POWER UPR208 20000mAh Nano Powerbank
Product Information
The 20K urbn 22.5 is a high-capacity power bank that can provide
up to 22.5 watts of charging power. It uses a Li-polymer battery
and chip to ensure a safe, efficient, and compatible user
experience. The power bank supports Quick charge (QC) and Power
Delivery (PD) with speed up to 22.5 Watts. It is also capable of
dual charging with up to 3.1 Amp 5V charging speed when connected
with two devices. The power bank has multiple safeguard
technologies to provide over-charge, over-discharge, high
temperature, and short circuit protection in all working
conditions.
Specifications
- Capacity: 20000mAh 3.85V(77Wh)
- Type-C1/C2 Input: 5V/2.4A, 9V/2A, 12V/1.5A (18W Max)
- Type-C1/C2 Output: 5V/3A, 9V/2.22A, 12V/1.67 (20W Max)
- USB-A Output: 5V/3A, 9V/2A, 12V/1.5A, 10V/2.25A (22.5W
Max) - Dual Output: 5V/3.1A (15.5W Max)
- Size: 108.20 x 28 x 69mm
- Weight: 293 g
- Battery Type: Li-Polymer
Product Usage Instructions
Charging
To charge the power bank, connect it to a compatible power
adapter. The power indicator will blink to show the charging
condition. The LED 1 to LED 4 indicate the charging level from
0-100%. White light on LED 1 indicates fast charging mode, and
green light on LED 1 indicates the activation of superfast charging
mode.
Discharging
To charge your device, connect it to the power bank. The power
indicator will blink to show the discharging condition. The LED 1
to LED 4 indicate the charging level from 0-100%. White light on
LED 1 indicates fast charging mode, and green light on LED 1
indicates the activation of superfast charging mode.
Precaution
Do not expose the power bank to water, fire, or extreme
temperatures. Do not disassemble or modify the power bank. Do not
use the power bank if it is damaged or swollen. Keep the power bank
away from children.
Limited Warranty
The manufacturer provides a one-year limited warranty for this
product. During the warranty period, a defective product will be
repaired or replaced with a reconditioned comparable model at the
manufacturer’s discretion. The maximum liability of the company
shall not exceed the actual purchase price paid by the
purchaser.
20K urbn 22.5 User Manual 7.5cmX10cm
Product Overview
Thank you for choosing this product. This product is a high-capacity 22.5 watt QC + PD Powerbank that uses a Li-polymer battery and chip for a safe, efficient, and compatible user experience.
Type – C Input/Output Type – C Input/Output USB Output
Power Check Power Indicator
Note: The power check button is not a power button. The power bank detects charging and discharging automatically. The power indicator goes off 2 minutes after fully discharged.
Safety: The power bank has multiple safeguard technologies to provide over-charge, over-discharge, high temperature, and short circuit protection in all working conditions.
Efficiency: The power bank supports Quick charge (QC) and Power Delivery (PD) with speed upto 22.5 Watts. It is also capable of dual charging with upto 3.1 Amp 5V charging speed when connected with two devices.
Specifications
Capacity: 20000mAh 3.85V(77Wh) Type-C1/C2 Input: 5V/2.4A, 9V/2A, 12V/1.5A (18W Max) Type-C1/C2 Output: 5V/3A, 9V/2.22A, 12V/1.67 (20W Max) USB-A Output: 5V/3A, 9V/2A, 12V/1.5A, 10V/2.25A (22.5W Max) Dual Output: 5V/3.1A (15.5W Max) Size: 108.20 x 28 x 69mm Weight: 293 g Battery Type: Li-Polymer
Charging
Connect with a compatible power adapter to charge the power bank. The indicator shows charging conditions as follows:
Blinking Power
LED 1 0-25%
LED 2 25-50%
LED 3 LED 4 50-75% 75-100%
White light on LED 1 indicates fast charging mode. Green light on LED 1 indicates the activation of superfast charging mode.
Fast Charging
Superfast Charging
Discharging
Connect your device with the power bank to charge it. The indicator shows discharging conditions as follows:
Blinking Power
LED 1 0-25%
LED 2 25-50%
LED 3 LED 4 50-75% 75-100%
White light on LED 1 indicates fast charging mode. Green light on LED 1 indicates the activation of superfast charging mode.
Fast Charging
Superfast Charging
Precaution
· Make sure your power bank is fully charged before its first use.
· When charging a device with the power bank, please check for the battery charging icon on the device to ensure proper functioning of the power bank.
· Once your device is fully charged, disconnect the power bank to avoid further discharge.
· Use BIS approved adapter for charging the power bank.
· Use and charge your power bank in a ventilated space. · Do not leave the power bank under direct sunlight
e.g. in a car, near the window, etc. · Do not open the casing as it may cause cell damage
and other dangers. · Do not dismantle, crush, or puncture the power bank.
Do not expose it to liquids, fire, or temperatures above 60°C (140°F). · Please do not discard the product with household waste. Kindly follow the local environmental regulations for proper disposal of the used product.
POWER YOUR VIBE
To know more about Urbn visit our website www.urbnworld.com
To connect with us for assistance please contact us on [email protected] or 1800 22 2468
urbnworld
urbnworld
20K urbn 22.5 User Manual 7.5cmX10cm
Limited Warranty
The manufacturer’s product warranty extends to the original consumer purchaser of the product. Neither the retailer nor any other company involved in the sale or promotion of this product is a co-warrantor of this manufacturer warranty.
WARRANTY DURATION: All the materials and workmanship are warranted to the original consumer purchaser for a period of one (1) year from the original purchase date.
WARRANTY COVERAGE: This product is warranted against defective materials or workmanship. This warranty is void if the product has been damaged by accident, in shipment, unreasonable use, misuse, neglect, improper service, commercial use, repairs by unauthorized personnel or other causes not arising out of the defects in material or workmanship. This warranty does not extend to any units which have been used in violation of the written instructions furnished by the manufacturer or to units which have been altered or modified or, to damaged products or parts thereof, which have had the serial number removed, altered, defaced, or rendered illegible.
WARRANTY DISCLAIMERS: This warranty is in lieu of all warranties expressed or implied and no representative or person is authorized to assume for manufacturer any other liability in connection with sale of our products.
WARRANTY PERFORMANCE: During the one (1) year warranty period, a product with defect will be either repaired or replaced with a reconditioned comparable model (at the manufacturer’s discretion). The repaired or replacement product will be in warranty for the balance of the warranty period or thirty (30) days, whichever is longer.
WARRANTY LIMIT: The maximum liability of the company shall not exceed the actual purchase price paid by the purchaser.
SERVICE AND REPAIR: If service is required for the product, kindly contact Acetron Tech Ventures Pvt Ltd Customer Service at [email protected] or call 1800 22 2468.
Disputes if any, shall be subject to Mumbai Jurisdiction only.
POWER
20000mAh
NANO POWER BANK
POWER YOUR VIBE
UPR208
Instruction Manual
Please read all instructions carefully. Retain for future use.
Urbn World
