TX-SR605 AV Receiver AV Amplifier
Product Information: Onkyo AV Receiver/ AV Amplifier
The Onkyo AV Receiver/ AV Amplifier is a high-performance audio
device designed to provide an immersive audio experience. The
product comes with a TX-SR605 AV Receiver and TX-SA605/TX-SA8560 AV
Amplifier. The device features advanced operations and a Zone 2
setup for multi-room audio.
Specifications:
- Model: TX-SR605
- Power Output: 90 watts per channel (8 ohms, 20 Hz-20 kHz, 0.08%
THD, 2 channels driven) - Inputs: 4 HDMI, 3 Component, 5 S-Video, 5 Composite, 7 Digital
audio (4 Optical, 3 Coaxial), 7 Analog audio, 1 Phono - Outputs: 1 HDMI, 1 Component, 3 S-Video, 3 Composite, 2 Digital
audio (1 Optical, 1 Coaxial), 2 Analog audio, 2 Subwoofer
pre-out
Important Safety Instructions:
- Read and keep the instructions manual for future
reference. - Do not expose the device to rain or moisture.
- Do not remove the cover or back of the device as there are no
user-serviceable parts inside. Refer servicing to qualified service
personnel. - Do not use the device near water and do not clean it with a wet
cloth. - Ensure proper ventilation and do not block any ventilation
openings. - Do not install the device near heat sources.
- Do not defeat the safety purpose of the polarized or
grounding-type plug. - Protect the power cord from being walked on or pinched.
- Use only attachments/accessories specified by the
manufacturer. - Unplug the device during lightning storms or when unused for
long periods of time.
Product Usage Instructions:
Before making any connections or plugging in the device, read
the instructions manual thoroughly. Following the instructions in
the manual will enable you to obtain optimum performance and
listening enjoyment from your new AV Receiver/ AV Amplifier.
First Time Setup:
Connect the device to your TV and speakers using the provided
cables. Ensure proper ventilation and do not block any ventilation
openings. Install in accordance with the manufacturer’s
instructions. Connect your sources such as DVD players, Blu-ray
players, and gaming consoles to the device using HDMI, Component,
S-Video, Composite, Digital audio, and Analog audio inputs. Connect
your subwoofers to the Subwoofer pre-out ports.
Basic Operations:
Turn on the device using the power button on the front panel or
remote control. Use the input selector buttons to choose the
desired input source. Adjust the volume using the volume control
knob or remote control.
Advanced Operations:
Refer to the instructions manual for advanced operations such as
setting up multi-room audio, adjusting tone controls, and
customizing sound modes.
Troubleshooting:
If you experience any issues with the device, refer to the
troubleshooting section of the instructions manual.
AV Receiver
TX-SR605
AV Amplifier
TX-SA605 TX-SA8560
Instruction Manual
Thank you for purchasing an Onkyo AV Receiver/ AV Amplifier. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new AV Receiver/ AV Amplifier. Please retain this manual for future reference.
Contents
Introduction………………………………..2 Connections ……………………………..18 First Time Setup ……………………….41 Basic Operations ………………………54 Advanced Operations………………..69 Advanced Setup………………………..70 Zone 2 ………………………………………87 Controlling Other Components ….90 Specifications …………………………..93 Troubleshooting………………………..94
En
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING
AVIS
RISK OF ELECTRIC SHOCK RISQUE DE CHOC ELECTRIQUE
DO NOT OPEN
NE PAS OUVRIR
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over.
PORTABLE CART WARNING S3125A
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15. Damage Requiring Service Unplug the apparatus from the wall outlet and refer servicing to qualified service personnel under the following conditions: A. When the power-supply cord or plug is damaged, B. If liquid has been spilled, or objects have fallen into the apparatus, C. If the apparatus has been exposed to rain or water, D. If the apparatus does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the apparatus to its normal operation, E. If the apparatus has been dropped or damaged in any way, and F. When the apparatus exhibits a distinct change in performance this indicates a need for service.
16. Object and Liquid Entry Never push objects of any kind into the apparatus through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases shall be placed on the apparatus. Don’t put candles or other burning objects on top of this unit.
17. Batteries Always consider the environmental issues and follow local regulations when disposing of batteries.
18. If you install the apparatus in a built-in installation, such as a bookcase or rack, ensure that there is adequate ventilation. Leave 20 cm (8″) of free space at the top and sides and 10 cm (4″) at the rear. The rear edge of the shelf or board above the apparatus shall be set 10 cm (4″) away from the rear panel or wall, creating a fluelike gap for warm air to escape.
2
Precautions
1. Recording Copyright–Unless it’s for personal use only, recording copyrighted material is illegal without the permission of the copyright holder.
2. AC Fuse–The AC fuse inside the unit is not userserviceable. If you cannot turn on the unit, contact your Onkyo dealer.
3. Care–Occasionally you should dust the unit all over with a soft cloth. For stubborn stains, use a soft cloth dampened with a weak solution of mild detergent and water. Dry the unit immediately afterwards with a clean cloth. Don’t use abrasive cloths, thinners, alcohol, or other chemical solvents, because they may damage the finish or remove the panel lettering.
4. Power WARNING BEFORE PLUGGING IN THE UNIT FOR THE FIRST TIME, READ THE FOLLOWING SECTION CAREFULLY. AC outlet voltages vary from country to country. Make sure that the voltage in your area meets the voltage requirements printed on the unit’s rear panel (e.g., AC 230 V, 50 Hz or AC 120 V, 60 Hz). The power cord plug is used to disconnect this unit from the AC power source. Make sure that the plug is readily operable (easily accessible) at all times. Some models have a voltage selector switch for compatibility with power systems around the world. Before you plug in such a model, make sure that the voltage selector is set to the correct voltage for your area.
For American model Pressing the [STANDBY/ON] button to select Standby mode does not fully shutdown the unit. If you do not intend to use the unit for an extended period, remove the power cord from the AC outlet. 5. Never Touch this Unit with Wet Hands–Never handle this unit or its power cord while your hands are wet or damp. If water or any other liquid gets inside this unit, have it checked by your Onkyo dealer. 6. Handling Notes · If you need to transport this unit, use the original
packaging to pack it how it was when you originally bought it. · Do not leave rubber or plastic items on this unit for a long time, because they may leave marks on the case. · This unit’s top and rear panels may get warm after prolonged use. This is normal.
· If you do not use this unit for a long time, it may not work properly the next time you turn it on, so be sure to use it occasionally.
For U.S. models
FCC Information for User
CAUTION: The user changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: · Reorient or relocate the receiving antenna. · Increase the separation between the equipment and
receiver. · Connect the equipment into an outlet on a circuit dif-
ferent from that to which the receiver is connected. · Consult the dealer or an experienced radio/TV tech-
nician for help.
For Canadian Models
NOTE: THIS CLASS B DIGITAL APPARATUS COMPLIES WITH CANADIAN ICES-003. For models having a power cord with a polarized plug: CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
Modèle pour les Canadien
REMARQUE: CET APPAREIL NUMÉRIQUE DE LA CLASSE B EST CONFORME À LA NORME NMB-003 DU CANADA. Sur les modèles dont la fiche est polarisée: ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.
3
