HJH55B Single Mode Bluetooth
User Manual
Remote control function description
| Button label | Features |
| 1 | The motor runs to the TV position with one button (no initial value). Multiplexing function: long-press the TV for about 3s, the backlight flashes, the buzzer sounds, and the current motor position is recorded to the TV. (Not cleared after power failure) |
| 2 | The motor runs to the LOUNGE position with one key (no initial value). Multiplexing function: long press LOUNGE for about 3s, the backlight flashes, the buzzer sounds, and the current motor position is recorded to LOUNGE. (Not cleared after power failure) |
| 3 | The motor runs to the ZG position with one key (no initial value). Multiplexing function: long press ZG for about 3s, the backlight flashes, the buzzer sounds, and the current motor position is recorded to ZG. (Not cleared after power failure) |
| 4 | The head motor extends. |
| 5 | The head motor retracts. |
| 6 | The foot motor extends. |
| 7 | The foot motor retracts. |
| 8 | The head and foot motors are extended. |
| 9 | The head and foot motors are retracted. |
| 10 | Press the flashlight to turn on, release the flashlight to turn off. |
| 11 | The motor runs to the M position with one key (no initial value). Alternate function: Long press M for about 3s, the backlight flashes, the buzzer sounds, and the current motor position is recorded to M. (Not cleared after power failure) |
| 12 | One-key reset, all motors retract to the minimum stroke position and reset after power-on. |
| Coding method: 1. Long press [remote control head up + foot up (4, 6) + control box code matching key] the buzzer will sound, indicating successful code matching. 2. The control box code key has no reset function. | |
Precautions:
To protect the reliability and safety of the motor and control box, do not switch the buttons frequently.
Caution:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
