Brainlit Saga Luminaire Pendant Installation Guide

Saga Luminaire Pendant

Product Information:

The product is a luminaire that comes with a driver touch
protection and a diffusor. It has WAGO connectors for power
connection and LED cables for light source. The luminaire can be
disassembled for maintenance or replacement of parts.

Product Usage Instructions:

1. Before disassembling, unplug the power connection to the
   luminaire by pulling apart the WAGO connectors.
2. Take down the luminaire by following the DA DA -+ DA + D-A L L
   N N pattern.
3. Using a screwdriver with a PH2 head, unscrew the screw(s) on
   the driver touch protection. Press down the cable securing button
   on the driver to unplug the LED cables.
4. To remove the diffusor, slightly tilt it. Do not use force or
   any sharp objects.
5. Unplug the light source(s) by pressing down the centre and
   pulling. Unscrew the screws holding the light source(s) with a
   suitable bit and a screwdriver.
6. If replacing the light source, attach the new light source and
   remount the luminaire by following these instructions in
   reverse.
7. Recycle all parts accordingly.

Disassembly instructions

STEP 1 Unplug the power connection to the luminaire by pulling apart the WAGO connectors.

pull

pull

Saga
STEP 2 Take down the luminaire.

DA DA -+

DA +

D-A

L

L

N

N

STEP 3 Unscrew the screw(s) on the driver touch protection using a screwdriver with a PH2 head.
Unplug the LED cables by pressing down the cable securing button on the driver.
STEP 3 Remove the diffusor from the luminaire by slightly tilting.
N.B. Don’t use force or any sharp objects.
STEP 4 Unplug the light source(s).

unscrew

press down and…

…pull

press down centre and pull

STEP 5

unscrew

Unscrew the screws holding the light source(s) with a suitable bit and a screwdriver.

STEP 6 Recycle all parts accordingly.
If replacing the light source; attach new light source and remount the luminaire by following this instruction in reverse.
