RC-CC1310-915-H Ultra Low Power Sub 1GHz Multichannels Radio Transceiver
Product Information
The RC-CC1310-915-H module is an ultra low power sub 1GHz
multichannel radio transceiver based on the Texas Instruments
CC1310F128 component. It combines a flexible RF transceiver with a
powerful 48 MHz Cortex M3 microcontroller, supporting multiple
physical layers and RF standards.
This module is designed for long-range operations and is ideal
for Internet of Things (IoT) applications. It has a sensitivity
parameter of -110dBm at data rates of 50 kbps and down to -124dBm
at a data rate of 0.625kbps. It can overcome interference from
other wireless communications with 90dB of blocking, ensuring
robust signaling for long-range communications.
The RC-CC1310-915-H module is compatible with
SimpleLink-Easylink, an ultra-low power platform designed by Texas
Instruments for easy implementation of long-range connectivity with
low power consumption in IoT projects. It also supports the TI-15.4
Stack, an IEEE802.15.4e/g standard-based star networking software
designed for long-range and robust star networks. Additionally, it
is compatible with 6LoWPAN systems and can be used with the open
platform Contiki.
Some key features of the RC-CC1310-915-H module include:
- Support for IEEE 802.15.4g mode switch
- Smart Grid and Automatic Meter Reading
- Ultra Low consumption technology
- Home and Building Automation
- Powerful ARM Cortex M3 microcontroller
- Wireless Sensor Network
- Supported by the open platform Contiki 6LoWPAN
- Very small size
For more detailed technical information, please refer to the
CC1310 Texas Instruments datasheet.
Product Usage Instructions
1. Power Supply:
- Ensure the operating voltage is within the range of 1.8V to
3.8V.
2. Radio Modes:
- RX Mode: The module operates in receive mode. Ensure the supply
current is within the specified range. - TX Mode: The module operates in transmit mode. Ensure the
supply current is within the specified range. - Standby Mode: The module is in a low-power standby mode. Ensure
the supply current is within the specified range. - Shut Down Mode: The module is powered off. Ensure the supply
current is within the specified range.
3. Frequency Band:
- The module operates in the specified frequency band. Ensure the
operative frequency band is appropriate for your application.
4. RF Power Output and Sensitivity:
- Ensure the RF power output and sensitivity are within the
specified ranges for reliable communication.
5. Data Rate:
- Select the appropriate data rate (50kbps or 625bps) based on
your application requirements.
6. Operating Temperature:
- The module can operate within the specified temperature range.
Ensure the operative temperature is suitable for your
application.
Note: Radiocontrolli s.r.l refuses any responsibility for
irregular uses of the devices and for any possible lack or
inaccuracy of the data. The company reserves the right to change
the information without notice.
For more information and support, visit the Radiocontrolli website.
RRCC–CCCC11130110–S9P1I5-4-H34
Radio
ontrolli
Wireless Modules
Ultra Low Power sub 1GHz Multichannels Radio Transceiver
The RC-CC1310-915-H module is based on Texas Instruments CC1310F128 component. This device combines a flexible, very low power RF transceiver with a powerful 48 MHz Cortex M3 microcontroller in a platform supporting multiple physical layers and RF standard.
Sub-1Ghz technology is becoming one of the chief driving forces behind the Internet of Things (Iot), in particular this type of module is ideal for this applications basically for the following reasons :
Ultra low power consumption, the consumption of this device is 5.5mA when receiving and 23.5mA when transmitting, in sleep mode the consumption is 0.6µA (microamps).
Long range operations, the sensitivity parameter is -110dBm at data rates of 50 kbps and down to -124dBm when the data rate is 0.625kbps. Interference from other wireless communications can be overcome with 90dB of blocking.
All this ensure a robust signaling for long range communications.
SimpleLink-Easylink compatibility,ultra-low power platform designed (from TI) to easily implement the long-range connectivity with low power consumption on the Internet of Things projects (IoT).
TI-15.4 Stack, IEEE802.15.4e/g Standard Based Star Networking Software Designed for long range & robust star networks.
6LoWPAN compatibility with mesh network stack for Contiki.
Applications : – Low-Power Wireless Systems
Feature : – IEEE 802.15.4g mode switch support
– Smart Grid and Automatic Meter Reading – Ultra Low consumption technology
– Home and Building Automation
– Powerful ARM Cortex M3
– Wireless Sensor Network
– Supported by the open platform Contiki 6LoWPAN.
– 6LoWPAN systems
– Very Small size
Radiocontrolli s.r.l refuses any responsibility for irregular uses of the devices and for any possible lack or inaccuracy of the data and reserves the right to change in whole or in part these information without notice.
www.radiocontrolli.com
Pag. 1 / 10 Rev 2.5
RRCC–CCCC11130110–S9P1I5-4-H34
Radio
ontrolli
Wireless Modules
RC-CC1310-XXX Parameter Operating Voltage Supply Current RX Mode Supply Current TX Mode Supply Current TX Mode Supply Current Standby Mode Supply Current Shut Down Mode Operative Frequency Band Frequency Error RF Power Output 50ohm (*) RF Sensibility 50kbps RF Sensibility Long Range Mode 625bps Data Rate Operative Temperature (*) Programmable parameter.
Symbol VCC lCRX lCTX1
lCTX2
lCSTB lCSHU F
of
F pp
/
S d SLR DCC TLR
Min. 1.8
/ 0,01 -30
Typ. 3.00 5.50 13.40 23.50 0,70 185 915 ±10
-110.0 -124.0
Max. 3.8
4.0 +75
Units VDC mA mA mA µA nA MHz ppm / dBm dBm Mbit/s °C
MICROCONTROLLER: – Power ARM Cortex – M3 – Up to 48MHz Clock Speed – 128KB of On-System Programming Flash – 8KB of SRAM for Cache (or as General-Purpose RAM) – 20KB of Ultralow Leakege SRAM – Support Over-the-Air Upgrade (OTA)
For more information and details, please refer to the CC1310 Texas Instruments datasheet.
Block Diagram
Antenna Connector
Filter +
RF Matching
32KHz crystal
24MHz crystal
CC1310F128 (SOC)
Reset
JTAG
GPIO (n.30)
Radiocontrolli s.r.l refuses any responsibility for irregular uses of the devices and for any possible lack or inaccuracy of the data and reserves the right to change in whole or in part these information without notice.
www.radiocontrolli.com
Pag. 2 / 10 Rev 2.5
RRCC–CCCC11130110–S9P1I5-4-H34
Reference Schematics
Radio
ontrolli
Wireless Modules
14
15
16
17
18
19
DIO-11 DIO-12 DIO-13 DIO-14 DIO-15 JTAG-TMSC JTAG-TCKC DIO-16/JTAG-TDO DIO-17/JTAG-TDI DIO-18
VDD
C1 106
1 2 3 4 5 6 7 8 9 10 11 12 13
GND DIO-1 DIO-2 DIO-3 DIO-4 DIO-5 DIO-6 DIO-7 GND VDD DIO-8 DIO-9 DIO-10
RC-CC1310-XXX
DIO-30 DIO-29 DIO-28 DIO-27 DIO-26 DIO-25 DIO-24 DIO-23
RESET DIO-22 DIO-21 DIO-20 DIO-19
36 35 ?3?4 33 32 31
30 29 28 27 26 25 24
RESET N
20
23
For cJTAG
VDD GND RESET N JTAG-TMSC JTAG-TCKC
For JTAG
VDD GND RESET N JTAG-TDI JTAG-TDO JTAG-TMSC JTAG-TCKC
DIO-17/JTAG-TDI 22
DIO-16/JTAG-TD0 21
JTAG-TCKC
JTAG-TMSC
Mechanical Dimension
1.27mm
15mm
Antenna UFL
Antenna Pad
39 38
37
Antenna hole
RC-CC1310-XXX
13 12 11 10 9 8 7 6 5 4 3 2 1 14 15 16 17 18 19 20 2 1 22 23
24 25 26 27 28 29 30 31 32 33 34 35 36
22mm
(2.50 mm)
Radiocontrolli s.r.l refuses any responsibility for irregular uses of the devices and for any possible lack or inaccuracy of the data and reserves the right to change in whole or in part these information without notice.
www.radiocontrolli.com
Pag. 3 / 10 Rev 2.5
RRCC–CCCC11130110–S9P1I5-4-H34
Radio
ontrolli
Wireless Modules
Terminal description RC-CC1310-915-H
Pads
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
37 38 39
Name
Description
GND
Ground
DIO-1
GPIO,Sensor Controller, High drive capability
DIO-2 DIO-3
GPIO, Sensor Controller, High drive capability GPIO, Sensor Controller, High drive capability
DIO-4 DIO-5
GPIO, Sensor Controller, High drive capability GPIO, Sensor Controller, High drive capability
DIO-6
GPIO, Sensor Controller, High drive capability
DIO-7
GPIO, Sensor Controller, High drive capability
GND
Ground
VDD
Power
DIO-8
GPIO
DIO-9
GPIO
DIO-10
GPIO
DIO-11 DIO-12
GPIO GPIO
DIO-13
GPIO
DIO-14 DIO-15
GPIO GPIO
JTAG-TMSC JTAG TMSC, High drive capability
JTAG-TCKC JTAG TCKC
DIO-16 DIO-17
GPIO,JTAG -TDO, High drive capability GPIO,JTAG-TDI, High drive capability
DIO-18 DIO-19
GPIO GPIO
DIO-20
GPIO
DIO-21
GPIO
DIO-22
GPIO
RESET-N RESET, (Active low)
DIO-23
GPIO, Sensor Controller, Analog
DIO-24 DIO-25
GPIO, Sensor Controller, Analog GPIO, Sensor Controller, Analog
DIO-26
GPIO, Sensor Controller, Analog
DIO-27 DIO-28
GPIO, Sensor Controller, Analog GPIO, Sensor Controller, Analog
DIO-29 DIO-30
GPIO, Sensor Controller, Analog GPIO, Sensor Controller, Analog
GND Antenna GND
Ground Antenna PAD Ground
13 12 11 10 9 8 7 6 5 4 3 2 1 14 15 16 17 18 19 20 21 22 23
24 25 26 27 28 29 30 31 32 33 34 35 36
39 38
37
Antenna Pad Antenna hole
RC-CC1310-915-H
Antenna connection
– Antenna connection trought hole and pad
Radiocontrolli s.r.l refuses any responsibility for irregular uses of the devices and for any possible lack or inaccuracy of the data and reserves the right to change in whole or in part these information without notice.
www.radiocontrolli.com
Pag. 4 / 10 Rev 2.5
RRCC–CCCC11130110–S9P1I5-4-H34
Radio
ontrolli
Wireless Modules
RC-CC1310-915-H Adapter board
To make immediate usable the RC-CC1310-915-H module with TI development systems has been realized the following board adapter.
Adapter board front
Adapter board rear
SMART RF06 Evaluation board (TI)
39 38
37
13 12 11 10 9 8 7 6 5 4 3 2 1 14 15 16 17 18 19 20 21 22 23
24 25 26 27 28 29 30 31 32 33 34 35 36
GND to pin 9
3V3 to pin 10
RST to pin 28 TMS to pin 19 TCK to pin 20 TDO to pin 21 TDI to pin 22
GND DIO-1 DIO-2 DIO-3 DIO-4 DIO-5
DIO-6 DIO-7
GND 3V3
DIO-8 DIO-9 DIO-10
Antenna hole
RC-CC1310-915-H
DIO-30 DIO-29 DIO-28 DIO-27 DIO-26 DIO-25 DIO-24 DIO-23
RST
DIO-22 DIO-21 DIO-20 DIO-19
DIO-11 DIO-12 DIO-13 DIO-14 DIO-15
TMS TCK TDO TDI
DIO-18
Texas Instruments Launchpad Connection
Radiocontrolli s.r.l refuses any responsibility for irregular uses of the devices and for any possible lack or inaccuracy of the data and reserves the right to change in whole or in part these information without notice.
www.radiocontrolli.com
Pag. 5 / 10 Rev 2.5
RRCC–CCCC11130110–S9P1I5-4-H34
Radio
ontrolli
Wireless Modules
Recommended Hardware design
1) Hardware All unused pins should be left floating; do not ground. All GND pins must be well grounded. Traces should not be routed underneath the module.
2) Power Supply The transceiver module must be powered from a regulated voltage. It is recommended to keep the power supply line for VCC as short and low impedence as possible. Near the power pins it is recommended to insert a ceramic the decoupling capacitor (100nF).
3) Ground Plane It is recommended to have a copper ground plane under the shielded zone of the module. The ground plane should be unbroken.
Shield Board Ground Plane
Cut off or copper free
4) Module Placement The antenna on the PCB has an omnidirectional radiation pattern. To maximize antenna efficiency, an adequate grounding plane must be provided under the module. Instead the areas underneath and surrounding the antenna area must be free of copper.
Antenna Area this PCB area must be cut-off or copper free
PCB Board Recommended location XY plane
PCB Board Not Recommended location XY plane
Radiocontrolli s.r.l refuses any responsibility for irregular uses of the devices and for any possible lack or inaccuracy of the data and reserves the right to change in whole or in part these information without notice.
www.radiocontrolli.com
Pag. 6 / 10 Rev 2.5
RRCC–CCCC11130110–S9P1I5-4-H34
Radio
ontrolli
Wireless Modules
Recommended PCB Layout
0.26 2.20
5.08 2.10
Ø0.60
15.24
1.20
23.00 1.27
1.40 0.70
1.60 0.70
1.77
0.23
1.27
11.43 16.0
Recommended Reflow Profile for Lead Free Solder
Radiocontrolli s.r.l refuses any responsibility for irregular uses of the devices and for any possible lack or inaccuracy of the data and reserves the right to change in whole or in part these information without notice.
www.radiocontrolli.com
Pag. 7 / 10 Rev 2.5
RRCC–CCCC11130110–S9P1I5-4-H34
REEL DIMENSIONS
Radio
ontrolli
Wireless Modules
Reel Diameter (330mm)
Reel Width (45mm)
TAPE DIMENSIONS
15.5mm ± 0.10mm 23.0mm ± 0.10mm 3.5mm ± 0.10mm 44.0mm ± 0.30mm 20.0mm ± 0.10mm
Radiocontrolli s.r.l refuses any responsibility for irregular uses of the devices and for any possible lack or inaccuracy of the data and reserves the right to change in whole or in part these information without notice.
www.radiocontrolli.com
Pag. 8 / 10 Rev 2.5
RRCC–CCCC11130110–S9P1I5-4-H34
Radio
ontrolli
Wireless Modules
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver connected. – Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected. – Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Important Note: Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment . This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Country Code selection feature to be disabled for products marketed to the US. This device is intended only for OEM integrators under the following conditions: 1. The antenna must be installed such that 20 cm is maintained between the antenna and
users,and 2. The transmitter module may not be co-located with any other transmitter or antenna, As long as the three conditions above are met, further transmitter testing will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed. Important Note: In the event that these conditions cannot be met (for example certain laptop configurations or colocation with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for reevaluating the end product (including the transmitter) and obtaining a separate FCC authorization. End Product Labeling The final end product must be labeled in a visible area with the following” Contains FCC ID: 2ANH5RC-CC1310-915H” Manual Information to the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warning as show in this manual.
Radiocontrolli s.r.l refuses any responsibility for irregular uses of the devices and for any possible lack or inaccuracy of the data and reserves the right to change in whole or in part these information without notice.
www.radiocontrolli.com
Pag. 9 / 10 Rev 2.5
RRCC–CCCC11130110–S9P1I5-4-H34
Radio
ontrolli
Wireless Modules
Integration instructions for host product manufacturers according to KDB 996369 D03 OEM Manual v01
2.2 List of applicable FCC rules
CFR 47 FCC PART 15 SUBPART C has been investigated. It is applicable to the modular transmitter
2.3 Specific operational use conditions
This module is stand-alone modular. If the end product will involve the Multiple simultaneously
transmitting condition or different operational conditions for a stand-alone modular transmitter in a
host, host manufacturer have to consult with module manufacturer for the installation method in end system.
2.4 Limited module procedures
Not applicable
2.5 Trace antenna designs
Not applicable
2.6 RF exposure considerations
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
2.7 Antennas
This radio transmitter FCC ID: 2ANH5RC-CC1310-915H has been approved by Federal Communications Commission to operate with the antenna types listed below, with the maximum
permissible gain indicated. Antenna types not included in this list that have a gain greater than the maximum gain indicated for any type listed are strictly prohibited for use with this device.
2.8 Label and compliance information
The final end product must be labeled in a visible area with the following” Contains FCC ID: 2ANH5RC-CC1310-915H “.
2.9 Information on test modes and additional testing requirements
Host manufacturer is strongly recommended to confirm compliance with FCC requirements for the transmitter when the module is installed in the host.
2.10 Additional testing, Part 15 Subpart B disclaimer
Host manufacturer is responsible for compliance of the host system with module installed with all other applicable requirements for the system such as Part 15 B.
Radiocontrolli s.r.l refuses any responsibility for irregular uses of the devices and for any possible lack or inaccuracy of the data and reserves the right to change in whole or in part these information without notice.
www.radiocontrolli.com
Pag. 10 / 10 Rev 2.5
Radiofrequency Modules and IoT Modules - RF Modules 433/868/915MH and IoT modules
