IR-PM-01 wireless charger equipment
Operation manual
Thank you for choosing IR-PM-01wireless charger, before getting started, please read the user’s manual carefully so as to ensure the operation.
Notice
- Do not use the charger near water, liquid, or wet areas. Clean using a soft paper or towel.
- Do not put any dangerous articles on this charger.
- Cut off the power before cleaning the charger.
- Do not try to disassemble, repair or remold the product by yourself
- Unplua this device when unused for long periods of time.
- Do not expose your charger to temperatures above 45℃ .deep out of direct sunlight.
Specifications
| input parameter | QC3.0 |
| output parameter | 01 Wireless charging |
| Output:5W/7.5W/10W | |
| Transmission distance:3-10mm | |
| Charging efficiency: _– 72% | |
| Defensive function | overcurrent protection |
| overvoltage protection | |
| short-circuit protection | |
| temperature protection, 80degrees of electricity | |
| Charging distance | 10mm Max |
| Weight | 82g |
| Dimension | D70*14mm |
Wireless charging compatible device
| Apple | iPhone8,iPhone 8Plus,iPhone X, iPhoneXs,iPhoneXs Max,iPhone XR, iPhone11 ,iPhone11pro,iPhone11proMax, iPhone se,iPhonel2. |
| Samsung | Galaxy S6,Galaxy S6 Edge,Galaxy S7, Galaxy S7 Edge,Galaxy S8,Galaxy S8+, Galaxy Note5, Galaxy Note8, Galaxy S9, Galaxy S9+,Galaxy S10,Galaxy S10+ |
| HUAWEI | Mate20 Pro,Mate20 RS,Mate RS Mate30,Mate30 Pro,P30 Pro,P40 Pro. |
| Nexus 4, Nexus 5, Nexus 6, Nexus 7, | |
| LG | G3,G4,G6,V30,V30+, |
| Any other Qi charger-supported device! |
Parts List
Transmitter ×1
User manual ×1
FCC STATEMENT This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:
- this device may not cause harmful interference, and
- this device must accept any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
The distance between user and products should be no less than 20cm
