone out

HDMI features

• Audio Return Channel
• 4K

EasyLink (HDMI-CEC)

• Remote control pass-through
• System audio control
• System standby
• One touch play

HDCP 2.2
Yes on all HDMI Numbers of CVBS 1

Multimedia Applications

Video Playback Formats

• Containers: AVI, MKV
• H264/MPEG-4 AVC
• MPEG-1
• MPEG-2
• MPEG-4
• WMV9/VC1
• HEVC (H.265)
• VP9

Subtitles Formats Support

• SMI
• SRT
• SUB
• TXT
• ASS

Music Playback Formats

• AAC
• MP3
• WAV
• WMA (v2 up to v9.2)
• WMA-PRO (v9 and v10)

Picture Playback Formats

• JPEG
• BMP
• GIF
• PNG
• 360 photo
• HEIF

Power

Mains Power

• AC 220 – 240 V 50/60 Hz
• Ambient temperature
• 5°C to 35°C
• Standby power consumption
• <0.3 W
• Power Saving Features
  • Auto switch-off timer
  • Picture mute (for radio)
• Energy Label Class
  • A+
• EU Energy Label power
  • 85 W
• Annual energy consumption
  • 125 kW·h
• Mercury content
  • 0 mg
    Presence of lead
  • Yes*
• Off-mode power consumption
  • N/A W

Sound

• Output power (RMS)
• 20 W
• Sound Enhancement
  • Auto Volume Leveller
  • Dolby Atmos®
  • 5 Band Equalizer
  • A.I. Sound
  • Bass Enhancement
  • Clear Dialogue
• Speaker configuration
• 2 x 10 W full-range speaker

Dimensions

• Box width
  • 1360.0 mm
• Box height
  • 860.0 mm
• Box depth
  • 160.0 mm
• Set Width
  • 1236.6 mm
• Set Height
  • 723.6 mm
• Set Depth
  • 79.9 mm
• Set width (with stand)
  • 1236.6 mm
• Set height (with stand)
  • 742.0 mm
• Set depth (with stand)
  • 261.0 mm
• Stand depth
  • 261.0 mm
• Stand height
  • 18.4 mm
• Stand width
  • 790.0 mm
• Adjustable stand width (Min.)
  • 700.0 mm
• Adjustable stand width (Max.)
  • 1036.0 mm
• Product weight
  • 16.1 kg
• Product weight (+stand)
  • 16.3 kg
• Weight incl. Packaging
  • 20.5 kg
• VESA wall mount compatible
  • 300 x 200 mm
