ABOX 1004N Mini Processor

Product Information

The MINI Processor (ABOX 1004N) is a versatile audio processing
unit designed for professional audio applications. It offers
various features and specifications to enhance audio quality and
control.

Sampling Frequency: 48KHz
Phantom Power: 48V
Input Gain: 20-52dB, 7 levels in total
Amplification: MIC Channel 18dBu, LINE Channel
18dBu
Frequency Response: 20Hz-20KHz
Background Noise: -88dBu
Operating Power Supply: DC12V
Dimensions (WxDxH): 180x168x42mm
Total Harmonic Distortion + Noise (THD +N):
MIC Channel 0.005%@4dBu, LINE Channel 0.01%@4dBu
Maximum Output Level: MIC Channel 18dBu, LINE
Channel 24dBu
Digital-analog Dynamic Range: 114dB
Analog-digital Dynamic Range: 114dB
Input Impedance (Balanced): 20 K
Output Impedance (Balanced): 100 – 120
dBu
EIN (A-weighted): 100dB@1KHz, 80dB@80Hz
Channel Isolation: 114dB
Power Consumption: 100W

Product Usage Instructions

To use the MINI Processor (ABOX 1004N) effectively, follow these
instructions:

Ensure the device is connected to a suitable power supply with
DC12V.
Connect your audio sources to the appropriate input channels,
either MIC or LINE.
Adjust the input gain according to your requirements using the
provided 7-level control.
If using condenser microphones, activate the phantom power by
setting it to 48V.
Monitor the audio output levels and adjust the amplification
accordingly. The maximum output levels are MIC Channel 18dBu and
LINE Channel 24dBu.
For optimal audio quality, ensure the input and output
impedance are balanced and set within the specified ranges.
To minimize background noise, keep the device away from
electromagnetic interference sources.
When connecting multiple audio sources, maintain channel
isolation to avoid interference by adjusting the settings as
needed.
The MINI Processor supports a sampling frequency of 48KHz,
providing accurate audio reproduction across the audible
range.
For reference, refer to the provided dimensions (WxDxH) to
determine the appropriate placement for your setup.
To measure the Total Harmonic Distortion + Noise (THD +N), use
the specified input levels (MIC Channel 4dBu, LINE Channel
4dBu).
Take advantage of the wide dynamic range (114dB) for clear and
detailed audio output.
If using A-weighted measurement, refer to the EIN values at
1KHz and 80Hz to assess the device’s noise performance.
Ensure the power consumption remains within the rated limit of
100W to avoid any issues.

View Fullscreen

The MINI Processor

ABOX 1004N

1. Built-in echo cancellation, feedback suppression and noise algorithms. 2. Using a stable two-way simultaneous speech (Double Talk) detection method to effectively eliminate excess echoes even in strong background noise and non-linear distortion environments. 3. Noise suppression algorithm can quickly and accurately track environmental noise changes and maintain good output sound quality. 4. A total of 10-way input signal interface, full-featured audio adjustment module. 5. Providing eight MIC inputs + two line inputs + four outputs, supporting gain adjustment, 48V fantasy power supply, built-in preamplifier, signal generator, expander, compressor, 5-band parametric equalization, 31-band graphic equalization, delay, crossover, limiter and other functional modules. 6. Built-in PC-based control software.

Sampling Phantom Power Input Gain Amplification Frequency Response Background Noise Operating Power Supply Dimensions (WxDxH)
THD +N Maximum Output Level

48KHz

Digital-analog Dynamic Range

48V

Analog-digital Dynamic Range

20-52dB, 7 levels in total

Input Impedance (Balanced)

20-20KHz,±0.5dB

Output Impedance (Balanced)

-88dBu

EIN (A-weighted)

DC12V

Channel Isolation
