RHB 6050 Hand Blender with Grater
Hand Blender with Grater
User Manual
The Hand Blender with Grater is available in three models: RHB
6050, RHB 6050 K, and RHB 6050 S. The product is suitable for
contact with food and has a power source of 220-240 V~, 50-60 Hz.
The power of the product is 1500 W, and it has insulation II class.
The product comes with a motor body, start/turbo button, chopping
blade, measuring cup, pushing apparatus, gear box, gear box button,
chopper hopper cover, grater and chopping knives, grater disc,
shredding knife, accessory shaft, process chamber, container lock,
beater accessory holder, and whisking blade.
Usage Instructions
First Operation
Before using the Hand Blender with Grater for the first time,
please read the user manual carefully. Make sure that all
components are assembled correctly and securely before use.
Intended Use
The Hand Blender with Grater is intended for use in personnel
kitchen areas in shops, offices and other working areas, ranches,
areas used by customers in mobile settings, bedrooms and breakfast
locations. The product can be used for blending, whisking,
chopping, and grating.
Blending
Insert the blending blade into the process chamber. Place the
ingredients into the container and attach it to the motor body.
Press the start/turbo button to begin blending. For best results,
use the start/turbo button intermittently.
Whisking
Insert the whisking blade into the accessory shaft. Attach the
accessory shaft to the motor body and place the ingredients into
the container. Press the start/turbo button to begin whisking. For
best results, use the start/turbo button intermittently.
Chopping
Insert the chopping blade into the process chamber. Place the
ingredients into the container and attach it to the motor body.
Press the start/turbo button to begin chopping. For best results,
use the start/turbo button intermittently.
Using the Grater Disc
Insert the grater disc into the process chamber. Place the
ingredients into the container and attach it to the motor body.
Press the start/turbo button to begin grating. For best results,
use the start/turbo button intermittently.
Important Safety and Environmental Instructions
Children should not use or tamper with the Hand Blender with
Grater. Cleaning and user maintenance should not be carried out by
children. The product must not be used by children. Follow all
safety instructions to prevent hazards that can result in injury or
property damage. Any warranty is void if safety instructions are
not followed. Do not immerse the appliance, power cord, or plug in
water or any other liquids. The product has protection class
against electric shock, and there is a warning of electric shock.
Recycle the product and packaging according to local
regulations.
Hand Blender with Grater
User Manual
RHB 6050 / RHB 6050 K / RHB 6050 S EN
01M-8818941100-1922-06 01M-8818931100-1922-06 01M-8819031100-1922-06
Please read this guide first!
Dear Customer, Thank you for choosing an Arçelik product. We would like you to achieve the optimal efficiency from this high quality product which has been manufactured with the state of the art technology. Please make sure you read and understand this guide and supplementary documentation fully before use and keep it as a reference. Include this guide with the unit if you hand it over to someone else. Observe all warnings and information herein and follow the instructions. Keep in mind that this user guide may apply to several product models. The guide clearly indicates any variations of different models.
Symbols and their meanings
Following symbols have been used throughout this guide:
Important information and beneficial advices regarding the usage of the device.
WARNING: Warnings about hazards to life and property.
Suitable for contact with food.
Do not immerse the appliance, the power cord or the plug in water or in any other liquids.
Protection class against electric shock.
Warning of electric shock.
RECYCLED & RECYCLABLE PAPER
7 2 1 3
4
5
6
8
9 10
15 11 12
16 14 13
1. Motor body 2. Start/Turbo Button 3. Chopping Blade 4. Measuring cup 5. Pushing Apparatus 6. Gear Box 7. Gear Box Button 8. Chopper Hopper Cover 9. Grater and Chopping Knives 10. Grater Disc 11. Shredding Knife 12. Accessory Shaft 13. Process Chamber 14. Container Lock 15. Beater Accessory Holder 16. Whisking blade
Technical data
Model
RHB 6050 – RHB 6050 K – RHB 6050 S
Power Source 220-240 V~, 50-60 Hz
Power
1500 W
I n s u l a t i o n II class
The values provided with the appliance or its accompanying documents are laboratory readings in accordance with the respective standards. These values may differ depending on the use and ambient conditions.
CONTENTS
1 Important safety and environmental instructions 6
1.1 General Safety …………………………………. 6 1.2 Compliance with WEEE regulations and waste disposal ………………………………………………. 8 1.3 Packaging information ……………………… 8 1.4 What to do for energy saving ……………… 8
2 Use
9
2.1 First Operation…………………………………. 9 2.2 Intended use……………………………………. 9 2.3 Blending……………………………………….. 10 2.4 Whisking ………………………………………. 11 2.5 Chopping………………………………………. 12 2.6 Using the grater disc ……………………….. 14
3 Cleaning and Maintenance 16
3.1 Cleaning………………………………………… 6 3.2 Storage ………………………………………… 17 3.3 Transportation and shipping………………. 17
Hand Blender with Grater / User Manual
5 / EN
1 Important safety and environmental instructions
This section contains safety instruc- be encountered. Children should
tions to prevent hazards that can not tamper with the appliance.
result in injury or property damage. Cleaning and user maintenance
Any warranty is void if these instruc- must not be carried out by chil-
tions are not followed.
dren. This appliance may not be
1.1 General safety
used by children.
·This appliance complies with in- ·Store the appliance and its elec-
ternational safety standards. trical cord out of the reach of
·This appliance is not designed children.
for commercial use, it is in- ·Do not use the appliance if the
tended for use at home and in power cord, the appliance or the
similar applications as specified appliance blade is damaged.
below:
Contact authorised service.
– In personnel kitchen areas in shops, offices and other working ar-
·Use only original parts or parts recommended by the manufac-
eas,
turer.
– Ranches,
·Do not disassemble the appli-
– Areas used by customers in mo- ance.
tels and hotels, and other residential ·Your mains power supply should
settings,
be in align with the specified in-
– Bedrooms and breakfast loca- formation on the type tag of the
tions.
appliance.
·Appliance may be used by per- ·Do not use the appliance with
sons with limited physical, per- an extension cord.
ceptual or mental abilities or persons with a lack of experience and knowledge if they are
·Do not unplug the appliance by pulling on the cord.
supervised or given instructions ·When it is left unattended, be-
on the operation of the appliance fore attaching/detaching acces-
and any relevant risks they may sories, or before cleaning, wait
6 / EN
Hand Blender with Grater / User Manual
1 Important safety and environmental instructions
for the moving parts to stop and lead the blades to become blunt
unplug the power cord of the very rapidly.
appliance.
·Follow all warnings to avoid in-
·Do not touch the plug of the juries due to misuse.
appliance while your hands are ·Do not touch the accessories
damp or wet.
while emptying the container,
·Do not use the appliance for hot during cleaning and after use,
meals.
without stopping the blades and
·Warning: Your product is equipped with a safety thermic for protection. Your product will automatically stop due to over-
unplugging the product. Handle the chopping blade carefully, trying to hold it only by its plastic part.
heating in long-term use. After ·After cleaning, dry the appliance
a short cooling period, you can and all its components before
restart your appliance.
connecting it to power and in-
·Use the appliance only with the stalling the components.
provided rubber base and the ·Do not immerse the appliance,
bowl.
the power cord or the plug in
·Do not operate the device for water or in any other liquids.
more than 30 seconds without ·Do not operate the appliance or interruption. After starting, let it its components over or near hot rest for 3 minutes before using surfaces or do not put on such
it again. Do not operate the ap- surfaces. pliance with the empty bowl. ·If you keep the packaging mate·To avoid damaging the blades rials, keep them out of the reach and the appliance, remove of children.
bones and seeds from foods.
·The appliance is not suitable for dried or rough food that may
Hand Blender with Grater / User Manual
7 / EN
1 Important safety and environmental instructions
1.2 Compliance with the WEEE regulations and waste disposal
This product does not contain the dangerous and prohibited materials indicated in “Waste Electrical and Electronic Equipment Control Regulation” published by Ministry of Environment and Urbanisation of the Republic of Turkey. Complies with WEEE Regulations. This product was manufactured from recyclable and reusable high quality parts and materials. Therefore, do not dispose of this product with other domestic wastes at the end of its life cycle. Take it to a collection point for recycling of electrical and electronic equipment. You can ask your local administration about these collection points. You can help protect the environment and natural resources by delivering the used products for recycling.
1.3 Packaging information
The product’s packaging is made of recyclable materials, in accordance with the National Legislation. Do not dispose of the packaging waste with the household waste or other wastes, dispose it to the packaging collection areas specified by local authorities.
1.4 What to do for energy saving
Observe the recommended periods specified in the manual during use. Unplug the appliance after each use.
8 / EN
Hand Blender with Grater / User Manual
2 Operation
2.1 First operation
Remove all packaging and labeling materials and dispose of them in accordance with the applicable law. Clean the device before using the device for the first time (see “Cleaning and Care”). Use the appliance in an upright position on a stable, flat, clean, dry and non-slip surface.
2.2 Intended use
· This appliance is designed for household use only. It should not be used for commercial purposes. · Do not use the appliance for any purpose other than its intended use. · This appliance is intended for slicing and blending food only.
· Unplug the appliance when not in use. · When you first press the trigger, it switches to the “operating” position, and when you
press the trigger all the way, it switches to the “turbo” function.
2.3 Blending
Warnings: · Do not touch the sharp parts of knives with bare hands · Make sure that the chopping blade is fully seated on the motor unit. Keep the device upright while mixing ingredients in the mixing bowl.
You can use your hand blender to prepare sauces, soups, mayonnaise, baby food, milkshakes, etc.
Put small pieces of the food you want to puree or blend into the measuring cup (4).
Attach the chopping blade (3) to the motor body (1) by turning it counterclockwise until it locks. Plug in the appliance.
Insert the chopping blade (3) into the measuring cup (4) containing the ingredients and start the device by pressing the low or high speed start button.
Hand Blender with Grater / User Manual
9 / EN
2 Operation
· If the ingredients stick to the sides of the plastic container, remove them with a spatula and continue mixing.
Turn the appliance off and unplug it.
Remove the chopping blade (3) from the Turn the chopping blade (3) clockwise
measuring cup (4).
to detach it from the motor unit (1).
2.4 Whisking
You can use the whisk attachment to whip cream, egg whites, ready-made dessert batter, etc.
Fit the whisking blade (16) into the whisker accessory holder (15) so that it clicks into place.
Attach the whisking blade holder (15) to the motor body (1) by turning it counterclockwise. Plug in the appliance.
Put the ingredients you want to process into the measuring cup (4).
10 / EN
Hand Blender with Grater / User Manual
2 Operation
Insert the whisking blade (16) into the measuring cup (4) containing the ingredients and press and hold the start button (2).
2.5 Chopping
When finished, release the start button (2) and unplug the appliance.
Remove the whisking blade (16) from the measuring cup (4). Separate the whisking blade (16) from the motor body (1) by turning it clockwise.
Warnings: · Do not crush extremely hard ingredients such as coffee beans, ice, coconut, cereals or bones. Remove the stems of the plants, the shell of the walnut, and the bone, nerve and cartilage of the meat.
· You can use it to shred minced meat, cheese, onion, mint and similar herbs, garlic, carrots, walnuts, almonds, prunes, etc.
· Do not touch the blades with bare hands. The blades are very sharp.
Place the processing chamber (13) on a flat surface.
Insert the shredding blade (11) into the processing chamber (13).
Chop large pieces of food into small pieces before putting the ingredients into the processing chamber (13).
Hand Blender with Grater / User Manual
11 / EN
2 Operation
2 1
Place the chopper hopper cover and Fit the motor body (1) onto the gearbox Plug in the appliance and press and
gearbox (6) on the hopper (13).
(6) by turning it clockwise.
hold the start button (2).
Warnings: · Make sure that the container lock (14) is fully engaged with the chopper hopper lid (8).
· If hot liquid is poured into the hopper, care must be taken as sudden vaporization may occur. Do not put food with a temperature higher than 70°C into the hopper and operate the product for a maximum of 30 minutes with food at this temperature.
· When you first press the trigger, it switches to the “operating” position, and when you press the trigger all the way, it switches to the “turbo” function.
1 2
When finished, release the start button and unplug the appliance from the power outlet.
To remove the motor body (1), turn the motor housing counterclockwise to remove it.
To remove the chopper bowl cover (8), first slide the latch (7) on the gearbox to the right and remove the attachment (6). Then press the container lock (14) and remove the hopper lid (8) by turning it.
12 / EN
Hand Blender with Grater / User Manual
2 Operation
Carefully remove the shredding blade (11).
2.6 Using the grater disk
You can use the grater and slicer blades to grate and slice ingredients such as cucumber, zucchini, carrot, eggplant.
2
1
Hold the grater and chopping blade (9) facing upwards and insert it into the grater disc (16).
Insert the accessory carriage shaft (12) into the fixed shaft in the processing chamber (13) and then insert the grater disc (10).
Then close the chopper hopper cover (8).
Hand Blender with Grater / User Manual
13 / EN
2 Operation
· Push gently from the bottom to remove the grater blade (9) from the disk (10). · A “click” is heard when the chopper bowl lid (8) is fully closed.
Fit the motor housing (1) onto the gearbox (6) by turning it clockwise.
Plug in the appliance. Place your food in the feed opening and push it with the pushing attachment (5), press and hold the start button (2) and pass it through the grater.
Warnings: · Never use your fingers, fork, knife, etc. to push. · Do not attach the blades (11) to the accessory carrier shaft (12) while grating.
1 2
When finished, wait for the disk (10) to stop and unplug it from the socket.
To remove the motor housing (1), turn the motor body counterclockwise to remove it.
To remove the chopper bowl cover (8), first slide the latch (7) on the gearbox to the right and remove the attachment (6). Then press the container lock (14) and remove the hopper lid (8) by turning it.
14 / EN
Hand Blender with Grater / User Manual
2 Operation
Holding the accessory carriage shaft (12), remove it together with the grater disk (10) and remove your food from the processing bowl (13).
Hand Blender with Grater / User Manual
15 / EN
3 Cleaning and maintenance
3.1 Cleaning
Warnings: · Never place the gearbox under running water and never put it in the dishwasher. · Never use gasoline, solvents, abrasive cleaners, metal objects, or hard brushes to clean the appliance. · Do not touch the chopping blades with bare hands. The blades are very sharp. Use any brush during cleaning! · Do not place the product body and the power cord in water or other liquids, do not put them under running water and never put them in the dishwasher. · You can wash the surfaces of the shredder bar that enter the chamber under the tap, but be careful not to get water on the inner surfaces.
Turn the appliance off and unplug it.
Wait for the appliance to completely cool down.
Clean the motor unit (3), whisk holder (17) and lockable cover (7) with a damp soft cloth and then wipe dry.
16 / EN
Hand Blender with Grater / User Manual
3 Cleaning and maintenance
Wash the pusher (5), shredding blade (11), accessory shaft (12), processing bowl (13), grater blade (9), grater disc (10), whisking blade (16), shredding blade (3) and measuring cup (4) in warm water with detergent. The container lid can be washed in the dishwasher.
Dry the washed parts with a dry cloth before putting them away.
It is easier to clean the appliance right after using it.
3.2 Storage
· If you do not plan to use the appliance for a long period of time, please store it carefully. · Ensure that the appliance is unplugged, cooled down completely. · Do not wrap its cable around the appliance. · Store the appliance in a cool and dry environment. · Keep the appliance out of the reach of children.
3.3 Transportation and shipping
· During transportation and shipping, carry the appliance with its original packaging. The packaging of the appliance will protect the appliance against physical damage.
· Do not place heavy objects on the device or its packaging. The appliance may get damaged. · If the appliance is dropped, the appliance may not operate or permanent damage may occur.
Hand Blender with Grater / User Manual
17 / EN
