HW357-3 2.4G Wireless Keyboard and Mouse Combo
Product Information
The product includes a keyboard, a mouse, a user manual, and a
hairbrush. The keyboard has a return key, DPI indicator, Fn lock
indicator, number lock indicator, caps lock indicator, power
indicator, and a USB receiver inside. It requires 2 AAA dry cell
batteries and has a working current of 3 mA. The effective
transmission distance is within 10 meters and it sleeps for 10
minutes after no operation. The wake-up method is by pressing any
key. The applicable systems are Win 8 (and above) system, MAC OS,
and Android. The product size is 434.5*121*21.5mm
The mouse has a DPI of 800-1200cdefault-1600 and multimedia
buttons for Windows and MAC OS. It requires 1 AA dry cell battery
and has an effective transmission distance within 10 meters. It has
a working current of 15 mA and sleeps for 10 minutes after no
operation. The wake-up method is by pressing any key. The product
size is 100.5*61.5*34.5mm
Product Usage Instructions
- Turn on the keyboard and mouse power switch.
- Take out the USB receiver from the receiver hole on the bottom
of the mouse. - Plug the USB receiver into your computer’s USB port.
- The keyboard and mouse are successfully connected.
To turn on/off the FN function, press FN+.
When the battery power is low, the DPI indicator will flash
red.
To wake up the keyboard or mouse from sleep mode, press any
key.
Note: The product is compatible with Win 8 (and above) system,
MAC OS, and Android.
NN
H$
PANTONE 548 C
packing list
1* Keyboard 1* Mouse 1* User manual 1* Hairbrush
Return key
DPI indicator Red light will flash when battery power is too low.
Fn lock indicator Number lock indicator Caps lock indicator Power indicator
USB receiver inside
Power switch
ON OFF
Battery hole
1*AUASB
2*AAA
Battery hole
Power switch
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
2.4G Connection
1. Turn on the keyboard and mouse power switch. 2. Take out the USB receiver from the receiver hole on the bottom of
the mouse. 3. Plug the USB receiver into your computer”s USB port.
4. Then the keyboard and mouse is successfully connected.
Keyboard Specifications
Applicable system
Win 8 (and above) system, MAC OS,Android
Battery specifications
2*AAA dry cell
Working current
3 mA
Product Size
434.5*121*21.5mm
Effective transmission distance Within 10 meters
Sleep time
Sleeps for 10 minutes after no operation
Wake-up method
Press any key to wake up
Mouse Specifications
DPI
800-1200cdefault-1600
Battery specifications
1*AA dry cell
Effective transmission distance Within 10 meters
Working current
15 mA
Product Size
100.5*61.5*34.5mm
Sleep time
Sleeps for 10 minutes after no operation
Wake-up method
Press any key to wake up
Multimedia buttons
Windows(Default)
MAC OS
Mute
Mute
Volume down
Volume down
Screenshot
Screenshot
Previous Play&Stop
Previous Play&Stop
Next
Next
Decrease brightness Decrease brightness
Increase brightness
Increase brightness
Select All
Select All
Copy
Copy
Paste
Paste
Cut
Cut
Window switching
NA
Searh
NA
Speech recognition(win+H)
NA
Equipment(Win+K)
NA
Set up
NA
Press FN+ to turn ON / OFF the FN function
