Caterlite Cc889 3.5 Liter Kettle Instruction Manual

3.5 Litre Kettle
Instruction manual

Safety Tips

• Position on a flat, stable surface.
• A service agent/qualified technician should carry out installation and any repairs if required. Do not remove any components on this product.
• Consult Local and National Standards to comply with the following:
• Health and Safety at Work Legislation
• BS EN Codes of Practice
• Fire Precautions
• IEE Wiring Regulations
• Building Regulations
• Ensure the water level is between the ‘MIN’ and ‘MAX’ marks.
• Always switch off the appliance before lifting, filling or pouring.
• Always use the handle when moving the appliance.
• The body of the appliance becomes hot during use.
• Avoid steam from the spout or when opening the lid.
• Always switch off and disconnect the power supply to the appliance when not in use.
• Keep all packaging away from children. Dispose of the packaging in accordance to the regulations of local authorities.
• If the power cord is damaged, it must be replaced by a CATERLITE agent or a recommended qualified technician in order to avoid a hazard.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Overfilling the kettle may result in boiling water being ejected.
• CATERLITE recommends that this product is connected to a circuit protected by an appropriate RCD (Residual Current Device).

Introduction

Please take a few moments to carefully read through this manual. Correct maintenance and operation of this machine will
provide the best possible performance from your CATERLITE product.

Pack Contents

The following is included:

• CATERLITE Kettle
• Instruction manual

CATERLITE prides itself on quality and service, ensuring that at the time of packaging the contents are supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your CATERLITE dealer immediately.

Operation

Note: Before using the appliance for the first time fill and boil it twice. Discard the water each time.
To use:

1. Lift the lid and fill it with cold water. Do not exceed the ‘MAX’ level.
2. Close the lid securely.
3. Connect the appliance to a mains power supply.
4. Push the power switch down to the ‘I’ position. The power indicator light turns On and the water will begin to boil.
5. When the water has boiled the switch will flick back up to the ‘0’ position. The power indicator light turns Off.

Note: The boiling process can be stopped at any time by manually flicking up the switch.
WARNING: There is a danger of scalding from steam. Take care during operation and when opening the lid.

Cleaning, Care & Maintenance

• Always turn off and disconnect the appliance from the power supply before cleaning.
• Use soapy water and a damp cloth to clean the exterior of the appliance.
• Dry thoroughly after cleaning.
• Periodically clean the inside of the appliance using a suitable descaling solution.

Troubleshooting

Technical Specifications

Electrical Wiring

This appliance is supplied with a 3 pin BS1363 plug and lead.
The plug is to be connected to a suitable mains socket.
This appliance is wired as follows:

• Live wire (colored brown) to the terminal marked L
• Neutral wire (colored blue) to terminal marked N
• Earth wire (colored green/yellow) to terminal marked E

This appliance must be earthed, using a dedicated earthing circuit.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency disconnection being required, they must be readily accessible.

Compliance

The WEEE logo on this product or its documentation indicates that the product must not be disposed of as household waste. To help prevent possible harm to human health and/or the environment, the product must be disposed of in an approved and environmentally safe recycling process.  For further information on how to dispose of this product correctly, contact the product supplier, or the local authority responsible for waste disposal in your area.
CATERLITE parts have undergone strict product testing in order to comply with regulatory standards and specifications set by international,  independent, and federal authorities.
CATERLITE products have been approved to carry the following symbol:

All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic, mechanical, photocopying,  recording or otherwise, without the prior written permission of CATERLITE. Every effort is made to ensure all details are correct at the time of going to press, however, CATERLITE reserve the right to change specifications without notice.

DECLARATION OF CONFORMITY

I, the undersigned, hereby declare that the equipment specified above conforms to the above Territory Legislation, Directive(s), and Standard(s).
Date
Signature
Full Name
Position
Producer Address

13th November 2020
Ashley Hooper	Eoghan Donnellan
Technical & Quality Manager	Commercial Manager/ Importer
Fourth Way, Avonmouth, Bristol, BS118TB United Kingdom	42 North Point Business Park New Mallow Road Cork Ireland

UK
Eire +44 (0)845 146 2887
CC889_ML_A5_v8_20201117
