Z-Wave Protocol Implementation Conformance Statement

General Information

Product Identifier:C-7
Brand Name:Hubitat
Product Version:HW: 1 FW: 7.13:07.13:02.03
Z-Wave Certification #:ZC12-20080110

Product Features

ColorBlack

Z-Wave Product Information

Supports Z-Wave Beaming Technology?Yes
Supports Z-Wave Network Security?Yes
Supports Z-Wave AES-128 Security S0?Yes
Supports Security S2?Yes: S2 Access Control, S2 Authenticated, S2 Unauthenticated
SmartStart Compatible?Yes

Z-Wave Technical Information

Z-Wave Frequency:Australia / New Zealand, UAE, U.S. / Canada / Mexico, CEPT (Europe)
Z-Wave Product ID:0x0001
Z-Wave Product Type:0x0001
Z-Wave Hardware Platform:EFR32Z
Z-Wave Development Kit Version:7.13.6
Z-Wave Library Type:Bridge Controller
Z-Wave Device Type / Role Type:Gateway / Central Static Controller

Association Group Information

Group # / Max NodesDescription
1 / 1Z-Wave Plus Lifeline

Hubitat Elevation

Supported Command Classes (21):

Association Group Information V3Association V3
CRC16 EncapsulationDevice Reset Locally
Firmware Update Meta-Data V5Inclusion Controller
Indicator V3Manufacturer Specific V2
Multi-Channel Association V4Multi-Command
Network Management Basic V2Network Management Proxy V2
Node ProvisioningPowerlevel
Security S0Security S2
SupervisionTime
Transport Service V2Version V3
Z-Wave Plus Info V2

Controlled Command Classes (28):

Association Group Information V3Association V3
Basic V2Central Scene V3
CRC16 EncapsulationDevice Reset Locally
Firmware Update Meta-Data V5Inclusion Controller
Indicator V3Manufacturer Specific V2
Meter V5Multi-Channel Association V4
Multi-Channel V4Multi-Command
Network Management Inclusion V3Node Provisioning
Notification V8Powerlevel
Security S0Security S2
Sensor Multilevel V11Supervision
TimeTransport Service V2
Version V3Wake Up V2
Z/IP V4Z-Wave Plus Info V2

Copyright © 2012-2021 Z-Wave Alliance. All Rights Reserved. All Logos property of respective rights’ holders, no claim intended.
Generated @ August 20, 2021
