BC-USB-02
NI-MH + LI-ION FAST
BATTERY CHARGER
BC-USB-02
Pure Power www.energenie.com
Specifications
- Input: 5 V / 2 A, 9 V / 2 A or 12 V / 1.5 A ( Micro-USB + TYPE-C) Auto adaption
Output: - Li-ion normal mode: 0.5A x 4, 1.0A x 2, 2.0A x 1 (in the 3rd or 4th slot)
- Li-ion fast charge mode: 0.75A x 4, 1.5A x 2, 3.0A x 1 (in the 3rd or 4th slot)
- Ni-MH/Ni-CD: 1A x 4
Compatible with: - Li-ion: 26650, 22650, 18650, 18500, 17500, 14500, 16340
- Ni-MH / Ni-CD: A, AA, AAA, SC, C
- Channel: 1-4 pcs independent channel
- Charging Indicators: 4-level LED (25%, 50%, 75%,100% charging status)
Charging mode: - Li-ion constant current, constant voltage
- Ni-MH / Ni-CD: constant current pulse
- Operating temperature: 0-40°C
- Dimensions: 110 x 105 x 39 mm
- Weight: 142 g
Declaration of conformity
This product is tested and complies with the essential requirements of the laws of member states concerning EMC (2014/30/EU), ROHS (2011/65/EU). The CE declaration can be found under
www.gembird.eu
