BF6 Smartphone
TECNO BF6 User Manual (C)
Product Information
- Front camera
- Volume + key
- Volume – key
- Power key & side fingerprint sensor
Product Usage Instructions
SIM/SD card installation
- Power off your mobile device.
- Refer to the provided picture for SIM/SD card
installation.
Charging the phone
You can charge your device using a charger or by connecting it
to the computer using a USB cable (comes with the phone).
- Ensure the correct orientation of the plug when connecting the
charger. - Use only TECNO charger and cables. The use of other chargers or
cables may damage the device and invalidate your phone
warranty.
FCC Caution – Labelling Requirements
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
- This device may not cause harmful interference.
- This device must accept any interference received, including
interference that may cause undesired operation.
Information to the user: Any changes or modifications not
expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
Specific Absorption Rate (SAR) information: This mobile phone
meets the government’s requirements for SAR.
TECNO BF6 User Manual (C)
Explosion diagram specification
1 FL(CTP+LCM) 3 FRONT_CAM_RUBBER 5 BACK_CAM_CON_FOAM 7 BACK_CAM_2 9 RECEIVER 11 LOWER_A_HOUSING 13 BACK_CAM_LENS_1 15 DECO_LENS 17 LOWER_B_HOUSING 19 FINGERPINT_MODULE 21 EARPHONE_RUBBER 23 SUB_PCB 25 MOTOR 27 BATTER 29 SPK_FPC
2 UPPER_HOUSING 4 FRONT_CAM 6 BACK_CAM_1 8 MAIN_PCB 10 FRONT_CAM_CON_FOAM 12 BATTERY_HOUSING 14 BACK_CAM_LENS_2 16 KATUO 18 LCD_50BTB_RUBBER 20 RF_CABLE 22 LCD_30BTB_RUBBER 24 USB_RUBBER 26 SIDEKEY_FPC 28 SPEAKEY
1
Know your phone
1. Front camera 2. Volume + key 3. Volume – key 4. Power key & side fingerprint sensor
2
SIM/SD card installation
1. Power off mobile. 2. Refer to the following picture for SIM / SD card
installation.
3
Charging the phone
You can charge your device using a charger or by connecting it to the computer using a USB cable (comes with the phone). 1. Please remind the front and back of the plug. 2. Use only TECNO charger and cables. Other chargers or
cables may damage the device. This will invalidate your phone warranty.
4
FCC Caution
Labelling requirements.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
Information to user. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Information to the user. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help.
Specific Absorption Rate (SAR) information: This mobile phone meets the government’s requirements for
5
exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. FCC RF Exposure Information and Statement The SAR limit of USA (FCC) is 1.6W/kg averaged over one gram of tissue. Device types: BF6 (FCC ID: 2ADYY-BF6) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for use at the ear is 1.17 W/kg and when properly worn on the body is 0.58 W/kg. Body-worn Operation This device was tested for typical body-worn operations. To comply with RF exposure requirements, a minimum separation distance of 1.0 cm must be maintained between the user’s body and the handset, including the antenna. Third-party belt-clips, holsters, and similar accessories used by this device should not contain any metallic components. Body-worn accessories that do not meet these requirements may not comply with RF exposure requirements and should be avoided. Use only the supplied or an approved antenna.
