Ropeflex Rx1500 Dragon Upright Rope Trainer Owner's Manual

RX1500 Dragon Upright Rope Trainer

Product Information

The product is the RX1500, an exercise equipment designed for
home use. It is important to register your new product online at
www.hipeq.com/product-registration.
The product serial number can be found on the equipment or in the
box.

In case any of the warning decals are missing or illegible,
please contact us toll-free at 650.549.5888, Monday through Friday,
9 a.m. until 5 p.m. Pacific Time, to order replacement decals.
Apply replacement decals in the indicated locations.

Before using this equipment, it is essential to read all
instructions in the assembly instructions and manual provided. The
manual contains important precautions to reduce the risk of serious
injury while using the equipment. Make sure all users of this
equipment are adequately informed of these precautions.

The equipment should only be used on a level surface, and the
floor beneath should be covered to protect it. The maximum user
weight supported by this equipment is 300 pounds. Keep children
under 12 and pets away from the equipment at all times. Ensure that
all parts are properly tightened before each use, and replace any
worn parts immediately.

Always wear athletic shoes for foot protection while exercising.
If you feel pain or dizziness at any time during exercise, stop
immediately and begin cooling down. It is recommended to consult a
physician before starting any exercise program, especially for
persons over the age of 35 or those with pre-existing health
problems. HiPEQ assumes no responsibility for personal injury or
property damage sustained through the use of this product.

Product Usage Instructions

Box Contents / Parts List

Tools Required for Assembly

A 3/4 Hex Open Wrench is required for the assembly process.

Product Assembly

Step 1: Assemble the unit as shown below and
tighten all fasteners. Note: Do not attempt assembly alone.
Two-person installation is required.

Mast Plates: Attach the mast plates using the
provided hardware (3/8 or 5/16 screws) – Quantity: 4.

Drums: Thread the rope through the pins as
shown and attach the cover plate with handle using the included
hardware (1/2 washers, bolts & lock-nut) – Quantity: 4, 2, and
2.

Hardware: Secure the hardware (5/16 washer
& screw) – Quantity: 4.

Continued Assembly: Install the stiffening mast
plates according to the provided instructions.

PLEASE REGISTER YOUR NEW PRODUCT
To register your product online please go to:
www.hipeq.com/product-registration
Product serial number is located on equipment or is shown in the box below SERIAL NUMBER
If serial number is not sown please check equipment
DRAGON ­ RX1500 Assembly Instructions & Manual DOC: 32-1029 Configuration subject to change

RX1500 ASSEMBLY INSTRUCTIONS & MANUAL
WARNING DECAL PLACEMENT
The decals shown here have been placed on the equipment in indicated locations. If any of the decals are missing or illegible, call us tollfree at 650.549.5888, Monday through Friday, 9 a.m. until 5 p.m. Pacific Time, to order replacement decals. Apply replacement decals in the locations shown.

32-1029-M-REV.B

1

RX1500 ASSEMBLY INSTRUCTIONS & MANUAL
IMPORTANT PRECAUTIONS

32-1029-M-REV.B

WARNING: To reduce the risk of serious injury, read the following important precautions before

using this equipment.

1. Read all instructions in this manual and

6. Make sure the adjustment knobs are fully

assemble as described before using this

engaged / disengaged before using the

equipment.

equipment.

2. It is the responsibility of the owner to ensure 7. Always wear athletic shoes for foot

that all users of this equipment are adequately informed of all precautions.

protection while exercising. 8. This equipment is designed to support a

3. Use this equipment only on a level surface. Cover the floor beneath to protect the surface.

maximum user weight of 300 pounds. 9. Pull on one the rope only and never grab a
rope in a way that prevents the drum from

4. Keep children under 12 and pets away from the equipment at all times.

rotating. Never attempt to hang on the rope or frame. Pull rope with hands only.

5. Make sure all parts are properly tightened

10. If you feel pain or dizziness at any time

each time you use this machine. Replace

while exercising, stop immediately and

any worn parts immediately.

begin cooling down.

WARNING: Before beginning this or any exercise program, consult your physician. This is especially important for persons over the age of 35 or persons with pre-existing health problems. Read all instructions before using. HiPEQ assumes no responsibility for personal injury or property damage sustained by or through the use of this product.

2

RX1500 ASSEMBLY INSTRUCTIONS & MANUAL

32-1029-M-REV.B

Box Contents / Parts List

DRAGON TOP ASSEMBLY

ITEM 1 2 3 4 5 6 7 8 9 10 11

QUANTITY 1 OR 2 1 1 2
UP TO 12 UP TO 12
4 2 2 2 4

DESCRIPTION RX505 (HYDRA) Drum with Rope RX1500 (DRAGON) Base RX1500 (DRAGON) Main Mast Mast cover plates Button Head Screw 5/16″ x 1″ Washer 5/16″ Washer ½” Screw ½-13″ x 5-1/2″ Lock-nut ½-13″ Base support tubes 3/8″ Mast cover plate screws

Qty. UP TO 12 HEX Head Screw
5/16″ x 1″

Qty.10 Washer 5/16″

Qty.2 Screw ½-13″ x 5.5″

Qty.4 Washer 1/2″

Qty.2 Lock-nut ½-13″
3

RX1500 ASSEMBLY INSTRUCTIONS & MANUAL
Tools Required for Assembly
¼” Hex Key

32-1029-M-REV.B

3/4 Hex Open Wrench

4

RX1500 ASSEMBLY INSTRUCTIONS & MANUAL

32-1029-M-REV.B

Product Assembly STEP 1 1-1 Assemble the unit as shown below and tighten all fasterns.

Note: Do not attempt assembly alone. Two person installation required.
Mast Plates
Hardware (3/8 or 5/16 screws) Qty.4

Drums may arrive unassembled. Thread rope through pins as shown and attach cover plate with handle using included hardware.

Hardware (1/2″ washers, bolts & lock-nut)
Qty.4, 2 & 2
5

Hardware
(5/16″ washer & screw) Qty.4

RX1500 ASSEMBLY INSTRUCTIONS & MANUAL

32-1029-M-REV.B

Product Assembly – continued
Stiffening mast plates installation
1-2 Before putting ROPE DRUMS remove the clips. Install clips once the drums
are securely positioned on the mast(s) and use threaded clips as show. Once stiffening mast plates are secure, cover tube ends with plastic covers.

OPTION A 4X 5/16-18 THREAD SNAP-IN NUT

PLASTIC TUBE COVER

OPTION B 4X 3/8-16 THREAD CLIP-ON BARREL NUT

6

RX1500 ASSEMBLY INSTRUCTIONS & MANUAL

32-1029-M-REV.B

Equipment Maintenance
WARNING: Routine inspection and maintenance is of critical importance to ensure maximum safety and performance. We use the highest quality materials available, but wear is inevitable. Be advised that dangerous conditions can arise even during a warranty period. A warranty does not negate the owner’s responsibility to thoroughly, carefully and daily inspect the machine. Consult your physician before starting your exercise program. For your own safety, do not begin any exercise program without proper instruction.
1. Check Rope While the machine is not in use carefully inspect the rope for damage and tears. Carefully inspect connection of rope ends and make sure that stitching (threads) are not torn or damaged. Do not use equipment until damaged rope has been replaced.
2. Upholstery Wipe down after every workout. Periodically take the time to use a mild soap or mild vinyl upholstery cleaner. Avoid using any abrasive cleaner not intended for use on vinyl. Keep sharp or pointed objects out of your pockets and clear of all upholstery.
3. Nuts/Bolts/Fasteners Periodically inspect all nuts and bolts. Tighten if needed. If bolts seem to loosen periodically, use Loctite 242 for a long-term cure. Go through a re-tightening sequence periodically to ensure that all hardware is properly tensioned.
4. Adjustments / Locking Pins / Tightening Knobs Check all pieces for signs of visible wear or damage. Check springs in Snap Links and Pop Pins for proper tension and alignment. If the spring sticks or has lost its rigidity, replace it immediately.
5. Anti-Skid Surfaces Replace if they appear worn or become slippery.
7. Warning Instruction Labels Inspect and familiarize yourself with all safety warnings and other user information on decals. Replace decals if damaged, illegible, or removed.

7

RX1500 ASSEMBLY INSTRUCTIONS & MANUAL

32-1029-M-REV.B

WARRANTY
We strive to offer the simplest and fastest resolution to all product related concerns. Our warranty service program gives its customers the option to return the product for repair, exchange or refund if the product is determined to be defective.

· All products are warranted to the original purchaser.
· Warranties apply and cover all defects in material and workmanship.
Frame (excluding coating): Lifetime Rope, Sheaves, Bearings and Labor: One-Year Upholstery and Stitching: 90-Days Electronics: One-Year
· Customer is responsible for the cost of shipment to HiPEQ. Company “ship to” address for product returns and service will be provided once the RMA has been issued. It will be at HIPEQ’s discretion to determine the party responsible for cost of shipment back to customer.
· Out-of-Warranty Products are repaired only with the customer’s prior approval.
· 15 Day 100% Satisfaction Guarantee includes full refund of purchase price, less shipping, handling and restocking fee equaling 15% of price during purchase. Email for more details. If you decide to return a HiPEQ product, simply email us within 15 days to ask for a return authorization number (RMA). Items must be returned in original condition and packaging and postmarked no later than 2 weeks after the date of return authorization.

8

If you have any questions regarding HIPEQ equipment or any instruction found in this document please call 650.549.5888 for assistance.
9
