Vortex Hd60i Mobile Phone User Guide

HD60I Mobile Phone

Product Information:

Product Usage Instructions:

To adjust the volume or mute incoming calls, short press the
VOLUME BUTTON on the device.

For more detailed instructions on using the product, please
refer to the Quick Start Guide included in the box.

PRODUCT HEX-VISION IMAGE

PRODUCT HEX-VISION IMAGE

Flash lamp

HD60i

VOLUME BUTTON:Short press to adjust the volume or to mute incoming calls.

7

SPECIFICATIONS
BASIC INFORMATION
Model HD60i Operating System Powered by AndroidTM 13 Go CPU 4xA53 1.5GHz MTK6739 RAM 2GB ROM 32GB Battery 2800mAh

Display

Screen Size 6.0″ IPS SCREEN Resolution 480*960 Pixeis Touch Capacitive multi-touch

Cameras

Front

Camera

Rear

Camera

Connection(I/O)

5MP Ca mera 8MP Camera

Band GSM:850/900/1800/1900 WCDMA:B2/4/5 LTE:B2/4/5/12/13/25/26/41/66/71
SIM/TF card 1 Micro SIM Card and 1 TF Card WiFi IEEE802.11 a/b/g/n/ Bluetooth Bluetooth 4.0 GNSS GPS
FM YES Earphone Port 3.5mm USB Port Type-Micro USB

Other Features
Video File Format 3GP/MPEG4,etc Audio File Format WAV/MP3/AAC/AMR/MIDI/APE/WMA,etc Card Extend Support TF card up to 64 GB Language Support Multi-language Sensor G-Sensor

In the box

1*Phone 1*USB-Micro Cable 1*Power Adapter
1*Quick Start Guide 1*Protective case 1*Battery

8

FCC Warning 15.19 Labeling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 15.21 Information to user. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 15.105 Information to the user. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Absorption Rate (SAR) information: This device meets the government’s requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. FCC RF Exposure Information and Statement The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. This device was tested for typical body-worn operations with the back of the device kept 10mm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain a appropriate separation distance between the user’s body and the back of the device. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided. Use only the supplied or an approved antenna.
BE BG CZ DK DE EE IE EL ES FR HR IT CY LV LT LU HU MT NL AT PL PT RO SI SK FI SE NO IS LI CH TR ln all EU member states. operation of 5150-5250 MHz is restricted to indoor use only.
Made in China

HD60i
