LAND CRUISER 300
Product Information: Land Cruiser 300
The Land Cruiser 300 is a vehicle built for every road and to
suit every person’s life. It is a powerful and reliable vehicle
that has been part of many families and businesses since its
introduction in 1951. With a global total sales volume of 10
million units, the Land Cruiser has established itself as the king
of 4×4 vehicles.
The Land Cruiser 300 features an elegant design with a bold
front grille and high gloss 20 alloy wheels. Its interior offers
both comfort and convenience, with versatile seat configurations
that can accommodate up to 7 passengers and their luggage. The rear
air conditioning and automatic rear air conditioner enhance
passenger comfort, while a switch allows for automatic stowing of
the third-row seats to create ample storage room.
Under the hood, the Land Cruiser 300 is equipped with
exceptional power. It features a newly developed GA-F platform
based on Toyota New Global Architecture (TNGA) and comes with
turbocharged V6 engines, including gasoline and diesel variants.
These engines offer improved power, torque, and efficiency from a
smaller displacement, contributing to fuel efficiency. The diesel
engine has a power output of 225kW and a maximum torque of 700 Nm,
while the petrol engine has a power output of 305kW and a maximum
torque of 650 Nm.
In addition to its power, the Land Cruiser 300 comes with
advanced technology features for exceptional driving performance.
It includes Multi-Terrain Select with Auto Mode, which allows the
driver to select the most suitable driving mode for different
terrains. The Multi-Terrain Monitor uses four cameras to provide
off-road driving support by capturing the road conditions around
the vehicle. The center display shows a panoramic view of the
vehicle from above, as well as an image featuring guidelines of the
view directly underneath the vehicle.
Product Usage Instructions
To make the most of your Land Cruiser 300, follow these usage
instructions:
- Seating Configuration: The Land Cruiser 300 offers flexible
seating arrangements. You can arrange the seats to suit all
passengers onboard and their luggage being carried. - Rear Air Conditioning: Use the automatic rear air conditioner
to enhance rear passenger comfort. Adjust the settings as per your
preference. - Luggage Room: If you need ample storage room, use the switch to
automatically stow the third-row seats (electric control only)
under the floor. - Powerful Engine: Enjoy the exceptional power of the Land
Cruiser 300’s engine. The diesel engine provides a maximum output
of 225kW and a maximum torque of 700 Nm, while the petrol engine
offers a maximum output of 305kW and a maximum torque of 650
Nm. - Driving Performance: Take advantage of the advanced technology
features for an exceptional driving performance. Use the
Multi-Terrain Select with Auto Mode to select the most suitable
driving mode for different terrains. The Multi-Terrain Monitor
provides a panoramic view of the vehicle from above and helps you
navigate off-road conditions.
By following these instructions, you can fully experience the
power, comfort, and convenience offered by the Land Cruiser
300.
LAND CRUISER 300
A STORY OF INHERITANCE SINCE 1951
MORE POWER
Toyota’s Land Cruiser began with the TOYOTA JEEP BJ SERIES in 1951 and by 2019, the global total sales volume reached 10 million units. In 2021 we celebrate the 70th anniversary of the Land Cruiser series.
The Land Cruiser is a vehicle built for every road and to suit every person’s life. These vehicles are built to carry anything you need to any part of the world no matter how remote or how tough the roads.
This high level of reliability is the reason why this model has been part of so many families and business and will continue to be part of our lives for years to come.
THE KING OF 4X4
CONQUER THE CITY WITH ELEGANCE AND STYLE
With its elegant design, the front grille gives new Land Cruiser a bold look. The high gloss 20″ alloy wheels complements the bold look. Take control!
AN INTERIOR THAT IS BOTH COMFORTABLE AND CONVENIENT
Lush comfort and convenient : why choose when you can have both? Elegant and cosy with noble material. New Land Cruiser provides extra convenience thanks to it’s versatile seat configurations. Travel in style and luxury with up to 7 passengers and all of their luggage.
SEATING CONFIGURATION OPTIONS
All seats can be flexibly arranged to suit all the passengers onboard and their luggage being carried.
REAR AIR CONDITIONING
An automatic rear air conditioner helps enhance
rear passenger comfort.
LUGGAGE ROOM
A switch allows you to automatically stow the third row seats (electric control only) under the floor to
create ample storage room.
EXCEPTIONAL POWER
We developed a new GA-F platform based on Toyota New Global Architecture (TNGA). Newly developed turbocharged V6 engines include gasoline and diesel variants, both offering greatly improved power, torque and efficiency from a smaller displacement compared to the current model. We have achieved a 200 kg weight reduction across the entire vehicle as a result of this initiative to help in fuel efficiency.
Engine 3.3 Diesel F33A-FTV Engine (10 speed Automatic) Power Max output 225kW / 4000 rpm Torque Max torque 700 Nm / 1600-2600 rpm
Engine 3.5 Petrol V35A-FTS Engine (10 speed Automatic) Power Max output 305kW /5200 rpm Torque Max torque 650 Nm / 2000-3600 rpm
V6 3.3 LITRE DIESEL ENGINE WITH 10 SPEED AUTOMATIC TRANSMISSION
The new 3.3 litre Twin Turbo Diesel Engine features smarter and more efficient technology with seamless shifts between single and dual turbo use as well as increased performance.
V6 3.5 PETROL ENGINE
Newly developed AJA0F 10-speed automatic transmission available on both engines enhance driving performance, fuel efficiency, and quietness.
– A newly developed torque converter and high precision lock-up slip control achieve excellent fuel efficiency and smooth acceleration feel matching driver’s intensions. – Cross-over gear ratios, component optimization, and precise highresponse control achieve an excellent shifting feel and exhilarating rhythmic gear shift feel. – The structure and control of the transmission aiming for utilizing a highly efficiency range of the engine reduce slip loss of the torque converter and enhance transmission efficiency.
4WD UPGRADE TO THE TOP
ADVANCED TECHNOLOGY FEATURES FOR AN EXCEPTIONAL DRIVING PERFORMANCE
MULTI-TERRAIN SELECT WITH AUTO MODE
Multi-terrain Select is a revolutionary system that enables you to drive over all kinds of road surfaces. To address the road surface and provide optimal traction, the system selects from five different modes, when the transfer range is in H4, and from four different modes when in L4. In addition, by selecting AUTO mode, the vehicle estimates the current driving surface based on information from various sensors and optimises driving force and suspension control. The driver does not need to change the driving mode to get the best off-road performance.
MULTI-TERRAIN MONITOR
With four cameras installed on the front sides and rear of the vehicle, the system provides off-road driving support by capturing the road conditions arounysd the vehicle, which are often in the driver’s blind spots.
The center display shows the front, rear, left and right of the vehicle, as well as also an image featuring guidelines, of the view directly underneath the vehicle as if the floor were transparent. In addition, a panoramic view will display an image of the vehicle from above.
A Front view B Side view (left & right) C Back view D Panoramic view E Underfloor view
FEEL THE POWER
ELECTRONIC KINETIC DYNAMIC SUSPENSION SYSTEM
The newly developed E-KDSS detects road surface conditions, vehicle speed, and steering operation and automatically and independently locks or frees the front and rear stabilizers. The system performs detailed control according to the detected cornering and road surface conditions to achieve both off-road driving performance and ride comfort as well as on-road handling stability.
FRONT DIFFERENTIAL LOCK
In addition to the rear differenitial lock, there is a new front differential lock. Even on rough roads, when one wheel is lifted off the ground, the system distributes driving force optimally to the grounded tire. This improves escape performance and provides excellent rough-road driving performance
CRAWL CONTROL
Crawl Control helps provide optimal throttle and brake control, maintaining a constant low speed to support safe, sure driving on sand, dirt, rock, snow, mud, steep grades, or other surfaces that require fine accelerator control. Five speeds are offered , with fully automatic throttle and brake control that helps you to concetrate on steering the veicle.
AVS: ADAPTIVE VARIABLE SUSPENSION
Adaptive Variable Suspension System with linear solenoid type enhances ride comfort and driving performance on rough roads. The system adjust damping force according to road conditions from small irregularities to large bumps and dips, thus contributing to enhancing ride comfort, handling stability, and ground covering performance on rough roads
TURN ASSIST FUNCTION
Turn Assist helps to turn the vehicle in response to the driver’s steering, while mainatining a consistently low speed, even in tight corners, which would normally be difficult to pass without a turnaround maneuver.
Connect your smartphone thanks to Apple CarPlay or AndroidAuto on the 12,3″ screen to take the road safely while enjoying your own music with 14 JBL speakers.
40 NATURAL BEIGE
30 BLACK & DARK RED
20 BLACK
PROGRESSION OF LUXURY
ADVANCED SAFETY TECHNOLOGIES
ABS : ANTI-LOCK BRAKE SYSTEM.
ABS operates by preventing the wheels from locking up during braking, thereby maintaining tractive contact with the road surface and allowing the driver to maintain more control over the vehicle.
VSC. VEHICLE STABILITY CONTROL
Vehicle Stability Control. It automatically activates each individual brake as needed and controls engine output to help maintain stability and prevent skidding when turning sharply or cornering on slippery road surfaces.
MORE SAFETY FEATURES
SRS AIRBAGS
Front airbags and knee airbags for the driver and front-seat passenger, side airbags for first and second rows, and curtain-shield airbags for all three rows support passenger safely in the event of a collision.
*Availability of airbags differs depending on vehicle specifications
Passengers and cargo without EBD Passengers and cargo with EBD Driver only with EBD
EBD: ELECTRONIC BRAKE FORCE DISTRIBUTION
Electronic Brakeforce Distribution. Even when there is a difference in front/rear or left/right wheel load, EBD controls brake force on each wheel appropriately and helps to shorten stopping distance. The EBD controls the braking force on the wheels, based on the total number of the occupants, load conditions and during deceleration and cornering, thus offering excellent brake control.
TSC. TRAILER SWAY CONTROL
Trailer Sway Control. It suppresses any trailer sway caused by wind, bumpy roads or steering. whenever you are towing. With sensors detecting yaw, acceleration and steering, TSC uses deceleration control and yaw moment to limit sway. The stop lamps are illuminated to warn drivers behind.
PARKING SUPPORT BRAKE
Parking support brake system provides driving force suppression and brake control for situations where there is a risk of collision with obstacles in front or behind the vehicle when driving at low speeds, such as when parking.
GRADES AND COLORS
202 Black
1G3 GRAY ME
070 WHITE PEARL CS
4V8 AVANT GARDE BRONZE ME
090 PRECIOUS WHITE PEARL
040 SUPER WHITE
8X8 DARK BLUE MC
3Q3 DARK RED M.M
19190055–191459m4m5 mm
218 ATTITUDE BLACK MC
1F7 SILVER ME
16616767–1166878m7mmm 19198800 mmmm
44995500-51-155 1m1m5mm
16618668–1166888m8mmm 11998800mmm m
TECHNICAL SPECIFICATIONS
Description Model Grade Model Code Seating Capacity Body Type
LC 300 GX-R Diesel GX-R FJA300L-GNUAY (D0) 7 SUV
LC 300 VX Diesel VX FJA300L-GNUVY (D3) 7 SUV
LC 300 VX-R Diesel VX-R FJAL-GNUZY (D6) 7 SUV
LC 300 GR-S Diesel GR-S FJA300L-GNUSY (D9) 7 SUV
LC 300 VX Petrol VX VJA300L-GNUVZ (P3) 7 SUV
LC 300 VX-R Petrol VX-R VJA300L-GNUZZ (P6) 7 SUV
Engine Code Number of cylinders and arrangement Engine
Maximum power (kW (HP) @ r/min) Maximum torque (Nm @ r/min) Transmission Gear ratio
Reverse Final drive gear ratio Brakes
F33A-FTV
6-Cyls. V Type
Displacement (cm3) 3346
Capacity (litre)
3.3L
Bore x Stroke (mm) 86.0 x 96.0
Compression ratio 15,4
225(306) @ 4000
700 @ 1600-2600
10AT
1st
4,923
2nd
3.257
3rd
2.349
4th
1.944
5th
1.532
6th
1.193
7th
1.000
8th
0.801
9th
0.661
10th
0.613
4.307
3.307
Front
VENTILATED DISC BRAKE WITH FIXED CALIPER 4-CYLINDER
Rear
VENTILATED DISC BRAKE WITH FLOATING CALIPER 1-CYLINDER
F33A-FTV 6-Cyls. V Type 3346 3.3L 86.0 x 96.0 15,4 225 (306) @ 4000 700 @ 1600-2600 10AT 4,923 3.257 2.349 1.944 1.532 1.193 1.000 0.801 0.661 0.613 4.307 3.307 VENTILATED DISC BRAKE WITH FIXED CALIPER 4-CYLINDER VENTILATED DISC BRAKE WITH FLOATING CALIPER 1-CYLINDER
F33A-FTV 6-Cyls. V Type 3346 3.3L 86.0 x 96.0 15,4 225 (306) @ 4000 700 @ 1600-2600 10AT 4,923 3.257 2.349 1.944 1.532 1.193 1.000 0.801 0.661 0.613 4.307 3.307 VENTILATED DISC BRAKE WITH FIXED CALIPER 4-CYLINDER VENTILATED DISC BRAKE WITH FLOATING CALIPER 1-CYLINDER
F33A-FTV 6-Cyls. V Type 3346 3.3L 86.0 x 96.0 15,4 225 (306) @ 4000 700 @ 1600-2600 10AT 4,923 3.257 2.349 1.944 1.532 1.193 1.000 0.801 0.661 0.613 4.307 3.307 VENTILATED DISC BRAKE WITH FIXED CALIPER 4-CYLINDER VENTILATED DISC BRAKE WITH FLOATING CALIPER 1-CYLINDER
V35A-FTS 6-Cyls. V Type 3445 3.5L 85.5 x 100.0 10,37 305 (415) @ 5200 650 @ 2000-3600 10AT 4,923 3.257 2.349 1.944 1.532 1.193 1.000 0.801 0.661 0.613 4.307 3.307 VENTILATED DISC BRAKE WITH FIXED CALIPER 4-CYLINDER VENTILATED DISC BRAKE WITH FLOATING CALIPER 1-CYLINDER
V35A-FTS 6-Cyls. V Type 3445 3.5L 85.5 x 100.0 10,37 305 (415) @ 5200 650 @ 2000-3600 10AT 4,923 3.257 2.349 1.944 1.532 1.193 1.000 0.801 0.661 0.613 4.307 3.307 VENTILATED DISC BRAKE WITH FIXED CALIPER 4-CYLINDER VENTILATED DISC BRAKE WITH FLOATING CALIPER 1-CYLINDER
Overall vehicle length (mm) Overall vehicle width (mm) Overall vehicle height (mm) Wheelbase (mm) Front Overhang (mm) Rear overhang (mm) Approach angle (*) Front Tread (mm) Minimum ground clearance (mm) Minimum turning circle (tyres, m) Fuel Tank Size (L) Gross vehicle weight (kg)
4950-5115 1980 1905-1945 2850 945 1190 32 1667 235 5,9 138 3230
4950-5115 1980 1905-1945 2850 945 1190 32 1667 235 5,9 138 3230
Dimensions and Capacities 4950-5115 1980 1905-1945 2850 945 1190 24 1667 235 5,9 93 3230
4950-5115 1980 1905-1945 2850 945 1190 32 1667 235 5,9 80 3230
4950-5115 1980 1905-1945
945 1190 32 1667 235 5,9 110 3230
4950-5115 1980 1905-1945 2850 945 1190 24 1667 235 5,9 110 3230
GX-R – STANDARD GRADE
Interior:
2-Zone Auto Air Conditioner Rear climate controls Air cleaner with pre-cleaner Radio AM/FM, MP3, CD, DVD Multimedia touch screen 7 (17.78 cm) Reverse camera (back monitor) Bluetooth audio and hands-free Wifi device support 6 speakers Auxiliary input USB Central cool box Wireless power door lock Power windows (all) one touch up/down and auto jampro Steering wheel controls, multi info, cruise control, audio & tele Leather steering wheel Tilt and telescopic steering adjustment Illuminated entry system Fabric seats, 7 seats, floor mats Moon roof with jam protection Electronic vertical driver seat adjust
VX – on top of GX-R
Interior:
4-Zone Auto Air Conditionner (Front and Rear) Leather feel seats Electronic vertical driver and passenger seat adjust Power tilt and telescopic steering adjustment Power back door (w/close & lock switch) Leather steering wheel with wood imitation Wireless charger for mobile phones Moon roof with jam protection and remote control
VX-R – on top of VX
Interior:
Multimedia touch screen 12.3 (31 cm) 14 speakers, JBL sound system with navigation system Door trim synthetic leather and with wood imitation Ventilated seats for driver and passenger (climate) RSE – Rear Seat Entertainment system, dual Two built-in DVD players in the back with 11.6 monitors Two wireless headphones for Rear Seat Entertainment Multi-Terrain monitor, 4 cameras (front, sides, back) & washer Premium leather seats Ventilated seats for driver, passenger and rear seats
GR-S on top of VX-R
GR-S push start GR-S headrests New Stability Control GR-S Leather seats (with stitching)
Exterior:
Colour painted front and rear bumpers Mud guards (front and rear) Side steps, aluminium Outside mirrors elect adjustable & retractable, colour Roof rails Rear spoiler Spare tire under the vehicle with lock Colour painted door handles Front and rear parking sensors with voice Front and rear parking sensors on display LED Daytime Running Lights Safety: ABS – Anti-lock Braking System EBD – Electronic Brake force Distribution BA – Brake Assist ATRC – Active Traction Control System VSC – Vehicle Stability Control TSC – Trailer Sway Control Anti-Theft system immobilizer and alarm
Exterior:
Front fog lamps (LED) Chromed outside mirrors heated with memory Acoustic windshield glass
Safety: Side airbags (SRS) Curtain airbags (SRS) ISOFIX points for child safety on rear outer seats
Technical: Welcome lightning system
Interior:
Seat heating for driver, passenger and 2nd row seats Power seat adjustments with memory for driver Power seat adjustments for passenger Kick sensor back door opening HDMI audio jack
Exterior: Side steps with illumination Mud guards full cover (only front) Illuminated scuff plates Aero bumpers with chrome details (Front and Rear) Rear fog lamps
265/65R18 GR-S FR & RR Differential Lock Power Back Door W/Pre lock Sw (No kick sensor) GR-S Smart Key
Safety:
Driver & Passenger Airbags (SRS) Technical: LED type main headlamps (low) Smart entry & Start system (keyless entry & start) Push start system Rear differential lock Alloy wheels Tyre dimensions 265/65R18 (71/2J Alumi) Cruise control Integrated sport driving mode (3 Mode) 110L fuel tank capacity (dual 80+30) Power steering wheel 4WD System Optitron gauge lightning Overall width: 1.980 mm Overall length: 4.950 – 5.115 mm Overall height: 1.905 – 1.945 mm Min. ground clearance: 235 mm Min. turning radius (tyre): 5.9 m Min. turning radius (body): 6.3 m
Technical:
BI-LED type main headlamps (low and high) DAC – Downhill Assist Control TA – Turn Assist Crawl Control AIM – AWD Integrated Management Automatic high beam control Headlamp cleaner BSM – Blind Spot Monitoring System Auto headlamp levelling, auto dynamic Auto dimming rear view mirror (day/night) Tyre dimensions 265/65R18 (71/2J Alumi) High Gloss Rain sensor, automatic wipers control
Technical:
E-KDSS – Elect-kinetic Dynamic Suspension system Torque Sensing LSD Tyre dimensions 265/55 R20, alloy wheels TEMS – Toyota Electronic Modulated Suspension AVS – Adaptive Variable Suspension System Integrated sport driving mode (5 Mode) MTS – Multi-Terrain Select Anti-teft with siren intusion and slat sensor Head Up Display (240 x 90 color)
GR-S Mud Guards GR-S Grille and Bumper GR-S Steering Wheel Carbon front console 80L Single Fuel Tank
COMPLETE PEACE OF MIND WITH TOYOTA.
Your Toyota dealership will advise you on your vehicle’s service requirements. It will need a health and safety check at least once a year. An intermediate check is necessary every year or 5,000 km.
All Toyota vehicles are designed and engineered to minimize your maintenance costs. This includes fewer parts that require servicing and, equally important, is that Toyota vehicle technology is made easily accessible so that maintenance labor time is less and pricing is competitive.
Providing the reassurance of Toyota quality, only genuine and approved components are used on your vehicle. If the vehicle is damaged, its design helps minimize the cost of repair because the most expensiveto-replace parts are deliberately located away from common damage zones. The result is ultimately less expense for parts and labor.
Accessories
Toyota genuine accessories are designed and manufactured with the same care, quality and attention to detail as Toyota vehicles. Adding a touch of style, comfort, convenience and practicality, they are tested for exceptional durability to enhance the enjoyment of your new vehicle. All accessories are covered by a 1-year warranty.
Every new Toyota comes with a 3 years or 100,000 km vehicle warranty, which covers any defect caused by a manufacturing fault. Transport to the nearest authorized Toyota repairer will also be covered*. In addition, a 3 years or 100,000 km paint warranty protects against defects and surface rust caused
by a manufacturing fault (except load bin’s which are covered for 1 year). Every Toyota commercial vehicle is covered by a 3 years with unlimited mileage corrosionperforation warranty* against corrosion of body panels caused by a manufacturing fault in materials or workmanship.
Toyota’s comprehensive security system withstands the insurance
attack test. The alarm system and engine immobilizer are approved by major insurance companies.
For more information about the LC300 and quotations, please contact your nearest Toyota dealership.
To the best of our knowledge, all information in this brochure is correct at time of going to print. Details of specifications and equipment provided in this brochure are subject to local conditions and requirements and may, therefore, vary from models available in your area. Please inquire with your local dealership for details on your local specifications and equipment. · Vehicle body colors may differ slightly from the printed photographs in this brochure. · The readability of QR Codes® present in this brochure may differ according to the scanner used. Toyota cannot be held responsible should your device not be able to read any QR Codes® or interactive content markers. · CFAO group reserves the right to alter any details of specifications and equipment without prior notice. · No part of this publication may in any way be reproduced without the prior written approval of CFAO group. 08/2021/LC300/CFAO
