404521 Cat.6 U/UTP Installation Cable,
LSZH, 100m
User Guide
Product Images
Short Description
23AWG
Copper Clad Aluminum (CCA)conductor
Low Smoke Zero Halogen (LSZH/LSOH)
RoHS compliant
CPR Certified, Class Eca
Color: RAL 7047 (Grey)
Performance: 250MHz
Package: PE Wrapped
Description
The equip® Installation Cable is made of preeminent materials and thoroughly examined to meet or surpass industrial standards. The solid installation cable is aimed to offer sturdy wide-ranged cable deployments, including 1000BASE-T Gigabit Ethernet and 100BASE-TX Fast Ethernet.
Additional Information
| Approval and compliance | Approval and compliance RoHS |
| Conductor material | CCA |
| Conductor size (AWG) | 23AWG |
| Conductor type | Solid |
| Jacket material | LSZH |
| Category | Cat.6 |
| Shielded | No |
| Product weight (kg) | 2,67 |
| Product breadth (mm) | 6,4 |
| Product depth (mm) | 6,4 |
| Product height (mm) | 100000 |
| Cable length | 100M |
| Color | Grey |
| EAN | 4.02E+12 |
| Model number | 404521 |
| Package contents | 404521 |
| Cable Length | 100m |
| Shielding | U/UTP |
