LJ610V 43 Inch Smart Full HD LED TV

Product Information: LG LED TV

The LG LED TV applies an LCD screen with LED backlights. This TV
comes with a user manual that provides safety instructions and
reference information for proper usage.

Important Safety Instructions:

Caution: Risk of electric shock. Do not open the back cover of
the TV. No user-serviceable parts are inside. Refer to qualified
service personnel.
Do not expose the TV to rain or moisture to reduce the risk of
fire and electric shock.
Keep the power plug accessible in case of an emergency.
Do not locate an outdoor antenna system in the vicinity of
overhead power lines or other electric light or power circuits as
it can cause death or serious injury. Ensure proper grounding of
the antenna system according to the National Electrical Code
(NEC).

Preparing:

Before operating the TV, ensure that you have purchased and
connected all necessary accessories such as the power cord, HDMI
cable, and antenna cable. If you need to connect a USB device,
ensure that the USB cable or USB memory stick fits into the TV’s
USB port. If not, use an extension cable that supports USB with
bezels less than 10 mm thick and 18 mm width.

Product Usage:

Connect the power cord to the TV and plug it into an electrical
outlet.
Connect the antenna cable to the TV if you plan to watch TV
channels.
If using external devices such as a DVD player or gaming
console, connect them to the TV using HDMI cables.
Use the remote control to turn the TV on and off, adjust the
volume, and change channels or inputs.
Refer to the user manual for advanced settings and features
such as picture and sound settings, network connection, and
software updates.

View Fullscreen

OWNER’S MANUAL
Safety and Reference
LED TV*
* LG LED TV applies LCD screen with LED backlights.
Please read this manual carefully before operating your set and retain it for future reference.

*MFL71100151*
(2211-REV01)

www.lg.com
Copyright © 2019 LG Electronics Inc. All Rights Reserved.

ENGLISH

Warning! Safety Instructions
CAUTION RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL.
This symbol is intended to alert the user to the presence of uninsulated”dangerous voltage”within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. WARNING: TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
· TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR OTHER ITEMS WITH OPEN FLAMES AWAY FROM THIS PRODUCT AT ALL TIMES.
· Do not place the TV and/or remote control in the following environments: – Keep the product away from direct sunlight. – An area with high humidity such as a bathroom. – Near any heat source such as stoves and other devices that produce heat. – Near kitchen counters or humidifiers where they can easily be exposed to steam or oil. – An area exposed to rain or wind. – Do not expose to dripping or splashing and do not place objects filled with liquids, such as vases, cups, etc. on or over the apparatus (e.g., on shelves above the unit). – Near flammable objects such as gasoline or candles, or expose the TV to direct air conditioning. – Do not install in excessively dusty places. Otherwise, this may result in fire, electric shock, combustion/ explosion, malfunction or product deformation.

· Ventilation – Install your TV where there is proper ventilation. Do not install in a confined space such as a bookcase. – Do not install the product on a carpet or cushion. – Do not block or cover the product with cloth or other materials while unit is plugged in.
· Take care not to touch the ventilation openings. When watching the TV for a long period, the ventilation openings may become hot.
· Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the device.
· Do not move the TV whilst the Power cord is plugged in. · Do not use a damaged or loosely fitting power cord. · Be sure to grasp the plug when unplugging the power cord. Do not
pull on the power cord to unplug the TV. · Do not connect too many devices to the same AC power outlet as this
could result in fire or electric shock. · Disconnecting the Device from the Main Power
– The power plug is the disconnecting device. In case of an emergency, the power plug must remain readily accessible.
· Do not let your children climb or cling onto the TV. Otherwise, the TV may fall over, which may cause serious injury.
· Outdoor Antenna Grounding (Can differ by country): – If an outdoor antenna is installed, follow the precautions below.
An outdoor antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can come in contact with such power lines or circuits as death or serious injury can occur.
Be sure the antenna system is grounded to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code (NEC) in the U.S.A. provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes and requirements for the grounding electrode.
Antenna grounding according to the National Electrical Code, ANSI/ NFPA 70

ENGLISH

· Grounding (Except for devices which are not grounded.) – TV with a three-prong grounded AC plug must be connected to a three-prong grounded AC outlet. Ensure that you connect the earth ground wire to prevent possible electric shock.
· Never touch this apparatus or antenna during a lightning storm. You may be electrocuted.
· Make sure the power cord is connected securely to the TV and wall socket if not secured damage to the Plug and socket may occur and in extreme cases a fire may break out.
· Do not insert metallic or inflammable objects into the product. If a foreign object is dropped into the product, unplug the power cord and contact the customer service.
· Do not touch the end of the power cord while it is plugged in. You may be electrocuted.
· If any of the following occur, unplug the product immediately and contact your local customer service. – The product has been damaged. – If water or another substance enters the product (like an AC adapter, power cord, or TV). – If you smell smoke or other odors coming from the TV. – When lightning storms or when unused for long periods of time.
Even if the TV is turned off by the remote control or power button, AC power source is still connected to the unit if it is not unplugged. · Do not use high voltage electrical equipment near the TV (e.g., a bug zapper). This may result in product malfunction. · Do not attempt to modify this product in any way without written authorization from LG Electronics. Accidental fire or electric shock can occur. Contact your local customer service for service or repair. Unauthorized modification could void the user’s authority to operate this product. · Use only an authorized attachments / accessories approved by LG Electronics. Otherwise, this may result in fire, electric shock, malfunction, or product damage. · Never disassemble the AC adapter or power cord. This may result in fire or electric shock. · Handle the adapter carefully to avoid dropping or striking it. An impact could damage the adapter. · To reduce the risk of fire or electrical shock, do not touch the TV with wet hands. If the power cord prongs are wet or covered with dust, dry the power plug completely or wipe dust off.

· Batteries – Store the accessories (battery, etc.) in a safe location out of the reach of children. – Do not short circuit, disassemble, or allow the batteries to overheat. Do not dispose of batteries in a fire. Batteries should not be exposed to excessive heat.
· Moving – When moving, make sure the product is turned off, unplugged, and all cables have been removed. It may take 2 or more people to carry larger TVs. Do not press or put stress on the front panel of the TV. Otherwise, this may result in product damage, fire hazard or injury.
· Keep the packing anti-moisture material or vinyl packing out of the reach of children.
· Do not allow an impact shock, any objects to fall into the product, and do not drop anything onto the screen.
· Do not press strongly upon the panel with a hand or a sharp object such as a nail, pencil, or pen, or make a scratch on it. It may cause damage to screen.
· Cleaning – When cleaning, unplug the power cord and wipe gently with a soft/dry cloth. Do not spray water or other liquids directly on the TV. Do not clean your TV with chemicals including glass cleaner, any type of air freshener, insecticide, lubricants, wax (car, industrial), abrasive, thinner, benzene, alcohol etc., which can damage the product and/or its panel. Otherwise, this may result in electric shock or product damage.

ENGLISH

Preparing

Separate Purchase

· If the TV is turned on for the first time after it was shipped from the factory, initialization of the TV may take a few minutes.
· Image shown may differ from your TV. · Your TV’s OSD (On Screen Display) may differ slightly from that shown
in this manual. · The available menus and options may differ from the input source or
product model that you are using. · New features may be added to this TV in the future. · The device must be easily accessed to a location outlet near the
access. Some devices are not made by turning on / off button, turning
off the device and unplugging the power cord. · The items supplied with your product may vary depending on the
model. · Product specifications or contents of this manual may be changed
without prior notice due to upgrade of product functions. · For an optimal connection, HDMI cables and USB devices should have
bezels less than 10 mm thick and 18 mm width. Use an extension
cable that supports USB if the USB cable or USB memory stick
does not fit into your TV’s USB port.

* A <= 10 mm

* B <= 18 mm

· Use a certified cable with the HDMI logo attached. · If you do not use a certified HDMI cable, the screen may not display or
a connection error may occur. (Recommended HDMI Cable Types) – Ultra High Speed HDMI®/TM Cable (3 m or less)

Separate purchase items can be changed or modified for quality improvement without any notification. Contact your dealer to buy these items. These devices only work with certain models. The model name or design may be changed depending on the upgrade of product functions, manufacturer’s circumstances or policies.
Wall Mounting Bracket
Make sure to use screws and wall mount bracket that meet the VESA standard. Standard dimensions for the wall mount kits are described in the following table.
A B

Model

32/43LT34*

VESA (A x B) (mm) 200 x 200

Standard screw M6

Number of screws 4

Wall mount bracket

LSW240B MSW240

Model

28LT34*

VESA (A x B) (mm) Standard screw Number of screws

100 x 100 M4 x L10 4

Wall mount bracket LSW149

49LT34*
300 x 300 M6 4 OLW480B MSW240

ENGLISH

Lifting and moving the TV
Please note the following advice to prevent the TV from being scratched or damaged and for safe transportation regardless of its type and size. · It is recommended to move the TV in the box or packing material that
the TV originally came in. · Before moving or lifting the TV, disconnect the power cord and all
cables. · When holding the TV, the screen should face away from you to avoid
damage.

· Avoid touching the screen at all times, as this may result in damage to the screen.
· Do not move the TV by holding the cable holders, as the cable holders may break, and injuries and damage to the TV may occur.
· When attaching the stand to the TV set, place the screen facing down on a cushioned table or flat surface to protect the screen from scratches.
Mounting on a Table

· Hold the top and bottom of the TV frame firmly. Make sure not to hold the transparent part, speaker, or speaker grill area.

1 Lift and tilt the TV into its upright position on a table. · Leave a 10 cm (minimum) space from the wall for proper
ventilation.

10 cm

· When transporting a large TV, there should be at least 2 people. · When transporting the TV by hand, hold the TV as shown in the
following illustration.
· When transporting the TV, do not expose the TV to jolts or excessive vibration.
· When transporting the TV, keep the TV upright, never turn the TV on its side or tilt towards the left or right.
· Do not apply excessive pressure to cause flexing / bending of frame chassis as it may damage the screen.
· When handling the TV, be careful not to damage the protruding buttons.

(Depending on model)
2 Connect the power cord to a wall outlet.
· Do not apply foreign substances (oils, lubricants, etc.) to the screw parts when assembling the product. (Doing so may damage the product.)
· If you install the TV on a stand, you need to take actions to prevent the product from overturning. Otherwise, the product may fall over, which may cause injury.
· Do not use any unapproved items to ensure the safety and product life span.
· Any damage or injuries caused by using unapproved items are not covered by the warranty.
· Make sure that the screws are inserted correctly and fastened securely. (If they are not fastened securely enough, the TV may tilt forward after being installed.) Do not use too much force and over tighten the screws; otherwise screw may be damaged and not tighten correctly.

Attaching the TV to a Desk
(Depending on model) The TV should be attached to a desk so it cannot be pulled in a forward/ backward direction, potentially causing injury or damaging the product.
A type

Using the Kensington security system
The Kensington security system connector is located at the rear of the TV. For more information of installation and using, refer to the manual provided with the Kensington security system or visit http://www. kensington.com. Connect the Kensington security system cable between the TV and a table.

ENGLISH

4-Screws (Not supplied with TV)
Stand
Desk
· Screw: M5 x L (*L: Table depth + 8~10 mm) ex) Table depth: 15 mm, Screw: M5 x L25 B type

(Depending on model)
Securing the TV to a Wall

2-Screws for Stand Fixing, 2-Washers for Stand Fixing,
2-Nuts for Stand Fixing (Supplied with TV)
Stand
Desk

(Depending on model)
1 Insert and tighten the eye-bolts, or TV brackets and bolts on the back of the TV. · If there are bolts inserted at the eye-bolts position, remove the bolts first.
2 Mount the wall brackets with the bolts to the wall. Match the location of the wall bracket and the eye-bolts on the rear of the TV.
3 Connect the eye-bolts and wall brackets tightly with a sturdy rope. Make sure to keep the rope horizontal with the flat surface.
· Use a platform or cabinet that is strong and large enough to support the TV securely.
· Brackets, bolts and ropes are not provided. You can obtain additional accessories from your local dealer.

ENGLISH

Mounting to the Wall
Attach an optional wall mount bracket at the rear of the TV carefully and install the wall mount bracket on a solid wall perpendicular to the floor. When you attach the TV to other building materials, please contact qualified personnel. LG recommends that wall mounting be performed by a qualified professional installer. We recommend the use of LG’s wall mount bracket. LG’s wall mount bracket is easy to move with cables connected. When you do not use LG’s wall mount bracket, please use a wall mount bracket where the device is adequately secured to the wall with enough space to allow connectivity to external devices. It is advised to connect all the cables before installing fixed wall mounts.

· When installing the wall mounting bracket, it is recommended to cover the stand hole using tape, in order to prevent the influx of dust and insects. (Depending on model)
Stand hole

10 cm

· Remove the stand before installing the TV on a wall mount by performing the stand attachment in reverse.
· For more information of screws and wall mount bracket, refer to the Separate purchase.
· If you intend to mount the product to a wall, attach VESA standard mounting interface (optional parts) to the back
of the product. When you install the set to use the wall
mounting bracket (optional parts), fix it carefully so as not
to drop. · When mounting a TV on the wall, make sure not to install
the TV by hanging the power and signal cables on the back
of the TV. · Do not install this product on a wall if it could be exposed
to oil or oil mist. This may damage the product and cause
it to fall.

ENGLISH

Connections
Connect various external devices to the TV and switch input modes to select an external device. For more information of external device’s connection, refer to the manual provided with each device.
Antenna/Cable
Connect the TV to a wall antenna socket with an RF cable (75 ). · Use a signal splitter to use more than 2 TVs. · If the image quality is poor, install a signal amplifier properly to
improve the image quality. · If the image quality is poor with an antenna connected, try to realign
the antenna in the correct direction. · An antenna cable and converter are not supplied.
Satellite dish
Connect the TV to a satellite dish to a satellite socket with a satellite RF cable (75 ). (Depending on model)
CI module
View the encrypted (pay) services in digital TV mode. (Depending on model) · Check if the CI module is inserted into the PCMCIA card slot in the
right direction. If the module is not inserted properly, this can cause damage to the TV and the PCMCIA card slot. · If the TV does not display any video and audio when CI+ CAM is connected, please contact to the Terrestrial/Cable/Satellite Service Operator.
Other connections
Connect your TV to external devices. For the best picture and audio quality, connect the external device and the TV with the HDMI cable. Some separate cable is not provided.
HDMI
· Supported HDMI Audio format (Depending on model): Dolby Digital / Dolby Digital Plus (32 kHz / 44.1 kHz / 48 kHz), PCM (32 kHz / 44.1 kHz / 48 kHz / 96 kHz / 192 kHz)

USB
It is recommended that you use an external USB HDD with a rated voltage of 5 V of less and a rated current of 500 mA or less.
External Devices
Available external devices are: Blu-ray player, HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC, gaming devices, and other external devices.
· The external device connection may differ from the model. · Connect external devices to the TV regardless of the order of the TV
port. · Refer to the external equipment’s manual for operating instructions. · If you connect a gaming device to the TV, use the cable supplied with
the gaming device. · In PC mode, there may be noise associated with the resolution,
vertical pattern, contrast or brightness. If noise is present, change the PC output to another resolution, change the refresh rate to another rate or adjust the brightness and contrast on the [Picture] menu until the picture is clear. · In PC mode, some resolution settings may not work properly depending on the graphics card. · When connecting via a wired LAN, it is recommended to use a CAT 7 cable. (Only when port is provided.)

ENGLISH

External Speakers
(Depending on model)
EXTERNAL SPEAKER OUT
or AUDIO LINE OUT

Network
(Depending on model)
Wired network connection
This TV can be connected to a Pro:Centric server via the port. After making the physical connection, the TV needs to be set up for network communication. Connect the port of the Modem or Router from Pro:Centric server to the port on the TV.

1
GND RIGHT

LEFT

GND

Broadband Modem

Router

Pro:Centric Server

· Use only with the 3 Pole 3.5 mm Stereo Jack. · Do not connect your headphones or earphones to the port
for connecting an external speaker.

Broadband Modem

Pro:Centric Server
1 Connect the port of the Modem or Router to the port on the TV. · Do not connect a modular phone cable to the port. · Since there are various connection methods, please follow the specifications of your telecommunication carrier or internet service provider.

ENGLISH

Using Button
You can simply operate the TV functions, using the button.

Adjusting the Angle of the TV to suit view
(Depending on model) Swivel 20 degrees to the left or right and adjust the angle of the TV to suit your view.

20°

Basic functions
Power On (Press) Power Off1 (Press and Hold) Menu Control (Press2) Menu Selection (Press and Hold3)
1 All running apps will close. 2 You can access and adjust the menu by pressing the button when
TV is on. 3 You can use the function when you access menu control.
Adjusting the menu When the TV is turned on, press the button one time. You can adjust the Menu items using the button.
Turns the power off. Changes the input source.
Scrolls through the saved programmes.
Adjusts the volume level.

· When adjusting the angle of the product, watch out for your fingers.
– Personal injury may occur if hands or fingers are pinched. If the product is tilted too much, it may fall, causing damage or injury.

ENGLISH

Using Remote Control
The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching the and ends to the label inside the compartment, and close the battery cover. To remove the batteries, perform the installation actions in reverse. Make sure to point the remote control toward the remote control sensor on the TV.
(Depending on model)

* To use the button, press and hold for more than 3 seconds.

(POWER) Turns the TV on or off.

Selects Radio, TV and DTV programme.

Recalls your preferred subtitle in digital mode.

Audio descriptions function will be enabled.

Resizes an image.

(INPUT) Changes the input source.

Number buttons Enters numbers.

Accesses the saved programmes list.

Returns to the previously viewed programme.

Adjusts the volume level.

Accesses your favourite programme list.

Shows programme guide.

(MUTE) Mutes all sounds.

* (MUTE) Accesses the [Accessibility] menu.

Scrolls through the saved programmes.

Moves to the previous or next screen.

Teletext buttons ( teletext.

) These buttons are used for

(HOME) Accesses the Home menu.

(SETTINGS) Accesses the Settings menu.

Accesses the Quick menus.

Navigation buttons (up/down/left/right) Scrolls through menus or options.

Selects menus or options and confirms your input.

Returns to the previous level.

Clears on-screen displays and returns to TV viewing.

Views the information of the current programme and screen.

This function is not supported.

Control buttons (

) Controls media contents.

These access special functions in some menus.

(Some buttons and services may not be provided depending on models or regions.)
11

ENGLISH

(Depending on model)

Selects Radio, TV and DTV programme.

Number buttons Enters numbers.

Accesses the saved programme list.

Returns to the previously viewed programme.

Adjusts the volume level.

Accesses your favourite programme list.

Resizes an image.

Mutes all sounds.

* Accesses the [Accessibility] menu.

Scrolls through the saved programmes.

Moves to the previous or next screen.

Shows programme guide.

Displays and removes hotel interactive menu.

Views the information of the current programme and screen.

Navigation buttons (up/down/left/right) Scrolls through menus

or options.

Selects menus or options and confirms your input.

Accesses the main menus.

(BACK) Returns to the previous level.

Clears on-screen displays and return to TV viewing.

These access special functions in some menus.

Teletext buttons (

) These buttons are used for

teletext.

Recalls your preferred subtitle in digital mode.

Control buttons (

) Controls media contents.

Accesses the AV devices connected with the HDMI

cable through HDMI-CEC. Opens the SIMPLINK menu.

Accesses the Quick menus.

Audio descriptions function will be enabled.

This function is not supported.

(Some buttons and services may not be provided depending on models or regions.)
* To use the button, press and hold for more than 3 seconds.
(POWER) Turns the TV on or off. Adjusts the brightness of the screen to reduce
energy consumption. Selects an AV mode. Changes the input source.

· Do not mix new batteries with old batteries. This may cause the batteries to overheat and leak.
· Failure to match the correct polarities of the battery may cause the battery to burst or leak, resulting in fire, personal
injury, or ambient pollution. · This apparatus uses batteries. In your community there
might be regulations that require you to dispose of these
batteries properly due to environmental considerations.
Please contact your local authorities for disposal or recycling
information. · The product’s internal and external batteries should not be
exposed to excessive heat such as direct sunlight, fire, or
the like.

ENGLISH

Troubleshooting
The software version can be updated for improvement in performance.
Customer needs to ensure the compatibility of customer’s equipment with LGE software. If needed, please consult with LGE and upload revised software version according to the guidance provided by LGE.
Cannot control the TV with the remote control.
· Check the remote control sensor on the product and try again. · Check if there is any obstacle between the product and the remote
control. · Check if the batteries are still working and properly installed ( to
, to ).
No image display and no sound is produced.
· Check if the product is turned on. · Check if the power cord is connected to a wall outlet. · Check if there is a problem in the wall outlet by connecting other
products.
The TV turns off suddenly.
· Check the power control settings. The power supply may be interrupted.
· Check if the auto-off function is activated on the settings related time.
· If there is no signal while the TV is on, the TV will turn off automatically after 15 minutes of inactivity.
When connecting to the PC (RGB/HDMI), no signal is detected.
· Turn the TV off/on using the remote control. · Reconnect the RGB/HDMI cable. · Restart the PC with the TV on.
Abnormal display
· If the product feels cold to the touch, there may be a small”flicker” when it is turned on. This is normal, there is nothing wrong with product.
· This panel is an advanced product that contains millions of pixels. You may see tiny black dots and/or brightly coloured dots (red, blue or green) at a size of 1 ppm on the panel. This does not indicate a malfunction and does not affect the performance and reliability of the product. This phenomenon also occurs in third-party products and is not subject to exchange or refund.
· You may find different brightness and colour of the panel depending on your viewing position(left/right/top/down). This phenomenon occurs due to the characteristic of the panel. It is not related with the product performance, and it is not malfunction.
· Displaying a still image for a prolonged period of time may cause image sticking. Avoid displaying a fixed image on the TV screen for a long period of time.

Generated sound · “Cracking”noise: A cracking noise that occurs when watching or
turning off the TV is generated by plastic thermal contraction due to temperature and humidity. This noise is common for products where thermal deformation is required. · Electrical circuit humming/panel buzzing: A low level noise is generated from a high-speed switching circuit, which supplies a large amount of current to operate a product. It varies depending on the product. This generated sound does not affect the performance and reliability of the product.
· When cleaning the product, be careful not to allow any liquid or foreign objects to enter the gap between the upper, left or right side of the panel and the guide panel. (Depending on model)
· Make sure to wring any excess water or cleaner from the cloth.
· Do not spray water or cleaner directly onto the TV screen. · Make sure to spray just enough of water or cleaner onto a
dry cloth to wipe the screen.
Settings
(The configurable items differ depending on model.) · [Standard] : Displays the picture with natural contrast, brightness and
sharpness levels. · [Basic] : Displays the picture in the manufacturer’s basic setting
which is optimised for normal viewing. · [APS] (Auto Power Save) mode reduces power consumption by using
dimming control. – Energy saving feature like [Energy Saving] [Energy Saving Step]
is switched [Auto], and power use is much less than [Vivid] mode. – The Ambient Light Sensor automatically adjusts the [Panel
Brightness], based on ambient lighting conditions. – In dark viewing conditions, the TV gradually dims according to the
brightness of the light source. A darker screen means less power consumption.

ENGLISH

Specifications

(Depending on country)
Television system
Channel coverage (Band)
Maximum number of storable programmes
External antenna impedance
CI Module (W x H x D)

DVB-S/S2 950~2,150 MHz

Broadcasting Specifications

Digital TV

DVB-S/S2 DVB-T/T2 DVB-C

DVB-C

DVB-T/T2

46 ~ 890 MHz

VHF III: 174 ~ 230 MHz UHF IV: 470 ~ 606 MHz UHF V: 606 ~ 862 MHz S Band II: 230 ~ 300 MHz S Band III: 300 ~ 470 MHz

6,000

2,000

Analogue TV PAL/SECAM B/G, D/K, I
SECAM L
46 ~ 862 MHz

75 100.0 mm x 55.0 mm x 5.0 mm

Operating Temperature Operating Humidity Storage Temperature Storage Humidity

Environment condition

0 °C to 40 °C Less than 80 % -20 °C to 60 °C Less than 85 %

ENGLISH

HDMI-DTV supported mode

Resolution 640 x 480p 720 x 480p 720 x 576p 1280 x 720p 1920 x 1080i
1920 x 1080p

Horizontal Frequency (kHz)
31.46 31.50 31.469 31.50 31.250 37.50 45.00 44.96 28.125 33.75 33.72 56.250 67.50 67.432 27.00 26.973 33.75 33.716

Vertical Frequency (Hz)
59.94 60.00 59.94 60.00 50.00 50.00 60.00 59.94 50.00 60.00 59.94 50.00 60.00 59.94 24.00 23.976 30.00 29.976

RGB-PC supported mode

Resolution
640 x 350 720 x 400 640 x 480 800 x 600 1024 x 768 1152 x 864 1360 x 768 1280 x 10241
1920 x 10801
1 Only 43/49LT34*

Horizontal Frequency (kHz)
31.468 31.469 31.469 37.879 48.363 54.348 47.712 63.981 66.587 67.50

Vertical Frequency (Hz)
70.09 70.08 59.94 60.31 60.00 60.053 60.015 60.020 59.934 60.00

HDMI-PC supported Mode
· PC audio is not supported. · Use HDMI IN 1 for PC mode. (Depending on model)

Resolution
640 x 350 720 x 400 640 x 480 800 x 600 1024 x 768 1152 x 864 1360 x 768 1280 x 10241 1920 x 10801

Horizontal Frequency (kHz)
31.468 31.469 31.469 37.879 48.363 54.348 47.712 63.981 67.50

Vertical Frequency (Hz)
70.09 70.08 59.94 60.31 60.00 60.053 60.015 60.020 60.00

1 Only 43/49LT34*

Component port connecting information

Component ports on the TV Video output ports on DVD player

Y B-Y R-Y

Y Cb Cr

Y Pb Pr

Signal 480i / 576i 480p / 576p 720p / 1080i
1080p

Component O O O O

ENGLISH

My Media Supported Files
· Maximum data transfer rate: 20 Mbps (Mega bit per second) · External supported subtitle formats: *.srt, *.smi, *.sub (Only for
SubViewer 1.0/2.0), *.ass, *.ssa, *.txt
Supported Photo Formats

Extension Item

Resolution

.jpeg, .jpg, .jpe
.bmp
.png

Available File Type
Photo Size
Photo Size Available File
Type
Photo Size

SOF0: Baseline SOF1: Extend Sequential SOF2: Progressive Minimum: 64 (W) x 64 (H) Maximum (Normal Type): 15360 (W) x 8640 (H) Maximum (Progressive Type): 1920 (W) x 1440 (H) Minimum: 64 (W) x 64 (H) Maximum: 9600 (W) x 6400 (H)
Interlace, Non-Interlace
Minimum: 64 (W) x 64 (H) Maximum (Interlace): 1200 (W) x 800 (H) Maximum (Non-Interlace): 9600 (W) x 6400 (H)

· BMP and PNG format files may be slower to display than JPEG. · Non-standard photo/image file may not be displayed.

Supported Audio Formats

File type

Item

Bit rate

mp3 Sample freq.

Support

Bit rate

AAC Sample freq.

Support

Bit rate

M4A Sample freq.

Support

Bit rate

WMA Sample freq.

Support

Bit rate

WMA 10 Channel / Pro Sample freq.

Support Bit rate OGG Sample freq. Support

Info
32 Kbps – 320 Kbps 16 kHz – 48 kHz
MPEG-1, MPEG-2, Layer2, Layer3 Free Format 8 kHz – 48 kHz ADIF, ADTS Free Format 8 kHz – 48 kHz MPEG-4
128 Kbps ~ 320 Kbps 8 kHz – 48 kHz
WMA7, WMA8, WMA9 Standard ~ 768 Kbps
M0: up to 2 Channel @ 48 kHz (Except LBR mode),
M1: up to 5.1 Channel @ 48 kHz, M2: up to 5.1 Channel @ 96 kHz
WMA 10 Pro Free Format 8 kHz – 48 kHz OGG Vorbis

ENGLISH

Supported Video Formats
· Maximum: 1920 x 1080 @ 30p (only Motion JPEG 640 x 480 @ 30p) · H.264/AVC is supported profile level 4.1 or below.

Extension

Codec

.asf

Video

MPEG-4 Part2, XViD, H.264/AVC, VC1(WMV3, WVC1)

.wmv

Audio

WMA Standard, WMA9(Pro), MP3, AAC, AC3

Video MPEG-2, MPEG-4 Part2, XViD, H.264/AVC

.avi

HE-AAC, LPCM, ADPCM, MPEG-1 Layer I,

Audio MPEG-1 Layer II, Dolby Digital, MPEG-1

Layer III (MP3)

.ts, .trp, .tp .mts, .m2ts

Video H.264/AVC, MPEG-2, H.265/HEVC
MPEG-1 Layer I, MPEG-1 Layer II, MPEGAudio 1 Layer III (MP3), Dolby Digital, Dolby
Digital Plus, AAC, HE-AAC

Video MPEG-1, MPEG-2

.vob

Audio

Dolby Digital, MPEG-1 Layer I, MPEG-1 Layer II, DVD-LPCM

.mp4, .m4v Video MPEG-2, MPEG-4 Part2, XVID, H.264/AVC

.mov

Audio AAC, MPEG-1 Layer III (MP3)

Video MPEG-2, MPEG-4 Part2, XViD, H.264/AVC

.mkv

Audio

HE-AAC, Dolby Digital, MPEG-1 Layer III (MP3), LPCM

.mpg, .mpeg Video MPEG-1, MPEG-2

.mpe

Audio

MPEG-1 Layer I, MPEG-1 Layer II, Dolby Digital, LPCM

Video MPEG-1, MPEG-2 .dat
Audio MP2

Video Sorenson H.263, H.264/AVC .flv
Audio MP3, AAC, HE-AAC

Video H.264/AVC, MPEG-4 Part2 .3gp
Audio AAC, AMR(NB/WB)

Open Source Software Notice Information
To obtain the source code that is contained in this product, under GPL, LGPL, MPL, and other open source licenses that have the obligation to disclose source code, and to access all referred license terms, copyright notices and other relevant documents, please visit https://opensource. lge.com. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to [email protected]. This offer is valid to anyone in receipt of this information for a period of three years after our last shipment of this product.
Licenses
Supported licenses may differ by model.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
Manufactured under license from Dolby Laboratories. Dolby, Dolby Vision, Dolby Vision IQ, Dolby Audio, Dolby Atmos, and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.
(Depending on model)

ENGLISH

IR CODES

· This feature is not available for all models.

Code (Hexa)
08
95 30

Function (POWER)

Note
Remote control Button (Power On/Off) Remote control Button Remote control Button

Remote control Button

(INPUT)

Remote control Button

10-19 Number Key 0-9 Remote control Button

Remote control Button

(MUTE)

Remote control Button

Code (Hexa)
40
41
07
06
44
43
28
5B
72 71 63 61 20 21 39 B1 B0 BA 8F 8E 7E 45 91 E8 7C BD

Function

Note Remote control Button Remote control Button

Remote control Button

(SETTINGS) (BACK)

Remote control Button Remote control Button

(HOME)

Remote control Button
Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button

ENGLISH

EXTERNAL CONTROL DEVICE SETUP
RS-232C Setup
· Image shown may differ from your TV. Connect the RS-232C (serial port) input jack to an external control device (such as a computer or an A/V control system) to control the product’s functions externally. Connect the serial port of the control device to the RS-232C jack on the product back panel. · RS-232C connection cables are not supplied with the product.

Phone jack Type
(Depending on model) · You need to purchase the phone-jack to RS-232C cable required for
the connection between the PC and the TV, which is specified in the manual. * For other models, connect to the USB port.
* The connection interface may differ from your TV.
(PC)

RS-232C IN (CONTROL & SERVICE)

(*Not Provided) (Depending on model)

RS-232C IN
(CONTROL & SERVICE)
(TV)

Type of Connector: D-Sub 9-Pin Male

No.

Pin name

1 3.5 V

2 RXD (Receive data)

3 TXD (Transmit data)

4 IR OUT from TV

6 No Connection

7 No Connection (5 V available in some models)

8 No Connection

9 No Connection (12 V available in some models)

ENGLISH

RS-232C Configurations
7-Wire Configurations (Standard RS-232C cable)

3-Wire Configurations (Not standard)

Communication Parameters
· Baud rate: 9,600 bps (UART) · Data length: 8 bits · Parity: None · Stop bit: 1 bit · Communication code: ASCII code · Use a crossed (reverse) cable.

Command Reference List
(Depending on model)

Data Command1 Command2
(Hexadecimal)

1 Power

00 to 01

2 [Aspect Ratio]

(See p. 21)

3 Screen Mute

(See p. 22)

4 Volume Mute

00 to 01

5 Volume Control k

00 to 64

6 [Contrast]

00 to 64

7 [Brightness]

00 to 64

8 [Colour]

00 to 64

9 [Tint]

00 to 64

10 [Sharpness]

00 to 32

11 OSD Select

00 to 01

12 Remote

Control Lock

Mode

00 to 01

13 [Balance]

00 to 64

14 [Colour Temperature]

00 to 64

15 [Energy Saving]

(See p. 24)

16 [Auto Configuration]

17 [Equalizer]

(See p. 24)

18 Tune Command

(See p. 25)

19 Programme [Skip/Add]

00 to 01

20 Key

(See p. 25)

21 Control [Backlight]

00 to 64

22 [Input] select

(See p. 26)

· During USB operations such as DivX or EMF, all commands except Power(ka) and Key(mc) are not executed and treated as NG.

ENGLISH

Transmission / Receiving Protocol
(Depending on Model)
Transmission
(Command1)(Command2)( )([Set ID])( )([Data])(Cr) (Command1): First command to control the TV. (j, k, m or x) (Command2): Second command to control the TV. ([Set ID]): You can adjust the set ID to choose desired monitor ID number in option menu. Adjustment range is 1 to 99. When selecting Set ID`0′, every connected set is controlled. Set ID is indicated as decimal (1 to 99) on menu and as Hexa decimal (0 x 0 to 0 x 63) on transmission/receiving protocol. ([Data]): To transmit command data. Transmit `FF’ data to read status of command. (Cr): Carriage Return
ASCII code `0 x 0D’ ( ): ASCII code `space (0 x 20)’
OK Acknowledgement
(Command2)( )([Set ID])( )(OK)([Data])(x) * The set transmits ACK (acknowledgement) based on this format
when receiving normal data. At this time, if the data is data read mode, it indicates present status data. If the data is data write mode, it returns the data of the PC computer.
Error Acknowledgement
(Command2)( )([Set ID])( )(NG)([Data])(x) * The set transmits ACK (acknowledgement) based on this format
when receiving abnormal data from non-viable functions or communication errors. [Data] 00: Illegal Code

1 Power (Command: k a) To control Power On/Off of the set. Transmission (k)(a)( )([Set ID])( )([Data])(Cr)
[Data] 00: [Off] [Data] 01: [On] Ack (a)( )([Set ID])( )(OK/NG)([Data])(x)
To Show TV is Power On/Off. Transmission (k)(a)( )([Set ID])( )(FF)(Cr)
Ack (a)( )([Set ID])( )(OK/NG)([Data])(x)
* Similarly, if other functions transmit `0 x FF’ data based on this format, Acknowledgement data feed back presents status about each function.
* OK Ack., Error Ack. and other message may display on the screen when TV is power On.
2 [Aspect Ratio] (Command: k c) (Main Picture Size) To adjust the screen format. (Main picture format) You can also
adjust the screen format using the picture settings. Transmission (k)(c)( )([Set ID])( )([Data])(Cr)
[Data] 01: [4:3] (Normal screen – [Just Scan] Off) [Data] 02: [16:9] (Wide screen – [Just Scan] Off) [Data] 06: [Original] ([Just Scan] Off) [Data] 09: [Just Scan] * Please make sure that the model doesn’t support both Vertical Zoom
and All-Direction Zoom mode.
Ack (c)( )([Set ID])( )(OK/NG)([Data])(x)
* Using the PC input, you select either 16:9 or 4:3 screen aspect ratio. * In DTV/HDMI (1080i 50 Hz / 60 Hz, 720p 50 Hz / 60 Hz, 1080p 24 Hz /
30 Hz / 50 Hz / 60 Hz), Component (720p, 1080i, 1080p) mode, [Just Scan] is available. * Full Wide is supported only for Digital, Analogue, AV.

ENGLISH

3 Screen Mute (Command: k d) To select screen mute on/off. Transmission (k)(d)( )([Set ID])( )([Data])(Cr)
[Data] 00: Screen mute off (Picture on) / Video mute off [Data] 01: Screen mute on (Picture off) [Data] 10: Video mute on Ack (d)( )([Set ID])( )(OK/NG)([Data])(x)
* In case of video mute on only, TV will display On Screen Display (OSD). But, in case of Screen mute on, TV will not display OSD.
4 Volume Mute (Command: k e) To control volume mute on/off.
You can also adjust mute using the mute button on remote control.
Transmission (k)(e)( )([Set ID])( )([Data])(Cr)
[Data] 00: Volume mute on (Volume off) [Data] 01: Volume mute off (Volume on) Ack (e)( )([Set ID])( )(OK/NG)([Data])(x)
5 Volume Control (Command: k f) To adjust volume.
You can also adjust volume with the volume buttons on remote control.
Transmission (k)(f)( )([Set ID])( )([Data])(Cr)
[Data] Min: 00 to Max: 64 * Refer to “Real data mapping”.
Ack (f)( )([Set ID])( )(OK/NG)([Data])(x)

6 [Contrast] (Command: k g) To adjust screen contrast.
You can also adjust contrast in the picture settings. Transmission (k)(g)( )([Set ID])( )([Data])(Cr)
Data Min: 00 to Max: 64 * Refer to “Real data mapping”. Ack (g)( )([Set ID])( )(OK/NG)([Data])(x)
7 [Brightness] (Command: k h) To adjust screen brightness.
You can also adjust brightness in the picture settings. Transmission (k)(h)( )([Set ID])( )([Data])(Cr)
Data Min: 00 to Max: 64 * Refer to “Real data mapping”. Ack (h)( )([Set ID])( )(OK/NG)([Data])(x)
8 [Colour] (Command: k i) To adjust the screen colour.
You can also adjust colour in the picture settings. Transmission (k)(i)( )([Set ID])( )([Data])(Cr)
[Data] Min: 00 to Max: 64 * Refer to “Real data mapping”. Ack (i)( )([Set ID])( )(OK/NG)([Data])(x)

ENGLISH

9 [Tint] (Command: k j) To adjust the screen tint.
You can also adjust tint in the picture settings. Transmission (k)(j)( )([Set ID])( )([Data])(Cr)
[Data] Red: 00 to Green: 64 * Refer to “Real data mapping”. Ack (j)( )([Set ID])( )(OK/NG)([Data])(x)
10 [Sharpness] (Command: k k) To adjust the screen sharpness.
You can also adjust sharpness in the picture settings. Transmission (k)(k)( )([Set ID])( )([Data])(Cr)
[Data] Min: 00 to Max: 32 * Refer to “Real data mapping”. Ack (k)( )([Set ID])( )(OK/NG)([Data])(x)
11 OSD Select (Command: k l) To select OSD (On Screen Display) on/off when controlling remotely. Transmission (k)(l)( )([Set ID])( )([Data])(Cr)
[Data] 00: [Off] [Data] 01: [On] Ack (l)( )([Set ID])( )(OK/NG)([Data])(x)

12 Remote Control Lock Mode (Command: k m) To lock the front panel controls on the monitor and remote control. Transmission (k)(m)( )([Set ID])( )([Data])(Cr)
[Data] 00: [Off] [Data] 01: [On] Ack (m)( )([Set ID])( )(OK/NG)([Data])(x)
* If you are not using the remote control, use this mode. When main power is on/off, external control lock is released.
* In the standby mode, if key lock is on, TV will not turn on by power on key of IR & Local Key.
13 [Balance] (Command: k t) To adjust balance.
You can also adjust balance in the audio settings.
Transmission (k)(t)( )([Set ID])( )([Data])(Cr)
[Data] L: 00 to R: 64 * Refer to “Real data mapping”.
Ack (t)( )([Set ID])( )(OK/NG)([Data])(x)
14 [Colour Temperature] (Command: x u) To adjust Colour Temperature. You can also adjust Colour
Temperature in the picture settings. Transmission (x)(u)( )([Set ID])( )([Data])(Cr)
[Data] Warm: 00 to Cool:64 * Refer to “Real data mapping”.
Ack (u)( )([Set ID])( )(OK/NG)([Data])(x)

ENGLISH

15 [Energy Saving] (Command: j q) To reduce the power consumption of the TV. You can also adjust
Energy Saving in picture settings. Transmission (j)(q)( )([Set ID])( )([Data])(Cr)

Power Saving Function
7654

Level Description
3210

Low Power

[Off]

Low Power

[Minimum]

Low Power

[Medium]

Low Power

[Maximum]

Low Power

[Screen Off]

Low Power

[Auto]

[Auto] is available in TV that supports`Intelligent Sensor’. Ack (q)( )([Set ID])( )(OK/NG)([Data])(x)

17 [Equalizer] (Command: j v) To adjust equalizer. Transmission (j)(v)( )([Set ID])( )([Data])(Cr)

MSB

LSB

0000 0 0 00

Frequency

Data

765 000 001 010 011 100

Frequency 1st Band 2nd Band 3rd Band 4th Band 5th Band

4 3 2 10 0 0 0 00 0 0 0 01 … … … … … 1 0 0 11 1 0 1 00

Step 0 (decimal) 1 (decimal)
… 19 (decimal) 20 (decimal)

Ack (v)( )([Set ID])( )(OK/NG)([Data])(x)

16 [Auto Configuration] (Command: j u) (Only RGB support model) To adjust picture position and minimize image shaking
automatically. It works only in RGB (PC) mode. Transmission (j)(u)( )([Set ID])( )([Data])(Cr)
[Data] 01: To set Ack (u)( )([Set ID])( )(OK/NG)([Data])(x)

ENGLISH

18 Tune Command (Command: m a) Select channel to following physical number. Transmission (m)(a)( )([Set ID])( )([Data] 00)( )([Data] 01)( )([Data] 02)(Cr)
[Data] 00: High channel data [Data] 01: Low channel data
ex. No. 47 00 2F (2FH) No. 394 01 8A (18AH), DTV No. 0 Don’t care [Data] 02: (Antenna) 0 x 00: Analogue Main 0 x 10: DTV Main 0 x 20: Radio (Cable) 0 x 80: Analogue Main 0 x 90: DTV Main 0 x A0: Radio (Satellite) 0 x 40: DTV Main 0 x 50: Radio Main Channel data range Min: 00 Max: 270F (0 to 9999) Ack (a)( )([Set ID])( )(OK/NG)([Data])(x)

19 Programme [Skip/Add] (Command: m b) To set skip status for the current Programme. Transmission (m)(b)( )([Set ID])( )([Data])(Cr)
[Data] 00: [Skip] [Data] 01: [Add] Ack (b)( )([Set ID])( )(OK/NG)([Data])(x)
20 Key (Command: m c) To send IR remote key code. Transmission (m)(c)( )([Set ID])( )([Data])(Cr)
[Data] IR CODES Ack (c)( )([Set ID])( )(OK/NG)([Data])(x)
21 Control [Backlight] (Command: m g) To control the backlight. Transmission (m)(g)( )([Set ID])( )([Data])(Cr)
[Data] Min: 00 to Max: 64 Ack (g)( )([Set ID])( )(OK/NG)([Data])(x)

ENGLISH

22 [Input] select (Command: x b) (Main Picture Input) To select input source for main picture. Transmission (x)(b)( )([Set ID])( )([Data])(Cr)
[Data] Structure

MSB 0000 External Input

LSB 0 0 00
Input Number

External Input

Input Number

Ack (b)( )([Set ID])( )(OK/NG)([Data])(x)

Data [DTV] [Analogue] [AV] [Component] [RGB]
[HDMI]
Data Input1 Input2 Input3 Input4

* Real data mapping 00: Step 0
A: Step 10 ([Set ID] 10)
F: Step 15 ([Set ID] 15) 10: Step 16 ([Set ID] 16)
64: Step 100
6E: Step 110
73: Step 115 74: Step 116
CF: Step 199
FE: Step 254 FF: Step 255

The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service.
Model Serial No.
