OLED888 Series Ambilight OLED TV
Product Information: Philips OLED TV Series
The Philips OLED TV Series includes the OLED808, OLED818,
OLED848, and OLED888 models. These televisions are available in the
following sizes:
- 42 inches
- 48 inches
- 55 inches
- 65 inches
The OLED888 model is available in the EU, while the OLED888
model is available in the UK.
The TV series comes with a user manual and a quick start guide.
To register your product and get support, visit
www.philips.com/TVsupport.
The wall mount dimensions for each TV size are as follows:
- 42 inches: 300x300mm M6 (L: 12mm~16mm)
- 48 inches: 300x300mm M6 (L: 10mm~15mm)
- 55 inches: 300x300mm M6 (L: 10mm~15mm)
- 65 inches: 300x300mm M6 (L: 10mm~15mm)
The recommended distance to the wall for the television is 10 to
20 cm.
Product Usage Instructions
- Read the safety instructions in the user manual before using
the television. - Connect your television to a power source using the appropriate
power cable for your region. - Connect your television to an antenna or satellite using the
appropriate cable. - Connect your television to other devices such as a set-top box,
gaming console, or Blu-ray player using the HDMI ports. - Connect your television to a sound system using the digital
audio out port or the audio out port. - If you want to mount your television on a wall, use the wall
mount dimensions provided in the user manual and quick start guide.
Make sure to follow all safety precautions and use the appropriate
tools. - Turn on your television and follow the on-screen instructions
to set up your TV.
Television
Quick Start Guide
OLED808/OLED818 OLED848/OLED888 Series
A 1a 42″/48″/55″
1b 65″
(EU)
OLED888
Television
(UK)
2
3
A
B
Register to nd out more and get support
www.philips.com/TVsupport
Television series
User Manual
42″/48″ (M5xL14) : x7 55″ (M5xL16) : x7 65″ (M5xL14.5) : x7
Register your product and get support at www.philips.com/TVsupport
Television Quick Start Guide
B
4
5 42″/48″/55″/65″
6
7
1
(42″)
(55″/65″)
x4
x2
2 Wall Mount dimensions (x, y)
42″ 300x300mm M6 (L: 12mm~16mm)
105 cm
48″ 300x300mm M6 (L: 10mm~15mm)
121 cm
55″ 300x300mm M6 (L: 10mm~15mm)
139 cm
65″ 300x300mm M6 (L: 10mm~15mm)
164 cm
8
9
10
11
TV
*
L
*
x
x4
y
R
R
L
1
2x AAA LR03 1.5V
2
2x AAA LR03 1.5V
(OLED888)
3
English Read the safety instructions.
Español Lea las instrucciones de seguridad. Polski
Zapoznaj si z instrukcjami
Svenska Läs säkerhetsinstruktionerna.
L
.
Cestina Hrvatski Dansk
Pectte si bezpecnostní pokyny. Procitajte sigurnosne upute. Læs sikkerhedsforskrifterne.
Deutsch Lesen Sie die Sicherheitshinweise.
Français Italiano Latviesu Lietuvi Magyar
Lisez les consignes de sécurité. Leggere le istruzioni di sicurezza. . Izlasiet drosbas nordjumus. Perskaitykite saugos instrukcijas. Olvassa el a biztonsági utasításokat.
bezpieczestwa.
Português Român
Leia as instruções de segurança. Citii instruciunile de siguran. .
Srpski
Procitajte bezbednosna uputstva.
Slovenscina Preberite varnostna navodila.
Türkçe Güvenlik talimatlarini okuyun.
.
FR
.
Eesti
Lugege ohutusnõudeid.
Nederlands Lees de veiligheidsvoorschriften.
Norsk
Les sikkerhetsforskriftene.
Slovenský Precítajte si bezpecnostné pokyny.
Suomi
Lue turvaohjeet.
FEUILLE
COMMON INTERFACE
CAM
USB 2 (42″) USB 3 (48″/55″/65″)
USB 1 (42″) USB 2 (48″/55″/65″)
HDD
3 < = 1m
(OLED888)
HDMI 3/4
POWER (EU)
POWER (UK) SAT (EU) ANTENNA
HDMI 1
4K 120Hz
HDMI 2
ARC/eARC 4K 120Hz
DIGITAL AUDIO OUT
(48″/55″/65″)
NETWORK
DIGITAL
USB 1
AUDIO OUT (48″/55″/65″)
(42″)
TOSLINK
TOSLINK Ultra High-speed HDMI cable
COAXIAL SATELLITE COAXIAL
4
5
(OLED888)
Click
(OLED888)
Wall
TV
Recommended distance to the wall 10 to 20 cm 0cm 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27
(OLED888)
HDMI eARC
ROUTER ROUTER
All registered and unregistered trademarks are property of their respective owners.
Specications are subject to change without notice. Philips and the Philips’ shield emblem are trademarks of Koninklijke Philips N.V. and are used under license from Koninklijke Philips N.V. This product has been manufactured by and is sold under the responsibility of TP Vision Europe B.V., and TP Vision Europe B.V. is the warrantor in relation to this product. 2023© TP Vision Europe B.V. All rights reserved. www.philips.com/welcome
