Epic Office Furniture Freestanding Acoustic Partition Screen Instruction Manual

Freestanding Acoustic Partition Screen

Product Information:

The product is a freestanding acoustic partition designed to
provide sound insulation and privacy in open office spaces or other
environments. It consists of multiple panels connected together
with screws for easy assembly and disassembly.

• Material: Not specified in the provided information
• Dimensions: Each panel measures W60cm x D500cm x H250cm
• Quantity: The package contains 16 panels and 2 screws

Product Usage Instructions:

1. Ensure that you have received all the necessary components,
   including 16 panels and 2 screws.
2. Identify a suitable area where you want to set up the
   freestanding acoustic partition.
3. Place the first panel in the desired position, making sure it
   is stable and upright.
4. Take one of the screws and insert it through the pre-drilled
   hole on the side of the first panel.
5. Align the second panel with the first panel, ensuring that the
   edges are flush.
6. Insert the other end of the screw through the pre-drilled hole
   on the side of the second panel.
7. Tighten the screw using a screwdriver, ensuring that the two
   panels are securely connected.
8. Repeat steps 3 to 7 for all remaining panels, connecting them
   together in a desired configuration.
9. Once all panels are assembled, adjust their positions if
   necessary to achieve the desired layout.

Important Note: It’s important to follow the
assembly instructions carefully to ensure proper installation and
stability of the freestanding acoustic partition. If you have any
questions or concerns, please refer to the product manual or
contact our customer support for assistance.

Freestanding Acoustic Partition Assembly Instructions

Screw

5X20

1

16PCS
W60xD500xH250
2

2PCS

STEP1

IMPORTANT NOTE:
· Place all laminated parts on a clean and smooth surface such as a rug or carpet to avoid the parts from being scratched. · Check to be sure that you have all parts and hardware.
· Remove all wrapping materials,including staples & packing straps before you start to assemble. · Don’t tighten all screws/bolts until all completely assembled.
· Keep all hardware parts out of reach of children
