Quickstart
This is a
secure
Alarm Sensor
for
.
Please make sure the internal battery is fully charged.
Important safety information
Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law.
The manufacturer, importer, distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other material.
Use this equipment only for its intended purpose. Follow the disposal instructions.
Do not dispose of electronic equipment or batteries in a fire or near open heat sources.
What is Z-Wave?
Z-Wave is the international wireless protocol for communication in the Smart Home. This
device is suited for use in the region mentioned in the Quickstart section.
Z-Wave ensures a reliable communication by reconfirming every message (two-way
communication) and every mains powered node can act as a repeater for other nodes
(meshed network) in case the receiver is not in direct wireless range of the
transmitter.
This device and every other certified Z-Wave device can be used together with any other
certified Z-Wave device regardless of brand and origin as long as both are suited for the
same frequency range.
If a device supports secure communication it will communicate with other devices
secure as long as this device provides the same or a higher level of security.
Otherwise it will automatically turn into a lower level of security to maintain
backward compatibility.
For more information about Z-Wave technology, devices, white papers etc. please refer
to www.z-wave.info.
Product Description
PRODUCT HIGHLIGHTS:- Quick and reliable open/close alerts sent to your Z-Wave hub- NEW 700 series chip for faster communication and more battery life than ever- Extra small for discreet mounting- Waterproof case available for outdoor installs (sold separately)- Powered by a single coin battery- The latest S2 security and SmartStart for secure set-up- Supports OTA firmware updatesPRODUCT SPECS:- Model Number: ZSE41- Z-Wave Frequency: 908.42 MHz- Power: 1 x CR2032 battery- Operating Temperature: 32104 F- Dimensions: 1.9 x 1 x 0.3 (magnet: 1.26 x 0.3 x 0.3)- Range: Up to 130 feet line of sight – Installation and Use: Indoor or outdoor with waterproof case (sold separately)
Prepare for Installation / Reset
Please read the user manual before installing the product.
In order to include (add) a Z-Wave device to a network it must be in factory default
state. Please make sure to reset the device into factory default. You can do this by
performing an Exclusion operation as described below in the manual. Every Z-Wave
controller is able to perform this operation however it is recommended to use the primary
controller of the previous network to make sure the very device is excluded properly
from this network.
Inclusion/Exclusion
On factory default the device does not belong to any Z-Wave network. The device needs
to be added to an existing wireless network to communicate with the devices of this network.
This process is called Inclusion.
Devices can also be removed from a network. This process is called Exclusion.
Both processes are initiated by the primary controller of the Z-Wave network. This
controller is turned into exclusion respective inclusion mode. Inclusion and Exclusion is
then performed doing a special manual action right on the device.
Quick trouble shooting
Here are a few hints for network installation if things dont work as expected.
- Make sure a device is in factory reset state before including. In doubt exclude before include.
- If inclusion still fails, check if both devices use the same frequency.
- Remove all dead devices from associations. Otherwise you will see severe delays.
- Never use sleeping battery devices without a central controller.
- Dont poll FLIRS devices.
- Make sure to have enough mains powered device to benefit from the meshing
Association – one device controls an other device
Z-Wave devices control other Z-Wave devices. The relationship between one device
controlling another device is called association. In order to control a different
device, the controlling device needs to maintain a list of devices that will receive
controlling commands. These lists are called association groups and they are always
related to certain events (e.g. button pressed, sensor triggers, …). In case
the event happens all devices stored in the respective association group will
receive the same wireless command wireless command, typically a ‘Basic Set’ Command.
Association Groups:
Group NumberMaximum NodesDescription
| 1 | 3 | The XS Sensor supports Group 1 for Lifeline communication to send open/close notifications. |
| 2 | 5 | This device will send a Basic Set command to Group 2 whenever it detects a change in the open/close status. It sends an ON command when OPEN status is detected and OFF command when CLOSED status it detected. |
Configuration Parameters
Z-Wave products are supposed to work out of the box after inclusion, however
certain configuration can adapt the function better to user needs or unlock further
enhanced features.
IMPORTANT: Controllers may only allow configuring
signed values. In order to set values in the range 128 … 255 the value sent in
the application shall be the desired value minus 256. For example: To set a
parameter to 200 it may be needed to set a value of 200 minus 256 = minus 56.
In case of a two byte value the same logic applies: Values greater than 32768 may
needed to be given as negative values too.
Parameter 1: LED Indicator Mode
Turn the LED indicator for open/close status change on or off.
Size: 1 Byte, Default Value: 1
SettingDescription
| 0 | LED indicator wont blink when the sensors status is changed from open to close and vice versa |
| 1 | LED indicator will blink when the sensors open/close status is changed(default) |
Parameter 3: Battery report
Battery report threshold %
Size: 1 Byte, Default Value: 10
SettingDescription
| 1 – 50 | % |
Parameter 4: Low Battery Alarm
Low battery alarm report
Size: 1 Byte, Default Value: 20
SettingDescription
| 10 – 50 | % |
Parameter 5: Status Notification on Magnet Closure
Decide which status should the sensor report to the hub when the magnet touches the sensor.
Size: 1 Byte, Default Value: 0
SettingDescription
| 0 | closed status reported when the magnet is by the sensor (default) |
| 1 | open status reported when the magnet is by the sensor. |
Parameter 6: Group 2 ON report delay
Set the delay before the sensor sends the ON basic set command to devices in Group 2 after the door is open.
Size: 4 Byte, Default Value: 0
SettingDescription
| 0 – 3600 | seconds |
Parameter 7: Group 2 OFF report delay
Set the delay before the sensor sends the OFF basic set command to devices in Group 2 after the door is closed.
Size: 4 Byte, Default Value: 0
SettingDescription
| 0 – 3600 | seconds |
Technical Data
| Hardware Platform | ZGM130 |
| Device Type | Notification Sensor |
| Network Operation | Reporting Sleeping Slave |
| Firmware Version | HW: 1 FW: 1.00 |
| Z-Wave Version | 7.13.9 |
| Certification ID | ZC12-21080282 |
| Z-Wave Product Id | 0x027A.0x7000.0xE001 |
| Firmware Updatable | Updatable by Consumer by RF |
| Outdoor Use | ok |
| Color | White |
| Security V2 | S2_UNAUTHENTICATED ,S2_AUTHENTICATED |
| Frequency | XXfrequency |
| Maximum transmission power | XXantenna |
Supported Command Classes
- Association Grp Info V3
- Association V3
- Battery
- Configuration V4
- Device Reset Locally
- Firmware Update Md V5
- Indicator V3
- Manufacturer Specific V2
- Multi Channel Association V4
- Notification V8
- Powerlevel
- Security 2
- Sensor Binary V2
- Supervision
- Transport Service V2
- Version V3
- Wake Up V2
- Zwaveplus Info V2
Explanation of Z-Wave specific terms
- Controller — is a Z-Wave device with capabilities to manage the network.
Controllers are typically Gateways,Remote Controls or battery operated wall controllers. - Slave — is a Z-Wave device without capabilities to manage the network.
Slaves can be sensors, actuators and even remote controls. - Primary Controller — is the central organizer of the network. It must be
a controller. There can be only one primary controller in a Z-Wave network. - Inclusion — is the process of adding new Z-Wave devices into a network.
- Exclusion — is the process of removing Z-Wave devices from the network.
- Association — is a control relationship between a controlling device and
a controlled device. - Wakeup Notification — is a special wireless message issued by a Z-Wave
device to announces that is able to communicate. - Node Information Frame — is a special wireless message issued by a
Z-Wave device to announce its capabilities and functions.
