Buyers Guide | Holiday 2009
Acer® H Series Display – Roadmap
Acer® v1.0 – October 16, 2009
Product Name | Acer 20″ Widescreen LCD | Acer 21.5″ Widescreen LCD | Acer 23″ Widescreen LCD | Acer 23″ Widescreen LCD | Acer 24″ Widescreen LCD |
Model Number | H203H Bbmd | H213H bmid | H233H bmid | H235H bmid | H243H bmid |
Viewable Area | 20″ diagonal, 16:9 aspect ratio | 21.5″ diagonal, 16:9 aspect ratio | 23″ diagonal, 16:9 aspect ratio | 23″ diagonal, 16:9 aspect ratio | 24″ diagonal, 16:9 aspect ratio |
Panel Type | LCD Active Matrix TFT | LCD Active Matrix TFT | LCD Active Matrix TFT | LCD Active Matrix TFT | LCD Active Matrix TFT |
Resolutions | 1600 x 900 (native and maximum) | 1920 x 1080 (native and maximum) | 1920 x 1080 (native and maximum) | 1920 x 1080 (native and maximum) | 1920 x 1080 (native and maximum) |
Brightness | 250 cd/m2 | 300 cd/m2 | 300 cd/m2 | 300 cd/m2 | 300 cd/m2 |
Contrast Ratio | 50000:1 | 20000:1 | 40000:1 | 100000:1 | 40000:1 |
Response Time | 5ms | 5ms | 5ms | 2ms | 2ms |
Viewing Angles | 160º Left/Right, 160º Up/Down | 170º Left/Right, 160º Up/Down | 160º Left/Right, 160º Up/Down | 160º Left/Right, 160º Up/Down | 160º Left/Right, 160º Up/Down |
Inputs | 1xVGA 1xDVI 1xPC audio | 1xVGA 1xDVI 1xHDMI, cable included 1xPC audio | 1xVGA 1xDVI 1xHDMI, cable included 1xPC audio | 1xVGA 1xDVI 1xHDMI, cable included 1xPC audio | 1xVGA 1xDVI 1xHDMI, cable included 1xPC audio |
High-Definition Support | 720p | 1080p | 1080p | 1080p | 1080p |
Display Stand | Included (adjustable tilt) | Included (adjustable tilt) | Included (adjustable tilt) | Included (adjustable tilt) | Included (adjustable tilt) |
Speakers | 2 integrated 1W speakers | 2 integrated 1W speakers | 2 integrated 1.5W speakers | 2 integrated 1.5W speakers | 2 integrated 1W speakers |
Mount | VESA mounting compliant (100 x 100mm) | VESA mounting compliant (100 x 100mm) | VESA mounting compliant (100 x 100mm) | VESA mounting compliant (100 x 100mm) | VESA mounting compliant (100 x 100mm) |
Agency Certifications | Energy Star®, UL, cUL, FCC Class B, NOM, CE, TUV/GS, VCCI, RoHS, TCO03 | Energy Star®, UL, cUL, FCC Class B, NOM, CE, TUV/GS, VCCI, RoHS, TCO03 | Energy Star®, UL, cUL, FCC Class B, NOM, CE, TUV/GS, VCCI, RoHS, TCO03 | Energy Star®, UL, cUL, FCC Class B, NOM, CE, TUV/GS, VCCI, RoHS, TCO03 | Energy Star®, UL, cUL, FCC Class B, NOM, CE, TUV/GS, VCCI, RoHS, TCO03 |
Page 2 | Acer® Confidential | v1.0 – October 16, 2009 | |||
Acer® H Series Displays Roadmap
Acer® 23″ Widescreen LCD
Acer® 23″ Widescreen LCD
Acer® 24″ Widescreen LCD
