Aeric Aerp101aw Portable Air Conditioner User Manual

AERP101AW Portable Air Conditioner

Product Information:

  • Product: Portable Air Conditioner
  • Model: AERP101AW
  • Cooling Capacity: 10,000 BTU SACC / 14,000 BTU ASHRAE
  • Recommended for spaces up to 700 sq. ft.
  • Dimensions (inches): 16.3 (W) x 13.5 (L) x 28.1 (H)
  • Total Weight: 74.5 lbs
  • Dehumidification Capacity: 108 pints/day
  • Fan Settings: Three
  • Air Flow – High: 260 CFM
  • Adjustable Thermostat
  • 6-Ft. Power Cord
  • Power Requirements: 115V/11.9A/1400W
  • Programmable Timer: 1-24 hours
  • Noise Level: 53 dbA (Max)
  • Warranty: 2 Year Limited

Product Usage Instructions:

  1. Unpack all the items included in the box:
  • 1x Air Conditioner Unit
  • 1x Window Venting Kit
  • 1x Window Venting Hose
  • 1x Remote
  • 2x Triple-A Batteries
  • 1x Manual
  • Choose a suitable location for the portable air conditioner
    near a window.
  • Attach the window venting kit to the air conditioner unit.
  • Connect the window venting hose to the venting kit and extend
    it to the window.
  • Securely install the window venting kit in the window
    opening.
  • Plug in the power cord into a standard electrical outlet.
  • Turn on the portable air conditioner using the remote or
    control panel buttons.
  • Set the desired temperature using the adjustable
    thermostat.
  • Select the fan setting according to your preference.
  • Use the programmable timer to schedule automatic operation for
    up to 24 hours.
  • To dehumidify the room, activate the dehumidification
    mode.
  • Monitor and adjust the air conditioner settings as needed.
  • When finished, turn off the air conditioner and unplug it from
    the power outlet.
  • Portable Air Conditioner
    AERP101AW
    Cooling Capacity: 10,000 BTU SACC / 14,000 BTU ASHRAE For spaces up to 700 sq. ft.

    Included in box:
    1x Air Conditioner Unit 1x Window Venting Kit 1x Window Venting Hose 1x Remote 2x Triple-A Batteries 1x Manual

    Dimensions (in.): 16.3 (W) x 13.5 (L) x 28.1 (H) Total Weight: 74.5 lbs

    Features

    Dehumidification
    108 (pints/day)

    Fan Settings
    Three

    Air Flow – High
    260 CFM

    Adjustable Thermostat
    61-89 °F

    6-Ft. Power Cord
    115V/11.9A/1400W

    Programmable Timer
    1-24 hour

    Noise Level
    53 dbA (Max)

    Warranty
    2 Year Limited
