E62-M3 MID Power 2T2R Digital Radio
Product Information
Product Name: E62-M3
Power: Mid Power
Radio: 2T2R Digital Radio
Output Power: Up to 40dBm
Supported Band: B41
Product Usage Instructions
1. Ensure that the device is compliant with Part 15 of the FCC
Rules. It should not cause harmful interference and must accept any
interference received.
2. Install and operate the device with a minimum distance of
80cm between the radiator and your body to comply with FCC
radiation exposure limits.
3. Make sure the socket-outlet is easily accessible.
4. Connect the A3 Access Unit, E3-O Optical Expansion Unit, and
M3 Mid Power Remote Unit as per the supported configurations.
5. The E62-M3 is a digital transport platform designed for B41
operation using the CPRI protocol over fiber optic cable.
6. The power amplifier technology used in this platform is
Digital Pre-Distortion, which improves power consumption compared
to analogue technology.
7. The E62-M3 supports multi-operator multiband deployments of
cellular services.
8. Key Features:
- Supports 2T2R Digital Radio
- Supports Full band41 SISO Single Fiber Link
- Up to 40dBm Output Power
- Supports External Alarm
- 5GNR Compliant
9. The system supports various configurations and has the
following technical specifications:
- Maximum RF Bands per Access Unit: 4
- Maximum RF Bands per Remote Unit: 1
- Maximum Access Units per System: 3 (1 x Primary A3 / 2 x
Secondary A3) - Maximum E3s per Primary A3: 8
- Maximum M3RUs per E3: 14
- Maximum Cascaded Level: 6
- Maximum IBW Band Selective Mode: 200MHz (280M by firmware
upgrade) - Channel Selective Mode: 100MHz, @1MHz step
- Fiber transmission Capacity: LTE: 5/10/15/20 MHz NR:
5/10/15/20/30/40/50/60/70/80/90/100 MHz - Filter Bandwidth Basic Units Occupied: 48 Basic Units
- M3RU DSP Capacity: 25M
- Filter Bandwidth DSP Units occupied: 25
- Maximum Carriers Supported per Band: N/A
- System Delay Adjustment System Delay (A3+E3+M3): N/A
- VSWR Supported Configurations: Configuration B41 MIMO
E62-M3
MID POWER
2T2R Digital Radio Up to 40dBm Output Power Support B41
Revision History
Revision Number
1.0.0
Revision Date
Summary of Changes
E62-M3
2T2R Digital Radio Support B41
Author
Copyright © 2023 Sunwave All rights reserved.
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission from Sunwave. All copyright, confidential information, patents, design rights and all other intellectual property rights of whatsoever nature contained herein are and shall remain the sole and exclusive property of Sunwave. The information furnished herein is believed to be accurate and reliable. However, no responsibility is assumed by Sunwave for its use, or for any infringements of patents or other rights of third parties resulting from its use. The Sunwave and CrossFire names and logos are trademarks or registered trademarks of Sunwave. All other trademarks are the property of their respective owners.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 80cm between the radiator & your body.
The socket-outlet shall be easily accessible.
Corning Optical Communications
E62-M3 Specification Sheet | Page 2
E62-M3
2T2R Digital Radio Support B41
Overview
Everon E62-M3 is a digital transport platform dedicated for B41 operation supporting cellular technologies on fiber optic cable using the CPRI protocol. The power amplifier technology adopts Digital Pre-Distortion, allowing for a significant improvement in power consumption compared with analogue technology. This platform is ideal for multi-operator multiband deployments of cellular services.
Key Features
2T2R Digital Radio Support Full band41 SISO Single Fiber Link
Up to 40dBm Output Power Supports External Alarm 5GNR Compliant
System Elements
A3 Access Unit
E3-O Optical Expansion Unit
M3 Mid Power Remote Unit
Corning Optical Communications
E62-M3 Specification Sheet | Page 3
Block Diagram
E62-M3
2T2R Digital Radio Support B41
Technical Specifications
System
Maximum RF Bands per Access Unit Maximum RF Bands per Remote Unit Maximum Access Units per System Maximum E3s per Primary A3 Maximum M3RUs per E3 Maximum Cascaded Level Maximum IBW Band Selective Mode
Channel Selective Mode
Fiber transmission Capacity Filter Bandwidth Basic Units Occupied M3RU DSP Capacity Filter Bandwidth DSP Units occupied Maximum Carriers Supported per Band System Delay Adjustment System Delay (A3+E3+M3) VSWR
Supported Configurations
Configuration B41 MIMO
Corning Optical Communications
CH1 2496-2690M
4
1
3 (1 x Primary A3 / 2 x Secondary A3)
8
14
6
200MHz, (280M by firmware upgrade)
100MHz, @1MHz step
LTE: 5/10/15/20 MHz NR: 5/10/15/20/30/40/50/60/70/80/90/100 MHz
48 Basic Units
25M
25<BW50M
50<BW75M
1
2
3
12 DSP Units per Band
25M
25<BW50M
50<BW75M
1
2
4
4
Up to 80.00µs
12µS
<1.6
75<BW100M 4
75<BW100M 4
CH2 2496-2690M
E62-M3 Specification Sheet | Page 4
E62-M3
2T2R Digital Radio Support B41
B41 SISO
2496-2690M
NC
1. CH1 & CH2 is combined inside M3, only one RF ANT port. Each CH has 37dBm output power.
Forward Path (Downlink)
Output Power per Band Maximum Gain Maximum Input Power EVM Manual Attenuation Control
39 ± 2dBm for B41 39 ± 3dB for B41 +15dBm (with AGC operating) / 0dBm (without AGC operating) <3.5% @ 256 QAM 35dB @ 1dB/step (A3: 20dB, M3: 15dB)
Corning Optical Communications
E62-M3 Specification Sheet | Page 5
Technical Specifications
Reverse Path (Uplink)
Output Power per Band Maximum Gain Maximum Input Power Manual Gain Control Noise Figure IIP3
Interfaces
M3 Antenna Interface M3 RF coupling port A3 RF Interface Optical Connector Type Optical Transmission Rate Optical Fibre Length Physical Alarms Maintenance Interface
Electrical
Complies with EMC Safety Maximum Power Consumption (A3/E3/M3) Power Supply
Environmental
Mean Time Between Failure (MTBF) Operating Temperature (A3/E3) Operating Temperature (M3) Humidity Cooling Installation
Mechanical
A3 (Width / Height / Depth / Weight) With package E3 (Width / Height / Depth / Weight) With package M3 (Width / Height / Depth / Weight) With package
Corning Optical Communications
E62-M3
2T2R Digital Radio Support B41
-11 ± 2dBm for B41 39 ± 3dB for B41 -35dBm 35dB @ 1dB/step (AU: 20dB, M3: 15dB) 6dB@max Gain -22dBm
4.3-10 Female QMA Female QMA Female SFP28, Standard LC 24.33024 Gb/s 10km RJ45 (2x in, 2x out) Ethernet RJ45
3GPP TS36.106 | 3GPP TS25.106 EN 301489-1 / -50, FCC 47 CFR 1.1307(b), FCC 47 CFR 1.310 EN 62368-1 60W / 40W / 200W 100-240V AC, 50/60Hz | 48VDC ± 20%
>220,000 hours -10°C to +50°C / 14°F to +122°F -40°C to +55°C / -40°F to +131°F 0% to 90% (Non-Condensing) Convection A3/E3: Wall or 19″ Rack | M3: Wall, Pole, 19″ Rack
440mm / 88mm / 329mm / 6.5kg, 17.32in / 3.46in / 12.95in / 14.33lb 555mm / 140mm / 535mm / 8.0kg, 21.85in / 7.09in / 21.06in / 17.64lb 440mm / 44mm / 220mm / 5.0kg, 17.32in / 1.73in / 8.66in / 11.02lb 555mm / 140mm / 370mm / 7.0kg, 21.85in / 7.09in / 14.57in / 15.43lb 330mm / 126mm / 250mm / 14.0kg, 13.00in / 4.96in / 9.84in / 30.86lb 555mm / 320mm / 430mm / 18.0kg, 21.85in / 12.60in / 16.93in / 39.68lb
E62-M3 Specification Sheet | Page 6
