DRS-1215 14 Outlet Economy Network Server Surge Protector
Product Information: 14-Outlet Economy Network Server Surge
Protector, 1U Rack-Mount, 15 ft. (4.57 m) Cord, 3000 Joules
The DRS-1215 is a versatile all-metal cabinet surge protector
that can be mounted in a standard 19-inch rack or a variety of
other mounting options. It comes with 14 NEMA 5-15R output
receptacles (6 front/8 rear) and a 15-ft. (4.57 m) AC cord with
NEMA 5-15P straight-in plug connection. The surge protector has a
3000 joule rating and EMI/RFI filtering for AC surge suppression.
It also has a diagnostic LED that confirms suppressor operation and
a lighted power switch that confirms power on/off status. The
product has a snap-in switch guard that prevents accidental turn
off and has a 15 amp capacity with circuit breaker. The DRS-1215 is
compatible with 120V AC, 50/60Hz electrical devices.
Product Usage Instructions:
- Choose the mounting option that best suits your needs,
including rackmount, wallmount, undercounter, or other creative
mounting options. - Insert the NEMA 5-15P straight-in plug connection into an
electrical outlet. - Connect your electrical devices to the 14 NEMA 5-15R output
receptacles. - Turn on the power by pressing the lighted power switch.
- Confirm that the diagnostic LED indicates that the suppressor
is operating properly. - If you need to turn off the power, use the snap-in switch guard
to prevent accidental turn off.
14-Outlet Economy Network Server Surge Protector, 1U Rack-Mount, 15 ft. (4.57 m) Cord, 3000 Joules
MODEL NUMBER: DRS-1215
Highlights
14 outlets / 15-ft. (4.57 m) cord 3000 joule rating Adjustable rackmount hardware
Package Includes
DRS-1215 Surge Suppressor Warranty information Instruction manual
Description
Tripp Lite’s DRS-1215 offers surge and noise suppression in a versatile all-metal multi-mount cabinet. Detachable mounting flanges are configurable for rackmount, wallmount and under-counter installation. Uses only 1 rack space (1U) when installed in any 19 inch EIA standard rack. Includes 14 outlets (6 front/8 rear), 15-ft. (4.57 m) AC power cord and guarded power switch to reduce the risk of accidental shutoff. Diagnostic LED indicates surge protection status. PLUG/OUTLETS: Input: NEMA 5-15P/Output: 14 NEMA5-15R (6 front & 8 rear) ELECTRICAL: 120V AC, 50/60Hz, 15A (Requires NEMA 5-15R wall receptacle) SUPPRESSION: AC: 140V RMS Clamping/3000 joules FORMAT: Supports 19 in. rackmount (uses 1 rack space/1U), wallmount, under-counter and more
Features
Versatile all-metal cabinet with detachable mounting flanges allows rackmount, wallmount, undercounter and other creative mounting options
Uses one rack space (1U) in standard 19 inch rack (“zero U” mounting possible in many racks) 3000 joules AC surge suppression with EMI/RFI filtering 14 NEMA 5-15R output receptacles (6 front/8 rear) 15-ft. (4.57 m) AC cord with NEMA 5-15P straight-in plug connection Diagnostic LED confirms suppressor operation Lighted power switch confirms power on/off status Snap-in switch guard prevents accidental turn off 15 amp capacity with circuit breaker 120V AC, 50/60Hz electrical compatibility
Specifications
OVERVIEW
1 / 4
Downloaded from Arrow.com.
UPC Code
037332100245
INPUT Nominal Input Voltage(s) Supported Recommended Electrical Service Voltage Compatibility (VAC) Maximum Surge Amps Input Plug Type Input Cord Length (ft.) Right-Angle Plug Input Cord Length (m) Integrated Cord Clip
120V AC 120V (110-125V) 120 120000 NEMA 5-15P 15 No 4.57 No
OUTPUT Frequency Compatibility Output (Watts) Output Receptacles Circuit Breaker (amps)
50 / 60 Hz 1800 (14) 5-15R 15
USER INTERFACE, ALERTS & CONTROLS
Diagnostic LED(s)
Yes
Switches
Power switch controls power to all outlets
Diagnostic LED Details
Green – Protection Present
Locking Switch Cover
Transparent locking switch cover prevents accidental shutoff
SURGE / NOISE SUPPRESSION AC Suppression Joule Rating AC Suppression Response Time Protection Modes Safe Thermal Fusing UL1449 Let Through Rating EMI / RFI Filtering Immunity Automatic Shut-Off
3000 < 1 ns Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression Prevents unsafe conditions during extreme extended over-voltages and catastrophic occurrences 330V 40-80 dB Conforms to IEE 587 / ANSI C62.41 No
DATALINE SURGE SUPPRESSION
Cable (Coax) Protection
No
2 / 4
Downloaded from Arrow.com.
Network (Ethernet) Protection
No
Telephone/DSL Protection
No
PHYSICAL Material of Construction Power Cord Color Form Factors Supported
Housing Color Included Mounting Accessories
Mounting Holes or Slots Outlets Measurement (Center to Center) Receptacle Color Shipping Dimensions (hwd / cm) Shipping Dimensions (hwd / in.) Shipping Weight (kg) Shipping Weight (lbs.) Unit Dimensions (hwd / in.) Unit Dimensions (hwd / cm) Unit Weight (lbs.) Unit Weight (kg) Mounting Details
Metal Black 1U rackmount, 0U vertical rackmount, wallmount and under-counter mounting supported – detachable flanges can be re-configured to support a variety of additional mounting options Black Included mounting flanges are pre-installed for 1U rackmount installation and can be re-configured to support a variety of mounting options No
Distance between front outlets = 38.9mm; Distance between rear outlets = 38.9mm
Black 23.62 x 6.35 x 51.82 9.30 x 2.50 x 20.40 2.66 5.86 1.75 x 17.5 x 4 4.45 x 44.45 x 10.16 4.6 2.09 Includes flanges
FEATURES & SPECIFICATIONS
Antimicrobial
No
Rotatable Outlets
No
STANDARDS & COMPLIANCE Canada Approvals UL1449 3rd Edition (AC Suppression) Certification & Compliance
Approved for Canada by ETL Exceeds IEEE 587 category A&B specifications UL1363 4TH EDITION, CAN/CSA-C22.2 No.308-14 UL 1363; CAN/CSA-C22.2 No.308 (Canada)
WARRANTY
Product Warranty Period (Worldwide)
Lifetime limited warranty
3 / 4
Downloaded from Arrow.com.
© 2022 Tripp Lite. All rights reserved. All product and company names are trademarks or registered trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. Tripp Lite uses primary and third-party agencies to test its products for compliance with standards. See a list of Tripp Lite’s testing agencies: https://www.tripplite.com/products/product-certification-agencies
