AOM Series Fiber Coupled and RF Drivers

User Manual

AOM Series Fiber coupled AOM & RF Drivers

Revision Sheet	Page
Release No.	V1.0 V1.1 V1.2
Date	25/09/2021 11/06/2023
Author	SER SER

1. General Information

Please read this manual carefully. It describes the hazard the
user might be exposed to while using the product. It also explains
in details how to use the product in the safest and most efficient
possible way. The safety of any system incorporating the product is
the responsibility of the assembler of the system. Any actions
taken by the user that is not clearly described in this user manual
might present a risk and is the sole responsibility of said
user.

This product is to be used in laboratory or industrial tasks,
and only by personnel who have followed a training in laser
hazard.

This product is an OEM device for system integration. It is
designed for use as a component (or replacement) part and is
thereby exempt from 21 CFR1040.10 and 1040.11 provisions. Make sure
it is not put in operation before the machine in which it will be
integrated has been declared to be compliant with the relevant
requirements of the current directives.

1.1 Definitions

Caution: A caution is advised when dealing
with hazardous situations, tasks or objects, to prevent harm or
death and avoid material damage or failure.
Warning: A warning is given for potentially
dangerous situation for people which cause them harm or lead to
death.
Note: A note is a complementary piece of
advice that must be acknowledged by the user.

1.2 General Warning

Caution: The compatible laser sources used with
the AOM can deliver up to several Watts of coherent LASER
radiation. Always wear protective goggles and observe the safety
instructions provided by the laser diode supplier when using the
AOM and/or AOM driver with your laser source.

WARNING: Do not try to open or remove the cover
of the AOM or RF driver modules.

WARNING: Avoid all shocks and strains when
handling the AOM.

WARNING: Handle the fiber-optic cables with
care as it is fragile. Do not bend or pinch it.

WARNING: Any settings or hardware tinkering
that is not described in this user manual or in the usage
recommendation may put the user or its environment at risk.

WARNING: The maintenance and servicing of the
AOM should NOT be executed by the end user: only AeroDIODE is able
to maintain the AOM.

2. Safety Instructions

2.1 AOM Safety Instruction

WARNING: Not following the safety
recommendations and the caution mentioned above can lead to eye
damage.

2.2 RF Driver Safety Instruction

Caution: Do not power up the signal output
interface when it is open or shorted. Risk of permanent
damage.
Caution: The product should be well grounded,
otherwise the performance can be affected.
Caution: The product is sensitive to ESD.

2.3 Contact

If you have any question about the AOM module, please contact
AeroDIODE: www.aerodiode.com

View Fullscreen

User Manual
AOM Series Fiber coupled AOM
& RF Drivers
AeroDIODE – Institut d’optique d’Aquitaine – Rue François Mitterrand 33400 Talence – France – Tél.: +33 (0)6 27 69 41 62 www.AeroDIODE.com

Contents
Revision Sheet…………………………………………………………………………………………………………….. 1 1. General information ………………………………………………………………………………………………… 2
1.1 Definitions ………………………………………………………………………………………………………… 2 1.2 General warning ………………………………………………………………………………………………… 2 2. Safety Instructions …………………………………………………………………………………………………… 3 2.1. AOM Safety instruction ………………………………………………………………………………………. 3 2.2. RF Driver Safety instruction ………………………………………………………………………………… 3 2.3. Contact …………………………………………………………………………………………………………….. 4 3. Package Content ……………………………………………………………………………………………………… 4 4. Absolute Maximum Ratings ………………………………………………………………………………………. 4 4.1. AOM ………………………………………………………………………………………………………………… 4 4.2. RF Driver …………………………………………………………………………………………………………… 4 5. Installation ……………………………………………………………………………………………………………… 4 5.1. AOM installation ……………………………………………………………………………………………….. 5 5.2. RF Driver installation ………………………………………………………………………………………….. 5 6. Specifications ………………………………………………………………………………………………………….. 7

Revision Sheet

Release No. V1.0 V1.1 V1.2

Date 25/09/2021 11/06/2023

Author SER SER

Revision Description
First version Second version Third version highlight the critical RF power level

Disclaimer : Information in this document is subject to change without notice.

Page 1/12 v3.3

1. General information
Please read this manual carefully. It describes the hazard the user might be exposed to while using the product. It also explains in details how to use the product in the safest and most efficient possible way. The safety of any system incorporating the product is the responsibility of the assembler of the system. Any actions taken by the user that is not clearly described in this user manual might present a risk and is the sole responsibility of said user.
This product is to be used in laboratory or industrial tasks, and only by personnel who have followed a training in laser hazard.
This product is an OEM device for system integration. It is designed for use as a component (or replacement) part and is thereby exempt from 21 CFR1040.10 and 1040.11 provisions. Make sure it is not put in operation before the machine in which it will be integrated has been declared to be compliant with the relevant requirements of the current directives :
· 2006/25/CE (following for example the regulation NF EN 60825-1) (Europe) · 21 CFR1040.10 and 1040.11 provisions (USA)
1.1 Definitions
Caution : A “caution” is advised when dealing with hazardous situations, tasks or objects, to prevent harm or death and avoid material damage or failure.
Warning : A “warning” is given for potentially dangerous situation for people which cause them harm or lead to death
Note : A note is a complementary piece of advice that must be acknowledged by the user.
1.2 General warning
Caution The compatible laser sources used with the AOM can deliver up to several Watts of coherent LASER radiation. Always wear protective goggles and observe the safety instructions provided by the laser diode supplier when using the AOM and/or AOM driver with your laser source.
WARNING Do not try to open or remove the cover of the AOM or RF driver modules.
Page 2/12 v3.3

WARNING Avoid all shocks and strains when handling the AOM WARNING Handle the fiber-optic cables with care as it is fragile. Do not bend or pinch it. WARNING Any settings or hardware tinkering that is not described in this user manual or in the usage recommendation may put the user or its environment at risk. WARNING The maintenance and servicing of the AOM should NOT be executed by the end user : only AeroDIODE is able to maintain the AOM.
2. Safety Instructions
2.1. AOM Safety instruction
WARNING Not following the safety recommendations and the caution mentioned above can lead to eye damage.
2.2. RF Driver Safety instruction
Caution Do not power up the signal output interface when it is open or shorted. Risk of permanent damage. Caution The product should be well grounded, otherwise the performance can be affected. Caution The product is sensitive to ESD.
Page 3/12 v3.3

2.3. Contact
If you have any question about the AOM module, please contact AeroDIODE : www.aerodiode.com

3. Package Content
The AOM modules comes with: · 1 AOM module with 900 µm fiber and 2* FC/APC fiber connectors. · A USB Key with the current user manual in pdf
The Driver part comes with : · An SMA-SMA cable to connect the Driver to the AOM · A special cable with Banana plugs to connect to a benchtop power supply

4. Absolute Maximum Ratings

4.1. AOM

· Optical power (CW) : refer to the AOM model Datasheet

Storage temperature -40 to +85

Operating temperature 0 to +60

· Caution : Applying a maximum RF power (voltage) above the maximum efficiency can

lead to AOM permanent damage. As a first test level : a maximum RF power below

2W must be securely set.

4.2. RF Driver

· Operating voltage: +25V

· Control signal levels from 0 to +5.5V

Storage temperature -40 to +85

Operating temperature 0 to +60

5. Installation

Page 4/12 v3.3

5.1. AOM installation
1. Wear safety Googles 2. Wear a proper and working ESD wrist strap; 3. Caution : Set the module on a heat dissipating surface (an optical table works fine). Letting
the AOM in air with no dissipating surface leads to overheating and permanent damage. 4. The light can be inserted in any direction. The performance are the same (insertion loss,
extinction ratio etc.) 5. Caution : when using another RF driver, The RF power shall not be set over the maximum
diffraction efficiency level. A power over 2W can lead to a permanent damage. The RF power must be adjusted progressively from 0 V up to the maximum diffraction level.
5.2. RF Driver installation
The product is dissipated by conducting heat. The product shall be mounted on a metal structure using fixing screws. The mounting surface shall be flat with minimum size and thickness. A certain amount of space should be reserved around and above the product.
The product is powered by a DC of + 24V, and the power connector is supplied with a per-centric capacitor; The core of the heart capacitor is connected to the positive power supply, and the grounding sheet of the heart capacitor is connected to the negative pole of the power supply. The characteristic impedance of the product signal output port is 50 .
The product receives both external pure analog and/or digital modulation.
The adjustment of RF output power is achieved by changing the resistance of a multi-turner : turn clockwise to increase the output power, turn counterclockwise to decrease the output power.
1. Make sure the RF Driver has the correct RF frequency required by the AOM model (model 1 : 100 MHz, model 2 : 200 MHz, model 3 : 80 MHz ; model 4 : 200 MHz).
2. Make sure the RF Driver model is the one you need (TTL input or Analog input). 3. Connect the RF driver to the AOM with the SMA cable. If you use the modular model
RFAOM-TA-200, set the S1-S4 switch to the proper configuration (see below ) 4. Caution : Place the module on a heat dissipating surface (an optical table works fine).
Letting the RF driver in air with no dissipating surface leads to overheating and permanent damage. 5. Connect a 24V >0.5A power supply to the RF driver 6. Caution : The RF power shall not be set over the maximum diffraction efficiency level. A power over 2W rapidly leads to a permanent damage. The RF drivers power level (little
Page 5/12 v3.3

screw) is normally set in a safe area allowing a correct diffraction efficiency. If ever it is adjusted, this must be done progressively from 0 V up to the maximum diffraction level. 7. Connect the trigger signal and make sure you apply the good electric signal :
· TTL 5V-50 Ohm for standard RF-AOM-T-xxx model, · Analog 0-5V signal for RF-AOM-A-xxx · Any signal (0-5V or 0.1V) for the modular RFAOM-TA-200 model 8. If you need to optimize the insertion loss, apply a small optical CW signal at the proper wavelength and apply a CW trigger signal to the RF Driver. Use a screwdriver (Ø 3mm Multiturn) to adjust the RF power to get maximum optical power at the output of the AOM.
Figure 1 Example of integration of standard model (either RF_AOM-T-xxx or RF_AOM-A-xxx ) at either 80, 100 or 200 MHz :
Page 6/12 v3.3

Figure 2 : Model RFAOM-TA-200 S1-S4 settings
RFAOM-TA-200 Configuration switch :
· S1Down : TTL high ; Up : TTL low input signal configuration setting · S2Down : TTL mode active ; Up : TTL mode disabled · S3Down : Analog input range : 0 -1V ; Up : Analog input range 0 – 5V. · S4Down : Analog mode active ; Up : Analog mode disabled

6. Specifications
6.1. AOM Modules :

Model 1, 3, 5, 7 : Standard version (ex model 7 : 1030/1064 nm )

Reference: 1064AOM-1
SPECIFICATIONS Material
Wavelength (model 7) Max Average optical power
Insertion loss (model 7) Extinction ration (1st order
on/off) Return loss (RF ON)
Rising time Frequency Frequency shift RF Power Input Impedance Electrical input interface Fiber type Fiber length

Unit
nm W dB dB dB ns MHz MHz W
m

Min 1000

Typ. TeO2 1064

1.5

40 45 100
+/- 100 1.5 50 SMA
PM980 1

Technology/Crystal : TeO2*

Maximum

Comments

1090 3 2.0

Customizable

50
1.8
Customizable Customizable

Page 7/12 v3.3

Pigtail termination

Working temperature

°C

Storage temperature

°C

Dimensions (without fiber boots)

Mounting holes diameter

*: See our tutorial : fiber modulator

FC/APC

-20

-30

60*25*12.5

Customizable

Model 2, 4, 6 8 : High speed version (ex : model 8 : 1030/1064 nm)

Reference: 1064AOM-2
SPECIFICATIONS Material
Wavelength (model 8) Max average optical power
Insertion loss Extinction ration (1st order
on/off) Return Loss (RF ON)
Rising time Frequency Frequency shift RF Power Input Impedance Electrical input interface Fiber type Fiber length Pigtail termination Working temperature Storage temperature Dimensions (without fiber
boots) Mounting holes diameter
*: See our tutorial : fiber modulator

Unit
nm W dB dB dB ns MHz MHz W
m
°C °C mm mm

Min 1000 2.0

Technology/Crystal : TeO2*

Typ. TeO2 1064
2.5 2.5

Maximum
1090 3 3.0

Comments Customizable

9.5

200

+/- 200

2.5

SMA

PM980

FC/APC

-20

-30

Customizable Customizable Customizable

67*23*15

2.5

Model 9, 11, 13 : Standard version (ex : model 11 : 1550 nm)

Reference: 1550AOM-1
SPECIFICATIONS Material
Wavelength (model 11) Average optical power
handling Peak optical power handling
Insertion loss

Unit
nm W KW dB

Min 1520
2.0

Technology/Crystal : TeO2*

Typ. TeO2 1550

Maximum 1580

Comments Customizable

0.5

2.5

3.0

Page 8/12 v3.3

Extinction ration (1st order on/off)
Rising time Frequency Frequency shift RF Power Input Impedance Electrical input interface Fiber type Fiber length Pigtail termination Working temperature Storage temperature Dimensions (without fiber
boots) Mounting holes diameter
*: See our tutorial : fiber modulator

dB ns MHz MHz W
m
°C °C mm mm

50 80

+/- 80

2.5

SMA

PM1550

FC/APC

-20

-30

60*25*12.5

Customizable Customizable Customizable

Model 10, 12, 14 : High speed version (ex : model 14 : 1550 nm )

Reference: 1550AOM-2
SPECIFICATIONS Material
Wavelength (model 14) : Average optical power handling
Peak optical power handling Insertion loss
Extinction ration (1st order on/off)
Rising time Frequency Frequency shift RF Power Input Impedance Electrical input interface Fiber type Fiber length Pigtail termination Working temperature Storage temperature Dimensions (without fiber
boots) Mounting holes diameter
*: See our tutorial : fiber modulator

Unit
nm W KW dB dB ns MHz MHz W
m
°C °C mm mm

Technology/Crystal : TeO2*

Min 1520

Typ. TeO2 1550

Maximum 1580

Comments Customizable

0.5

4.0

4.5

5.0

9.5

200

+/- 200

SMA

PM1550

FC/APC

-20

-30

Customizable Customizable Customizable

45*28*12

Page 9/12 v3.3

6.2. RF Drivers :
Model 1 : Standard version for digital (TTL) Input trigger ; 3 RF models : 80, 100 or 200 MHz

Reference: RFAOM – T 80, 100 or 200 (MHz)

SPECIFICATIONS Output Frequency

Unit MHz

Min

Typ. Maximum

80 or 100 or 200 MHz

Output power

0.1

2.8

Impedance matching Extinction ratio Synchro Input
Synchro input interface RF to AOM interface Working voltage Dimensions Interhole distances / Hole diameters

Ohm
V mm mm

50 >70 dB
Digital (TTL) SMA SMA
24 81*58.5*15
75*52.5 / 4

Comments Choose your version
Adjustable with a screwdriver

Model 2 : Standard version for analog (0-5V) input trigger ; 3 RF models : 80, 100 or 200 MHz

Reference: RFAOM – A 80, 100 or 200 (MHz)

SPECIFICATIONS

Unit Min

Typ. Maximum

Comments

Page 10/12 v3.3

Output Frequency
Output power
Impedance matching Extinction ratio Synchro Input
Synchro input interface RF to AOM interface Working voltage Dimensions Interhole distances / Hole diameters

MHz W
Ohm
V mm mm

80 or 100 or 200 MHz

0.1

2.8

50 >30 dB
Analog (0-5V) SMA SMA
24 81*58.5*15

75*52.5 / 4

Choose your version Adjustable with a screwdriver

Page 11/12 v3.3

Model 3 : Special version ; for AOMs with 200 MHz RF signal only
· Adjustable RF power (multi-turner)

· S1 : TTL high / TTL low input
· S2 : TTL mode active/inactive
· S3 : Analog input range : 0-1V / 0-5V S4 : Analog mode active/inactive

Reference: RFAOM – TA – 200

SPECIFICATIONS Output Frequency

Unit MHz

Output power

Impedance matching Synchro Input
Extinction ratio (Analog mode / TTL mode)
Synchro input interface RF to AOM interface Working voltage Dimensions Interhole distances / Hole diameters

Ohm
V mm mm

Min

Typ. Maximum

Comments

200 MHz

0.1

2.8

Adjustable with a screwdriver

TTL (high or low), Analog (0-1V) and Analog (0-5V)

30 dB / 70 dB

SMA SMA
24 103*54*20.5

97*48 / 3.3
